HOLDEN MP Spark 2019 Manuel utilisateur

MY19 MP Spark

Owner’s Manual

holden.com.au

GM Holden Ltd, ABN 84 006 893 232, Holden New Zealand Ltd., Company Number 1602 (hereinafter Holden)

Change of name, address or ownership

If you drive a pre-owned Holden, have moved house or changed any of your details, we’d like to hear from you!

Holden uses your details to keep your vehicle’s factory provided RoadsideAssistance and Warranty details up to date.

It also helps us let you know if there is an existing rework action required on your vehicle. To update your details, please

take a few minutes to ll in and mail the form at the back of the Service & Warranty Booklet or visit Holden’s website at:

www.holden.com.au/forms/change-of-owner-details

GM Holden Ltd (Holden) is collecting the new owner’s personal information in order to process the request for

transfer for the specied vehicle. We may disclose your personal information to our related companies and third

parties who provide us with (or help us provide) products and services, including to overseas locations such as the

USA, and other countries in Europe, Oceania and Asia.

Holden’s privacy policy (available at: www.holden.com.au/privacypolicy) states how you can seek to access or correct

any personal information Holden holds about you, how to complain about a privacy breach by Holden and how

Holden will deal with a privacy complaint.

You can contact Holden on 1800 033 349 or alternatively, you may prefer to email Holden at:

[email protected]

Note: Please refer to the inside front cover of the Service & Warranty Booklet for the Vehicle Identication Certicate.

Printed in Australia Reproduction in whole or part is

Part No. 92510126 prohibited without written approval from

May 2018 GM Holden Ltd., ABN 84 006 893 232 (Australia) or

(MY19 MP Spark. Print 1) Holden New Zealand Ltd., Company Number 1602 (New Zealand)

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-
12588158) - 2019 - crc - 5/15/18
Contents Introduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 16
Seats and Restraints . . . . . . . . . . . 32
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 48
Instruments and Controls . . . . . . . 51
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . 75
Infotainment System . . . . . . . . . . . . 80
Climate Controls . . . . . . . . . . . . . . 101
Driving and Operating . . . . . . . . . 106
Vehicle Care . . . . . . . . . . . . . . . . . . 134
Service and Maintenance . . . . . 176
Technical Data . . . . . . . . . . . . . . . . 178
Customer Information . . . . . . . . . 183
Index .................... 186

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-

12588158) - 2019 - crc - 5/15/18

2 Introduction

Introduction

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-

12588158) - 2019 - crc - 5/15/18

Introduction 3

Introduction

Your vehicle is a designed

combination of advanced

technology, safety, environmental

friendliness and economy.

This owner's manual provides you

with all the necessary information to

enable you to drive your vehicle

safely and efficiently.

Make sure your passengers are

aware of the possible risk of

accident and injury which may result

from improper use of the vehicle.

Using this Manual

.This manual describes all

options and features available

for this model. Certain

descriptions, including those

for display and menu

functions, may not apply to

your vehicle due to model

variant, special equipment or

accessories.

.The "In brief" section will give

you an initial overview.

.The table of contents at the

beginning of this manual and

within each section shows where

the information is located.

.The index will enable you to

search for specific information.

.Directional data, e.g. left or right,

or front or back, always relate to

the direction of travel.

.Display messages and interior

labelling are written in bold

letters.

.For a complete list of the

registered trademarks contained

in this manual, see Trademarks

and License Agreements.

Trademarks and Licence

Agreements 0183.

Danger, Warning, and

Caution

{Danger

Text marked {Danger provides

information on risk of fatal injury.

Disregarding this information may

endanger life.

{Warning

Text marked {Warning provides

information on risk of accident or

injury. Disregarding this

information may lead to injury.

Caution

Text marked Caution provides

information on possible damage

to the vehicle. Disregarding this

information may lead to vehicle

damage.

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-

12588158) - 2019 - crc - 5/15/18

4 Introduction

2NOTES

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-

12588158) - 2019 - crc - 5/15/18

In Brief 5

In Brief

Initial Drive Information

Vehicle unlocking . . . . . . . . . . . . . . . 5

Seat Adjustment . . . . . . . . . . . . . . . . 6

Head Restraint Adjustment . . . . . . 7

Safety Belts . . . . . . . . . . . . . . . . . . . . . 7

Mirror Adjustment . . . . . . . . . . . . . . . 7

Steering Wheel Adjustment . . . . . 8

Instrument Panel Overview . . . . . . 9

Exterior Lighting . . . . . . . . . . . . . . . 10

Horn ........................... 12

Windshield Wiper/Washer . . . . . . 12

Climate Controls . . . . . . . . . . . . . . . 13

Transmission . . . . . . . . . . . . . . . . . . 14

Starting the Engine . . . . . . . . . . . . 14

Parking . . . . . . . . . . . . . . . . . . . . . . . . 15

Initial Drive

Information

Vehicle unlocking

Press Kto unlock the doors and

tailgate. Open the doors by pulling

the handles.

The hazard warning flashers will

flash twice.

To open the tailgate, push the

touchpad switch under the tailgate

moulding.

Remote Control 018,

Central Locking System 020,

Boot 024.

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-

12588158) - 2019 - crc - 5/15/18

6 In Brief

Seat Adjustment

Seat positioning

1. Move the seat forwards or

backwards by lifting the bar at

the front and sliding the seat.

2. Release the bar to engage the

latch.

Try to move the seat back and

forth to ensure the seat is

locked in place.

Seat Position 033,Seat Adjustment

033.

Seat backrests

1. Recline the seatback by pulling

the lever.

2. Adjust the angle and release

the lever.

3. Allow the seat to engage

audibly.

Note

Do not lean on the seat when

adjusting.

Seat Position 033,Seat Adjustment

033.

Seat height

Pump the lever on the outside of the

seat cushion.

1. Push the lever down several

times to lower the seat

cushion.

2. Pull the lever up several times

to raise the seat cushion.

Seat Position 033,Seat Adjustment

033.

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-

12588158) - 2019 - crc - 5/15/18

In Brief 7

Head Restraint

Adjustment

.Lift the head restraint up to

raise.

.Push the locking button and

push the head restraint down to

lower.

.Push the locking buttons on

each head restraint post and pull

the head restraint up to remove.

Safety Belts

1. Withdraw the belt from the reel.

2. Pull the metal tongue across

your body into the buckle, until

it clicks into place.

3. Tension the lap belt regularly

while driving by tugging the

shoulder belt.

Seat Position 033,

Seat Belts 036,

Airbag System 040.

Mirror Adjustment

Interior Mirror

To reduce headlamp glare from

following vehicles, push the lever

towards the front of the vehicle.

Manual Rearview Mirror 027.

Holden Spark (Next Gen) Owner Manual (GMK-Localizing-Holden-

12588158) - 2019 - crc - 5/15/18

8 In Brief

Exterior Mirrors

Select the relevant exterior mirror by

turning the control left (L) or

right (R). Then swivel the control to

adjust the mirror. In position 0 no

mirror is selected.

Power Mirrors 027.

Steering Wheel

Adjustment

{Warning

Do not attempt to adjust the

steering wheel while driving.

1. To unlock, move the

lever down.

2. Adjust the steering wheel.

3. To lock, move the lever up.

4. Ensure the steering wheel is

locked in position before

driving.
