Hirschmann OCTOPUS 8M-8PoE Manuel utilisateur

OCTOPUS 8M/16M/24M/OS32

Release

05/2012

Technical Support

https://hirschmann-support.belden.eu.com

User Manual

Installation

IP67 / IP54 Switch

OCTOPUS 8M..., OCTOPUS 16M..., OCTOPUS 24M...,

OCTOPUS OS32...

OCTOPUS 24M OCTOPUS 24M-2FX

OCTOPUS 16M-2FX

OCTOPUS 16MOCTOPUS 8M

OCTOPUS 24M-...FX

OCTOPUS 24M...

OCTOPUS 16M-...FX

OCTOPUS 16M...

OCTOPUS 8M...

OCTOPUS OS32-081602O6O6...

OCTOPUS OS32-081602T6T6...

P1 P2 RM FAULT

V.2 4

ACA

Power

Managed

ETHERNET Switch

x y

OCTOPUS

OS32

Produktcode

IP-ADDRESS

FunctionPin

N.C.

GND

+48V DC

FunctionPin

FAULT 3

TP-Ports

P1 P2 RM FAULT

V.2 4

ACA

Power

Managed

ETHERNET Switch

x y

OCTOPUS

OS32

Produktcode

IP-ADDRESS

FunctionPin

N.C.

GND

+48V DC

FunctionPin

FAULT 3

TP-Ports

FunctionPin

1 MDX1+

2 MDX1 -

3 MDX0+

4 MDX0 -

5 MDX2+

6 MDX2 -

7 MDX3 -

8 MDX3+

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use. For devices with embedded software, the end-user license agreement on the

enclosed CD applies.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Printed in Germany

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Tel.: +49 (0)1805 14-1538

OCTOPUS 8M/16M/24M/OS32 039 679-002-10-0512 -8.5.12

OCTOPUS 8M/16M/24M/OS32

Release

05/2012 3

Contents

Safety instructions 5

About this Manual 12

Legend 12

1 Device description 13

1.1 General device description 13

1.2 Description of the device variants 14

1.2.1 Devices without Power over Ethernet 14

1.2.2 Devices with Power over Ethernet 14

2 Assembly and start-up 17

2.1 Installing the device 17

2.1.1 Unpacking and checking 17

2.1.2 Installing the SFP modules (optional) 17

2.1.3 Connecting the connector for

supply voltage and signal contact 18

2.1.4 Installing the device and grounding 20

2.1.5 Connecting the supply voltage, starting up 25

2.1.6 Connecting the data lines 25

2.2 Display elements 29

2.3 Basic set-up 30

3 Disassembling the SFP modules (optional) 33

4 Technical data 34

A Further Support 43

4OCTOPUS 8M/16M/24M/OS32

Release

05/2012

OCTOPUS 8M/16M/24M/OS32

Release

05/2012 5

Safety instructions

Important Information

Notice: Read these instructions carefully, and look at the equipment to

become familiar with the device before trying to install, operate, or

maintain it. The following special messages may appear throughout this

documentation or on the equipment to warn of potential hazards or to call

attention to information that clarifies or simplifies a procedure.

The addition of this symbol to a Danger or Warning safety label

indicates that an electrical hazard exists, which will result in

personal injury if the instructions are not followed.

This is the safety alert symbol. It is used to alert you to potential

personal injury hazards. Obey all safety messages that follow

this symbol to avoid possible injury or death.

Note: A note contains important information on the product, on how to

manage the product, or on the respective section of the documentation to

which your special attention is being drawn.

DANGER

DANGER indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided,

can result in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided,

can result in minor or moderate injury.

6OCTOPUS 8M/16M/24M/OS32

Release

05/2012

Certified usage

The device may only be employed for the purposes described in the

catalog and technical description, and only in conjunction with external

devices and components recommended or

approved by the manufacturer. The product can only be operated cor-

rectly and safely if it is transported, stored, installed and assembled pro-

perly and correctly. Furthermore, it must be operated and serviced

carefully.

