GE 24991 Manuel utilisateur

Universal Remote

Instruction Manual

Control Remoto Universal

Manual de Instrucciones

24991

7252

Congratulations on your purchase of the GE Universal

Remote. This remote is capable of operating

thousands of audio/video devices including TVs, DVD

players, cable, satellite receivers and more!

IMPORTANT:

SAVE THIS MANUAL AND CODE LIST FOR FUTURE

REFERENCE

Introduction..................................................................................... 2

Battery Installation ...................................................................... 3

Button Functions .......................................................................... 4

Programming Your Remote..................................................... 6

Direct Code Entry.......................................................................... 6

Auto Code Search......................................................................... 8

Master Volume Feature...........................................................11

Reset to Factory Settings........................................................12

Troubleshooting..........................................................................13

FCC Statement.............................................................................15

Table of Contents

Scan this to view remote

setup video

Mira a ver el video de

instalación remota

http://www.jascoproducts.com/remote

Your universal remote requires two (2) AAA

Alkaline batteries.

To Install the Batteries:

1. Remove the battery compartment cover by sliding

the cover down.

2. Match the (+) and (-) marks on the batteries to the

(+) and (-) marks inside the battery compartment,

then insert two (2) AAA Alkaline batteries. Be sure

to use fresh batteries.

3. Slide the battery compartment cover back

into place.

Note: If your remote stops operating properly, replace

the batteries with new ones. The remote will retain

the codes you have programmed for up to 10 minutes

after the batteries are removed.

Battery Precautions:

• Donotmixoldandnewbatteries.

• Donotmixalkaline,standard(carbon-zinc),or

rechargeable (Ni-Cd, Ni-MH, etc.) batteries.

• Alwaysremoveold,weakorworn-outbatteries

promptly and recycle or dispose of them in

accordance with local and national regulations.

Battery Installation

INPUT Selects the video

inputs from available

viewing sources.

In SHIFT mode GUIDE

displays satellite or cable

on-screen program guide.

(INFO) displays/selects on-

screen channel information, etc.

MENU displays the Menu on the

TV and other devices. Use the

SHIFT button to access

this feature.

NUMBERS Enter numbers for

direct channel selection.

RECORD, PLAY,

STOP, REW (rewind),

FF (fast forward), PAUSE

ON•OFF Turns

the device on

or off.

MUTE Turns off the TV sound

while the picture remains.

In SHIFT mode OK selects

menu items for the device

you are controlling.

TV, CBL/SAT,

DVD/VCR

Selects the device

to control.

Red Indicator

lights when

any button is

pressed.

Button Functions

DOT: Used to select digital

channels,forexample:4.1,9.2

VOLUME UP/DOWN

Changes the volume

level of the device,

normally the TV.

CHANNEL Up/Down

Changes the channels.

In SHIFT mode, these

buttons navigate on-

screen cursors and

are used to make

selections.

Button Functions, cont.

SETUP button is used to

program the remote.

SHIFT is the alternate

function of this button.

Use the SHIFT button

to access the Menu and

Navigation functions of your

device. To enter the SHIFT

mode press this button once.

Toexittheshiftmode,press

the SHIFT button again.

In SHIFT mode EXIT exitson-

screen menus and/or return to

previous on-screen selection.

(PREV. CH) Returns to the

previously selected channel.

ENTER

For some TV models, used after

direct channel number entry

to immediately change to the

selected channel.

Programming Your Remote

Your GE universal remote control is designed to

control up to 4 different audio/video devices such as

TV, DVD, VCR, satellite, cable and audio using only one

remote. To use this remote, you will need to program

it to control the devices of your choice. There are two

ways to program the remote - direct code entry or

auto code search.

Direct Code Entry (Recommended)

1. Locate the Code List provided with this

manual. Find the DEVICE CATEGORY

youwishtoprogram(forexampleTV,

DVD, CBL) and then ﬁnd the BRAND of

that device. Circle all the codes under

thatbrand.Example:ForaGETV,

locate the TV code section then circle

all of the GE TV codes.

2. Manually turn on the device you wish

to control.

3. Press and hold the SETUP button

until the red indicator light stays on

(approximately2seconds)andthen

release the SETUP button.

4. Press and release the desired device

button on the remote (TV, DVD, CBL).

The red indicator will blink once and

then remain on.

5. Enter the ﬁrst 4-digit code previously

found in the code list using the number

buttons on the remote. If the code

entered is a valid code, the red

indicator light will turn off. If the code

entered is not a valid code, the red

indicator light will ﬂash and remain on

allowing you to re-enter the code.

Note: If no buttons are pressed for 35

seconds, the remote will exit the SETUP

mode and you will have to start over.

6. Point the remote at the device. Press

the POWER button—if the device turns

off, no further programming is required

Programming Your Remote

for that device. If the device does not

turn off, repeat steps 3-6 and use

thenextcodefoundinthecodelist.

Continue this process until a code for

your device is found.

7. Repeat this process for each device

(forexampleTV, DVD, CBL) in your

home entertainment system you wish

to control.

Programming Notes

• Ifyourdevicedoesnotrespondtotheremoteafter

trying all codes listed or your brand is not listed in

the code list, use the Auto Code Search method to

program your remote.

