Review this Quick Reference Guide for an overview of some important features in your GMC Terrain.

More detailed information can be found in your Owner Manual. Some optional equipment described in this guide

may not be included in your vehicle. For easy reference, keep this guide with your Owner Manual in your glove box.

www.gmc.com

Instrument Panel .............2

Remote Keyless Entry

Transmitter .................4

Rear Door Safety Locks .......4

Tilt/Telescopic Steering Wheel ..4

Driver’s Seat Adjustments......5

Rear Seat Adjustments ........6

Exterior/Interior Lighting .......6

Wipers and Washers..........7

Power Programmable Liftgate...7

Audio System ...............8

Bluetooth System ...........10

Audio Steering Wheel Controls . 10

GMC IntelliLink .............11

Navigation System ..........13

Rear Seat Entertainment

System....................13

Cruise Control ..............14

Forward Collision Alert/

Lane Departure Warning......14

Accessory Power Outlets .....15

Passenger Presence System ..15

Parking Brake ..............15

Wind Noise ................15

Driver Information Center .....16

Vehicle Personalization .......16

Climate Controls ............17

Automatic Transmission

Features ..................18

StabiliTrak/Traction

Control Systems ............18

Roof Rack Cross Rails .......19

Tire Pressure Monitor ........19

Engine Oil Life System .......19

Refueling the Vehicle ........19

Roadside Assistance.........20

myGMC and OnStar

Mobile Apps................20

GMC Owner Center..........20

This

Important

Information To Be

REMOVED

AND READ

BY THE

CUSTOMER

Turn Signal Lever/

Exterior Lamp Control

Instrument

Cluster

Tilt/Telescopic Steering

Wheel Lever

Windshield

Wipers Lever

Instrument Panel

Illumination Control

Cruise Control

Buttons

Instrument Panel

Safety Belt

Reminder

Check Engine

Low Tire Pressure

Brake System

Warning

Antilock Brake

System Warning

Charging System

Oil Pressure

Airbag Readiness

Security

Fog Lamps

Cruise Control On/Set

Traction Control Off

StabiliTrak/Traction

Control Off

StabiliTrak/Traction

Control Warning

Lights On

Audio Steering

Wheel ControlsF

Symbols

Express-Down

Power

Windows (All)

Power Door

Locks Button

Note: Refer to your Owner Manual to learn about the information being relayed by the lights, gauges

and indicators of the instrument cluster, as well as what to do to ensure safety and prevent damage.

See Instruments and Controls in your Owner Manual.

Audio System/

Navigation

SystemF

Power Door

Locks Button

StabiliTrak

Button

Center Vent

Open/Close

Control

Accessory

Power

Outlet

Rear Door

Safety Locks

Button

Hazard Warning

Flashers Button

Driver

Information

Center

Controls

Climate Controls/

Heated Seat

ButtonsF

Center Vent

Open/Close

Control

eco

Button

F Optional equipment

Remote Keyless Entry Transmitter

Unlock

Press to unlock the driver’s door. Press

again to unlock all doors and the liftgate.

Lock

Press to lock all doors and the liftgate.

The driver’s door will not lock if open.

TIP: The unlock and lock settings can be

changed in the Vehicle Settings menu by using

the audio system controls.

Liftgate

Press to open/stop/close the power liftgate

(optional).

Vehicle Locator/Panic Alarm

Press and release to locate your vehicle.

The turn signal lamps will ash and the

horn will sound.

Press and hold to activate the alarm. The

turn signal lamps will ash and the horn will

sound until the button is pressed again or

the ignition is turned on.

Remote Vehicle StartF

Press and release the Lock button and

then press and hold the button to start

the engine from outside the vehicle. After

entering the vehicle, turn the ignition to the

On position.

– The engine will run for 10 minutes.

Repeat these steps for a 10-minute

time extension.

– Only two remote starts are allowed

between ignition cycles.

– Press and hold the button to cancel

a remote start.

Note: Open the Vehicle Settings in the

Conguration menu to have the heated seatsF

turn on during a remote start.

See Keys, Doors and Windows in your Owner Manual.

Tilt/Telescopic Steering Wheel

With the vehicle in Park, push down the lever on the left side of the steering column to

adjust the steering wheel. The steering wheel can then be moved up or down and in or

out. After adjustment, pull up the lever to lock the steering wheel in place.

See Instruments and Controls in your Owner Manual.

Rear Door Safety Locks

FOptional equipment

Press the rear door Safety Locks

button located on the center of the instru-

ment panel to prevent the rear doors

from opening from the inside. Press

again for normal operation.

See Keys, Doors and Windows in your Owner Manual.

A B C

A. Seat Fore/Aft Adjustment

Lift the handle under the front of the

seat to manually slide the seat forward

or rearward.