Warning!

Do not use the device in safety-related applications - in particular

where life and limb may be in danger.

Supply voltage

For safety reasons the devices have been designed to operate at low

voltages. Thus, they may only be connected to the supply voltage

connections and to the signal contact with SELV circuits with the voltage

restrictions in accordance with IEC/EN 60950-1.

Operational environment

In the inside of buildings

In the inside of vehicles

Table 1: Operational environment

OCTOPUS 8M/16M/24M/OS32

Release

05/2012 7

The supply voltage is electrically isolated from the housing.

Use undamaged parts.

Only use voltage supply cables with the permitted diameter specified

by the manufacturer of the right angled cable socket.

Relevant for North America:

Devices without Power-over-Ethernet (PoE) may only be connected to

a supply voltage of class 2 that fulfills the requirements of the National

Electrical Code, Table 11(b). If the voltage is being supplied

redundantly (two different voltage sources), the combined supply

voltages must fulfill the requirements of the National Electrical Code,

Table 11(b).

Relevant for North America: For use in Class 2 circuits.

Only use copper wire/conductors of class 1, 75 °C (167 °F).

Relevant for North America

for devices certified for hazardous locations:

Power, input and output (I/O) wiring must be in accordance with

Class I, Division 2 wiring methods [Article 501-4(b) of the National

Electrical Code, NFPA 70] and in accordance with the authority having

jurisdiction.

Shielding ground

Note: The shielding ground of the connectable twisted pair lines is

connected to the housing as a conductor.

Beware of possible short circuits when connecting a cable section with

conductive shielding braiding.

Housing

Only technicians authorized by the manufacturer are permitted to open

the housing.

The device is grounded via the separate ground screw.

Make sure that the electrical installation meets local or nationally

applicable safety regulations.

WARNING

RISK OF BURNING

The surfaces of the device housing may become hot. Avoid touching the

device while it is operating. Wait until the device has cooled down.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

8OCTOPUS 8M/16M/24M/OS32

Release

05/2012

Environment

The device may only be operated at the specified surrounding air

temperature (temperature of the surrounding air at a distance of up to

5 cm (1.97 in) from the device) and relative air humidity specified in the

technical data.

Install the device in a location where the climatic threshold values

specified in the technical data are adhered to. Make sure the

environment does not heat the device. It can be mounted on

temperature-isolating material.

Use the device only in an environment within the pollution degree

specified in the technical data.

Qualification requirements for personnel

Qualified personnel as understood in this manual and the warning signs,

are persons who are familiar with the setup, assembly, startup, and

operation of this product and are appropriately qualified for their job. This

includes, for example, those persons who have been:

trained or directed or authorized to switch on and off, to ground and to

label power circuits and devices or systems in accordance with current

safety engineering standards;

trained or directed in the care and use of appropriate safety equipment

in accordance with the current standards of safety engineering;

trained in providing first aid.

General safety instructions

Please note that products recommended as accessories may have

characteristics that do not fully correspond to those of the corresponding

product. This may limit their possible usage in the overall system.

Electricity is used to operate this equipment. Comply with every detail of

the safety requirements specified in the operating instructions regarding

the voltages to apply.

See “Supply voltage” on page 6.

OCTOPUS 8M/16M/24M/OS32

Release

05/2012 9

Non-observance of these safety instructions can therefore cause material

damage and/or injuries.

Only appropriately qualified personnel should work on this device or in

its vicinity. Qualified personnel must be thoroughly familiar with the

warnings and maintenance procedures in accordance with this

operating manual.

The proper and safe operation of this device depends on proper

handling during transport, proper storage and assembly, and

conscientious operation and maintenance procedures.

Never start operating the device with damaged components.

Only use the devices in accordance with this manual. In particular,

observe the warnings and safety-related information.

Any work that may be required on the electrical installation may only

be carried out by personnel trained for this purpose.