• Sometimestherstcodethat“works”withyour

device may operate only a few functions of your

device. There may be another code in the code list

that controls more functions. Try other codes from

the code list for more functionality.

• Youcanuseanydevicebuttontocontrolother

devices in your home entertainment system. For

example,youcanusetheCBL device button to

control an audio receiver or a DVD, VCR, satellite,

etc.

• Forcombinationdevices,youmayhavetoentera

codeforeachdevice.Forexample,foraVCR/DVD

device, you may have to enter a code for the DVD

under the DVD button and enter a code for the

VCR using a different device button on the remote.

• Writedownthecodefoundtooperateyourdevice

for future reference.

Programming Your Remote

Auto Code Search

The Auto Code Search, searches automatically through

all of the codes stored in this remote. Read all the

following steps prior to starting the auto code search

as you will need to be prepared to lock-in the proper

code when found.

1. Manually turn on the device you wish

to control.

2. Press and hold the SETUP button

until the red indicator light stays on

(approximately2seconds)andthen

release the button.

3. Press and release the desired device

button on the remote (TV, DVD, CBL).

The red indicator will blink once and

then remain on.

4. Point the remote at the device and press

and release the POWER button (for TV)

or PLAY button (for DVD, VCR, etc.) to

start the search. The red indicator will

ash(approximatelyevery2seconds)as

the remote searches. Note: The remote

must be pointed at the device for the

duration of this search.

5. Place your ﬁnger on the #1 button so

you are prepared to lock-in the code.

6. Whenthedeviceshutsofforbegins

playing, press the #1 button to lock-in

the code. The red indicator light will

turn off. Note: You have approximately

two seconds after the device shuts off or

begins playing to lock-in the code.

Programming Your Remote

7. Point the remote at the device and check to see

if the remote operates the device as desired. If it

does, no further programming is required for that

device. If it does not, return to step 2 and start the

auto search again.

8. Repeatthisprocessforeachdevice(forexample

TV, DVD, CBL) in your home entertainment system

you wish to control.

Programming Notes

• Thisprocessmaytakeseveralminutesasthe

remote contains many codes.

• WhenusingtheAudioCodeSearchprogramming

method, the device you want to control must be

selected(forexample,theTV device button must

be selected in step 3 if you want to control a TV,

the DVD device button for a DVD player, etc.)

• TheSETUP button can be used during the search

process to reverse the direction of the search of

theremotecodes.Forexample,ifyoumissthe

code for your device and the remote is continuing

to search (as indicated by the blinking red light),

press the SETUP button and the code search will

reverse direction and return to the code.

• Sometimestherstcodethat“works”withyour

device may operate only a few functions of your

device. There may be another code in the code list

that controls more functions. Continue the code

search as directed above until the best code is

found.

Using Your Remote

For MENU, press and release

SHIFT/SETUP then INFO/MENU.

For OK, press and release

SHIFT/SETUP then MUTE/OK.

For EXIT, press and release

SHIFT/SETUP then LAST/EXIT.

SPECIAL NOTE: Remote will stay in shift mode until the SHIFT

button is pressed again, or until 10 seconds of inactivity. The red

indicator light will blink when the remote is in shift mode.

Using SHIFT for Menu and Navigation

The SHIFT button allows access to more than one

function for certain buttons.

Use the SHIFT/SETUP button prior to accessing

the MENU, OK, EXIT and Navigation functions,

forexample:

Controlling Combo Devices

Some Combo devices (e.g. TV/VCR, TV/DVD, DVD/

VCR, etc.) will require you to set up two different Mode

buttons to control both parts of the Combo device.

Forexample,ifyouhaveaTV/DVDCombo,youmight

need to set up one code under the TV button to

control the TV part AND a separate code (under any

other Mode button) to control the DVD part.

For Up, Down, Left or Right Navigation,

press and release SHIFT/SETUP

followed by the respective Channel or

Volume button.

Autres manuels pour 24991

Table des matières

Langues :

Manuels Télécommande universelle populaires d'autres marques

Pronto

Pronto Peel Manuel utilisateur

Radio Shack

Radio Shack Wireless Remote Control System Manuel utilisateur

AUVIO

AUVIO Universal Home Theater Remote Manuel utilisateur

Philips

Philips Icon SRU4106 Manuel utilisateur

THOMSON

THOMSON ROC4309 Manuel utilisateur

Philips

Philips pm625S Manuel utilisateur

RCA

RCA RCU600WMS - Universal Remote Control Manuel utilisateur

Blackweb

Blackweb BWB17AV002 Manuel utilisateur

Marmitek

Marmitek DoorGuard 300 Manuel utilisateur

Chunghop

Chunghop RM-L618 Manuel utilisateur

Anderic

Anderic KTN828 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Manuel utilisateur

Medion

Medion E74023 Manuel utilisateur

intensity

intensity RM02A Manuel utilisateur

Sky

Sky MY Manuel utilisateur

RCA

RCA RCU600M - Universal Remote Control Manuel utilisateur

Savant

Savant SUR-0500 Guide de référence rapide

GDI

GDI GDI-WT2K Manuel utilisateur