B. Seat Height Adjustment

Press the vertical control to raise or

lower the seat.

C. Lumbar Adjustment

Press the horizontal control to adjust the

amount of lumbar support.

D. Seatback Recline Adjustment

Lift the lever to manually recline or raise

the seatback.

Manual Driver’s Seat

Power Driver’s SeatFA. Seat Adjustment

Move the front horizontal control to

move the seat forward or rearward and

to raise, lower or tilt the seat.

B. Seatback Recline Adjustment

Move the vertical control to recline or

raise the seatback.

C. Lumbar Adjustment

Press the rear horizontal control to

adjust the amount of lumbar support.

A B C

Memory Driver’s SeatF

Set Memory Positions

1. Adjust the driver’s seat and power outside mirrors to the desired position.

2. Press and hold the MEM button and button 1 on the outboard side of the driver’s seat

until a beep sounds.

3. Repeat these steps using button 2 for a second driver.

Recall Memory Positions

Press and hold button 1 or 2 until the memory position is reached.

The memory positions also can be programmed using the Vehicle Settings menu to be

recalled automatically.

See Seats and Restraints in your Owner Manual.

F Optional equipment

Driver’s Seat Adjustments

Exterior/Interior Lighting

Automatic Headlamp System

Rotate the outer band to operate the

exterior lamps.

Headlamps

Manual operation of the headlamps.

Parking Lamps

Manual operation of the parking lamps.

AUTO Automatic Headlamp System

Activates the Daytime Running Lamps

(DRLs) in the daytime and the headlamps

and other exterior lamps at night or when

necessary.

Off/On

Fog Lamps

Rotate the inner band to turn the fog lamps

on or off.

TIP: Push the lever to turn on the high beam

headlamps; pull the lever to return to low beam

operation. Pull the lever to activate the ash-to-

pass feature.

Instrument Panel Lighting

The control knob is located on the left

side of the instrument panel next to the

steering column.

Instrument Panel Brightness

Turn the knob to increase or decrease

the instrument panel lighting.

Dome Lamp

The dome lamps are controlled by a

three-position switch on the front overhead

console.

Dome Lamp Override/Off

Door Open (Default position)

See Lighting in your Owner Manual.

Note: The second-row dome lamps also can be

turned on/off using the buttons by the lamps.

A. Seat Fore/Aft Adjustment

Lift the bar under the front of the seat

to manually slide the seat forward or

rearward.

B. Folding/Reclining Seatback

Lift the lever on top of each seatback to

fold down the seatback.

Lift and hold the lever to adjust the seat-

back to any of three recline positions.

See Seats and Restraints in your Owner Manual.

A B

Rear Seat Adjustments

Wipers and Washers

Windshield Wipers and Washer

Move the lever to operate the

windshield wipers.

HI Continuous High Speed

LO Continuous Low Speed

INT Intermittent

Rotate the band to adjust the delay

between wipes.

OFF

Mist

Washer Fluid

Pull the lever toward you to spray washer

uid on the windshield.

Rear Wiper and Washer

The rear wiper switch is located on the end

of the wiper lever.

A. ON Continuous Low Speed

B. OFF

C. INT Intermittent

Washer Fluid

Push the lever away from you to spray

washer uid on the rear window.

See Instruments and Controls in your Owner Manual.

Power Programmable LiftgateF

Programming the Liftgate Height

1. Turn the power liftgate switch to the

3/4 mode position.

2. Open the liftgate by pressing the RKE

transmitter liftgate button or the touch-

pad on the center of the liftgate.

3. Stop the liftgate at the desired height

by pressing any liftgate button. Adjust

manually to the desired height if

necessary.

4. To save the setting, press and hold the

button next to the liftgate latch for three

seconds. The taillamps will ash when

the setting is saved.

See Keys, Doors and Windows in your Owner Manual.

MAX

Fully open the liftgate.

3/4

Open the liftgate to the programmed height.

OFF

Operate the liftgate manually.

F Optional equipment

Audio System

See your Infotainment System Owner Manual.

Power/

Volume

HOME

HOME:

Main screen

BACK:

Move back

one level in

the menus

1–6:

Preset

radio

stations

SOURCE:

Select radio

band, CD,

auxiliary source

FAV:

Display pages

of favorite

radio stations

MENU/SEL:

Tune radio

stations/

Open and

select a menu

SEEK:

Previous/

Next radio

station or track

CONFIG:

Congure

system

settings

Phone

Mute

Time

INFO:

Display

available

song

information

Eject

disc

TONE:

Tone and

sound

settings

PLAY/

PAUSE

Standard audio system shown.

Other systems are similar.

Audio System

Note: Avoid extended searching for specic items or conguring system settings while driving.

