HOLDEN CG CAPTIVA 7 Guide de l'utilisateur

OWNER’S HANDBOOK

CG CAPTIVA 7

HOLDEN.COM.AUCG CAPTIVA 7

GM Holden Ltd, ABN 84 006 893 232 (hereinafter Holden)

Change of name, address or ownership

In the event of a Safety Recall, or for various reasons,

Holden may need to contact you as the owner of this vehicle.

If you have recently changed your address, or name, or purchased this

vehicle second-hand, please help us to help you by taking a few minutes

to ll in and mail the forms at the beginning of the Service/warranty booklet.

For information about GM Holden’s privacy policy or to update owner

details online, please visit Holden’s website at www.holden.com.au

Note Please refer to the inside front cover of the Service/

warranty booklet for the Vehicle Identication Certicate.

Printed in Australia

Part No. 92274448

March 2014 (MY14 CG Captiva 7. Print 2)

Reproduction in whole or part is prohibited

without written approval from GM Holden Ltd,

ABN 84 006 893 232

CAPTIVA 7_IFC.indd 1 14/03/2014 10:34:25 AM

Contents 1

Introduction .................................... 2

In brief ............................................ 4

Keys, doors, and windows ........... 16

Seats, restraints ........................... 29

Storage ........................................48

Instruments and controls ............. 53

Lighting ........................................83

Infotainment system ..................... 89

Climate control ........................... 141

Driving and operating ................ 151

Vehicle care ............................... 190

Service and maintenance .......... 240

Technical data ............................ 242

Customer information ................ 248

Index ..........................................250

BOOK_MY14_CAPTIVA 7.indb 1 19/11/2013 2:56:46 PM

2 Introduction

Introduction

We thank you for choosing Holden and want to

assure you of our continuing interest in your

driving pleasure and satisfaction.

This handbook applies to the current Captiva model.

Therefore, due to different models and options, you may

nd reference in this Handbook to some equipment

not tted to your own vehicle.

Please note that all information, illustrations and

specications in this Handbook are based on the latest

production information available at the time of printing.

Holden reserves the right to make changes at any time

without notice and without incurring any obligation.

BOOK_MY14_CAPTIVA 7.indb 2 19/11/2013 2:56:46 PM

Introduction 3

Introduction

Your vehicle is a designed

combination of advanced technology,

safety, environmental friendliness and

economy.

This Owner’s Handbook provides

you with all the necessary

information to enable you to drive

your vehicle safely and efciently.

Make sure your passengers are

aware of the possible risk of accident

and injury which may result from

improper use of the vehicle.

Using this manual

• The In brief section will give you

an initial overview.

• The table of contents at the

beginning of this manual and

within each chapter shows where

the information is located.

• The index will enable you to

search for specic information.

• Directional data, e.g. left or right,

or front or back, always relate to

the direction of travel.

• Depending on the model variant,

integrated special equipment

and accessories, the scope of

equipment of your vehicle can

differ from the descriptions in this

Owner’s Handbook.

• The Bluetooth®word mark and

logo are registered trademarks

and are owned by the Bluetooth

SIG, Inc.

Danger, warnings

and cautions

Danger

Text marked Danger provides

information on risk of fatal injury.

Disregarding this information may

endanger life.

Warning

Text marked Warning

provides information on risk of

accident or injury. Disregarding

this information may lead to injury.

Caution

Text marked Caution provides

information on possible damage

to the vehicle. Disregarding this

information may lead to vehicle

damage.

BOOK_MY14_CAPTIVA 7.indb 3 19/11/2013 2:56:46 PM

4 In brief

In brief

Initial drive

information

Unlocking the vehicle

Remote keyless entry

Q K

The keyless access transmitter

operates all door locks:

Q: Lock

K : Unlock

: Panic vehicle/locate button

The code number for the keys is

stamped on the key plate (A).

Keys and locks, see page 16.

Doors, see page 19.

Manual door locks

Q K

To remove the key for manual door

operation:

1. Press (A).

2. Remove the key from the

transmitter.

Note

Do not remove the key without

pressing the button.

BOOK_MY14_CAPTIVA 7.indb 4 19/11/2013 2:56:47 PM

In brief 5

• To lock all doors, insert the key

into the driver’s door lock and

turn anticlockwise (A), then turn

back to the vertical position and

remove.

• To unlock all doors, insert the

key into the driver’s door lock

and turn clockwise (B), then turn

back to the vertical position and

repeat, then remove.

Keys and locks, see page 16.

Doors, see page 19.

Seat adjustment

The vehicle may have the following

levers and switches for seat

adjustment.

Forwards/backwards (Type A)

Up/down (Type A)

Recline (Type A)

BOOK_MY14_CAPTIVA 7.indb 5 19/11/2013 2:56:47 PM

6 In brief

Lumbar

Forwards/backwards (Type B)

Up/down (Type B)

Recline (Type B)

Front seats, see page 30.

Head restraints

Warning

The head restraint safety feature

is not intended to rest the head

upon. It is solely for the reduction

of whiplash neck movement in an

accident involving the vehicle.

The centre of the head restraint

should be at eye level, never at

neck level.

To adjust the height:

1. Push the button in.

BOOK_MY14_CAPTIVA 7.indb 6 19/11/2013 2:56:47 PM

In brief 7

2. Pull the head restraint up or push

the head restraint down.

To tilt the front head restraints:

1. Place the head restraint in its

upright position by pushing it

forward fully and releasing it.

2. Push the head restraint forward

carefully to the required position.

Head restraints, see page 29.

Seat belts

The belt should not be twisted. It

should lie at and t rmly across

your hips.

1. Pull the metal tongue across

your body.

2. Clip it into the buckle.

When the metal tongue is locked

safely into place you will hear a

click.

Three point belt, see page 37.

Mirror adjustment

Rear view mirror

Adjust the rear view mirror by

moving right or left, up or down.

To reduce headlamp glare at night

from following vehicles, pull the lever

towards the rear of the vehicle.

For daylight operation, push the

lever towards the front of the vehicle.

Interior mirrors, see page 24.

Automatic dimming rear view mirror,

see page 25.

BOOK_MY14_CAPTIVA 7.indb 7 19/11/2013 2:56:47 PM

8 In brief

Steering wheel

adjustment

Warning

Do not attempt to adjust the

steering wheel while driving.

1. To unlock, move the lever down.

2. To adjust, move the steering

wheel up, down, closer or away.

3. To lock, move the lever up.

Ensure the steering wheel is

locked in position before driving.

Controls, see page 54.

Exterior mirrors

Power mirrors

To adjust the mirrors, turn the

ignition control knob to the on or

accessories position:

• Move switch (A) to the right to

operate the driver side mirror.

• Move switch (A) to the left to

operate the passenger side

mirror.

Exterior mirrors, see page 23.

BOOK_MY14_CAPTIVA 7.indb 8 19/11/2013 2:56:47 PM