Relevant for OCTOPUS 16M-2FX, OCTOPUS 16M-8PoE-2FX,

OCTOPUS 24M-2FX, OCTOPUS OS32-08xx02O6O6...:

Note: LED or LASER components in compliance with IEC 60825-1

(2007):

CLASS 1 LASER PRODUCT

CLASS 1 LED PRODUCT

National and international safety regulations

Make sure that the electrical installation meets local or nationally

applicable safety regulations.

E marking

The devices comply with the regulations contained in the following

European directive(s):

72/245/EWG, 2009/19/EG

Guideline for standardizing the regulations of member states relating to

radio interference from motor vehicles. Certified devices are marked with

an e1 type approval indicator.

(Relevant for OCTOPUS 8M-8PoE, OCTOPUS 8M-6PoE, OCTOPUS

16M-8PoE, OCTOPUS 16M-8PoE-2FX, OCTOPUS 24M-8PoE)

Rule No.10 of the Economic Commission for Europe (ECE): Devices with

a certification are labelled with the E1 type-approval mark.

(Relevant for OCTOPUS OS32...)

Note: For use in connection with a suitable type approved power supply

only.

10 OCTOPUS 8M/16M/24M/OS32

Release

05/2012

CE marking

The devices comply with the regulations contained in the following

European directive(s):

2004/108/EC

Directive of the European Parliament and the council for standardizing

the regulations of member states with regard to electromagnetic

compatibility.

In accordance with the above-named EU directive(s), the EU conformity

declaration will be at the disposal of the relevant authorities at the

following address:

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Tel.: +49 (0)1805 14-1538

The product can be used in the industrial sector.

Interference immunity: EN 61000-6-2:2005

Emitted interference: EN 55022:2010

Warning! This is a class A device. This device can cause interference in

living areas, and in this case the operator may be required to take

appropriate measures.

Note: The assembly guidelines provided in these instructions must be

strictly adhered to in order to observe the EMC threshold values.

FCC note:

This device complies with part 15 of the FCC rules. Operation is subject

to the following two conditions : (1) This device may not cause harmful

interference; (2) this device must accept any interference received,

including interference that may cause undesired operation.

Appropriate testing has established that this device fulfills the

requirements of a class A digital device in line with part 15 of the FCC

regulations.

These requirements are designed to provide sufficient protection against

interference when the device is being used in a business environment.

The device creates and uses high frequencies and can also radiate high

frequencies, and if it is not installed and used in accordance with this

operating manual, it can cause radio transmission interference. The use

of this device in a living area can also cause interference, and in this case

the user is obliged to cover the costs of removing the interference.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hirschmann Changer

Hirschmann

Hirschmann 943 686-003 Manuel utilisateur

Hirschmann

Hirschmann Power MICE Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann MACH102 Series Manuel utilisateur

Hirschmann

Hirschmann Octopus II Manuel utilisateur

Hirschmann

Hirschmann LION-GIGA-1SX Manuel utilisateur

Hirschmann

Hirschmann RS1 Series Manuel

Hirschmann

Hirschmann OCTOPUS OS20 Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann RH1-TP Manuel

Hirschmann

Hirschmann MACH104-20TX-F Series Manuel utilisateur

Hirschmann

Hirschmann BRS20-0400 Series Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann CS30 Manuel utilisateur

Hirschmann

Hirschmann OCTOPUS 8M Series Manuel utilisateur

Hirschmann

Hirschmann GREYHOUND GMM42 Manuel utilisateur

Hirschmann

Hirschmann Dragon PTN Manuel utilisateur

Hirschmann

Hirschmann ETHERNET IP67 Instructions d'utilisation et d'installation

Hirschmann

Hirschmann OCTOPUS OS20 Manuel utilisateur

Hirschmann

Hirschmann SPIDER 8TX-PRO Manuel utilisateur

Hirschmann

Hirschmann RSPE 30 Manuel utilisateur

Hirschmann

Hirschmann MACH1000 Series Manuel utilisateur

Hirschmann

Hirschmann MACH 100 Manuel utilisateur

Hirschmann

Hirschmann RH1-CX+ Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