Setting the Time

1. Press the Clock button.

2. Touch the Set Time screen button.

3. Touch the + (plus) or – (minus) screen button to adjust the hours, minutes or date.

4. Touch the OK screen button to conrm the setting.

Storing Favorite Stations

Radio stations from all bands (AM, FM or XM♦) can be stored, in any order, on up to six

pages of favorites.

1. Tune in the desired radio station.

2. Press the FAV button to display the page where the station is to be stored.

3. Press and hold one of the six preset screen buttons until a beep is heard.

4. Repeat the steps for each desired station.

Portable Audio Devices

An accessory power outlet, 3.5mm auxiliary

input jack and a USB portFare located in

the center console.

An iPod™, iPhone™, MP3 Player, a

USB ash drive or a USB mass storage

device can be connected to the USB

port. GMC IntelliLinkFwill read the

device, build a list of voice commands,

and ll in missing song information and

album graphics. Search for music on-

screen or by voice commands.

A portable audio device connected to the auxiliary input jack can be controlled only

by using the portable device controls. To optimize speaker volume, fully increase the

volume level of the portable device.

Active Noise Cancellation (4-cylinder models only)

The Active Noise Cancellation (ANC) system monitors and effectively cancels out poten-

tially undesirable vehicle noises at certain vehicle speeds. For optimal ANC performance,

do not block the rear speaker located on the right side of the cargo area.

See your Infotainment System Owner Manual.

F Optional equipment

10 FOptional equipment

Bluetooth® System

Before using a Bluetooth-enabled device in the vehicle, it must be paired with the

in-vehicle Bluetooth system. Not all devices will support all functions. Bluetooth streaming

audio is available with the IntelliLink system.F For more information, visit

www.gm.com/bluetooth.

Pair a Phone

1. To use voice recognition, press the Voice Recognition button on the steering

wheel; after the beep, say “Pair.”

To use the screen buttons, press the CONFIG button and then touch Phone Settings >

Pair Device.

2. Start the pairing process on the phone. Locate your vehicle name on the phone.

3. Enter the four-digit code that appears on the touch screen into the phone or conrm the

six-digit code on the phone.

4. If your phone prompts you to accept the connection or phone book download, click “yes”

and always allow.

See your Infotainment System Owner Manual.

Audio Steering Wheel Controls

Next/Previous

Rotate up or down to go to the next or

previous favorite radio station, track or le.

Push to Talk

Press to start voice recognition.

Say OnStar, navigation or an IntelliLink

command.

End Call/Mute

Press to end or reject an OnStar or

a Bluetooth call.

Press to mute the vehicle speakers.

See Instruments and Controls in your Owner Manual.

+ VOL – Volume

Press +or –to adjust the volume.

SRC Source

Press to select an audio source.

Autres manuels pour 2013 Terrain

Table des matières

Autres manuels GMC Automobile

GMC

GMC 2002 Envoy Manuel d'utilisation et d'entretien

GMC

GMC 2008 Canyon Instructions de montage

GMC

GMC 2012 GMC Sierra Denali Manuel utilisateur

GMC

GMC 2008 Yukon Instructions de montage

GMC

GMC SIERRA CK2 1999 Manuel utilisateur

GMC

GMC 2005 Canyon Manuel utilisateur

GMC

GMC Buick Encore 2022 Manuel utilisateur

GMC

GMC 2011 Yukon Denali Manuel utilisateur

GMC

GMC Sierra Denali 2006 Manuel utilisateur

GMC

GMC Sierra Manuel utilisateur

GMC

GMC 2017 Canyon Manuel utilisateur

GMC

GMC YUKON/XL 2022 Manuel utilisateur

GMC

GMC 2012 GMC Canyon Manuel utilisateur

GMC

GMC TERRAIN 2018 Manuel utilisateur

GMC

GMC 2001 Savana Van Manuel utilisateur

GMC

GMC YUKON/XL 2019 Manuel utilisateur

GMC

GMC SIERRA 2500 HEAVY DUTY 2023 Manuel utilisateur

GMC

GMC Sierra 2023 Manuel utilisateur

GMC

GMC 2009 Envoy Denali Instructions de montage

GMC

GMC Savana 2008 Instructions de montage

GMC

GMC 2007 Sierra Instructions de montage

GMC

GMC 1993 Safari Manuel utilisateur

GMC

GMC 1994 Yukon Manuel utilisateur

GMC

GMC Chevrolet Silverado 2500 HD 2022 Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur

Skoda

Skoda FABIA RS - ANNEXE 118 Manuel utilisateur

Seat

Seat toledo Manuel utilisateur

PEUGEOT

PEUGEOT 206 CC Manuel utilisateur

SSANGYONG

SSANGYONG ACTYON 2010.01 Manuel utilisateur

Renault

Renault Master Manuel utilisateur
