Universal

Remote Control

INSTRUCTION

MANUAL

RM24927 & RM94927

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 1

Thank you for purchasing the GE Universal

Remote Control. This product is designed to

provide years of service operating a wide

variety of video and audio equipment.

Please retain this guide for future reference.

Table of Contents

Install the Batteries 1

Button Description 2-4

Programming for TV 5

Programming for VCR 6

Programming For DVD 7

Programming For DBS System 8

Programming For Cable 9

Programming For Audio 10

Programming For Second Device 11

Operating Audio Function 12-13

Sleep Functions 14

Programming With Code Search 15

Identifying Codes For Your Remote 17

Warranty 18

Lost Codes 18

This Universal Remote Control is already

programmed for most GE, RCA and ProScan

TVs, VCRs, DBS Systems, DVD Players, and

Audio/Video Receivers.

NOTE: For users of GE, RCA and ProScan

DBS Products, older DBS models require that

the DISPLAY Button on this remote be used

to make program selections. Use the SELECT

Button for making program selections on

newer GE, RCA and ProScan DBS models.

Battery Installation

Your Universal Remote Control requires 2 AAA

alkaline batteries.

To install the batteries:

1. Turn the remote over and push down on the

cover and slide it off.

2. Insert the batteries, matching the batteries to the

(+) mark inside the battery case.

3. Slide the battery cover back into place.

NOTE: Programmed codes will remain in memory

for a short period of time allowing for battery

replacement. If batteries have been dead for a pro-

longed period of time, reprogramming may be

required.

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 2

Button Description

INDICATOR LIGHT

The Indicator Light flashes to show that the

remote is working.

ON•OFF

The ON•OFF button operates the same as

your original remote.

NOTE: Some GE, RCA and ProScan models

require you to press the device button to turn

the device on and the ON•OFF button to

turn the device off.

TV, VCR, DVD, SAT, AUDIO, AUX, CBL

The TV, VCR, DVD, SAT, AUDIO-AUX, and

CBL buttons are used to select the device you

want to control.

VOL & CHAN

The VOL (Volume) and CHAN (Channel)

buttons increase or decrease the channel

numbers or volume.The CHANNEL buttons

also control the SKIP functions for DVD and

CD Player.

MUTE

Mutes volume on the TV.

PREV CHAN

The PREV CHAN button allows you to go to

the previous channel you selected. Operates

the same as Last Channel, Go Back or Recall

on your original remote.

CODE SEARCH

Used to program the remote or to search

through codes.

GUIDE

Brings up the on-screen TV program guide if

your TV has that feature.

DISP

Display Button shows the date and the time

if your TV or VCR has that feature.

NAVIGATION BUTTONS & SELECT

Used to move through on-screen menuing

and guides. With some DBS models the DISP

button should be used to select the highlight-

ed item. Use the navigation buttons to move

the highlighted choice up, down, left or right.

MENU•PROG

Brings up the Main Menu. If you already in

the menu system, press SELECT to select a

highlighted choice. Use the arrows buttons to

move through the Menu Selection.

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 3

CLEAR

Removes the on screen display to return to

normal viewing.

0-9

The number buttons operates the same as on

your original remote, and are used for enter-

ing device codes.

ENTER

The ENTER button is used to complete chan-

nel selection for some brands of TV. It is also

used to complete the code entry process.

TV/VCR

The TV/VCR button operates the TV/VCR

function of your TV.

REW, PLAY, FF, REC, STOP, PAUSE

These buttons operate the same as on your

original VCR or remote. You must press the

REC button twice to begin recording. The

REW and FF buttons also control the Reverse

and Forward functions for DVD and CD

Player.

PIP, SWAP & INPUT

PIP (Picture-in-Picture) and SWAP operate

your television’s Picture-in-Picture features.

INPUT selects the video input of your TV if

equipped with this feature.

SLEEP

The SLEEP button allows you to set a time

for you to turn off your TV automatically.

Button Description For Audio

Operation

Press AUDIO device button to enable the

AUDIO MODE Audio functions indicated by

pink descriptions

LEVEL+/LEVEL-

Sets the level of the speakers during test tone

mode.

DSP ON•OFF

Enables the receiver’s Digital Sound

Processing Mode.

DSP MODE

When the DSP mode is enabled, pressing this

button allows the user to toggle through the

various DSP modes.

CD, TAPE, TUNER, TV, VIDEO

The CD, TAPE, TUNER, TV and VIDEO but-

tons are used to directly select the device you

want to control. (Works in AUDIO mode).

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 4

AM•FM

The AM•FM button allows you to select the

AM•FM band on your audio receiver.

FUNCTION

Toggles the different audio input devices. The

number buttons also select the function

labeled below the buttons when in AUDIO

mode.

DELAY-, ON, DELAY+

Increases or decreases the delay between the

surround and main speakers when the receiv-

er is in the surround sound mode.

ON•OFF, SURR. MODE

ON•OFF SURR.

toggles the sur-

round modes on

and off. SURR

MODE toggles

through the

receiver’s various

surround sound

mode settings.

FRONT,

CENTER, REAR,

TEST

Adjust the levels

of the front, cen-

ter, and rear

speakers respec-

tively. The test

tone must be

enabled first by

pressing the TEST

button.

PRESET

Used to operate

preset channels

while in the

AUDIO mode.

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 5

Programming For TV

Most GE, RCA and ProScan TVs will not

require programming. Check to see if your

TV responds to the remote before you begin

programming.

1. Manually turn on the TV. Find the three

digit code for your TV in the code list

below.

2. Press and hold the

CODE SEARCH but-

ton

until the INDICATOR

LIGHT lights, then

release the CODE

SEARCH button.

3. Press and release

the TV button (The

INDICATOR LIGHT

will blink then

remain lit.

4. Enter the code

using the Number

Buttons. After your

code is entered, the

INDICATOR LIGHT

will turn off. If the

code is not valid, the

INDICATOR LIGHT

will blink. Check the

code list and repeat

process.

5. Aim the remote at

your TV and press the

ON•OFF button. Your

TV should turn off.

NOTE: If your TV does not respond, try all

the codes for your brand. If the codes do not

work, or your brand is not listed, try the

Code Search method.

6. With your TV on, press CHAN+

(CHANNEL UP). If the TV responds, no

further programming is required.

7. Enter your code here for easy reference.

TV CODE

CHAN +

ON•OFF

123

456

789

(OFF)

(BLINK)

INDICATOR

LIGHT

SETUP

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 6

Programming For VCR

Most GE, RCA and ProScan VCRs will not

require programming. Check to see if your

VCR responds to the remote before you

begin programming.

1. Manually turn on the VCR. Find the

three digit code for your VCR in the code list

below.

2. Press and hold the

CODE SEARCH button

until the INDICATOR

LIGHT lights, then

release the CODE

SEARCH button.

3. Press and release the

VCR button (The INDI-

CATOR LIGHT will

blink then remain lit.

4. Enter the code using

the Number Buttons.

After your code is

entered, the INDICA-

TOR

LIGHT will turn off. If

the code is not valid, the

INDICATOR LIGHT

will blink. Check the

code list and repeat

process.

5. Aim the remote at

your VCR and press the

ON•OFF button. Your

VCR should turn off.

NOTE: If your VCR does not respond, try all

the codes for your brand. If the codes do not

work, or your brand is not listed, try the

Code Search method.

6. With your VCR on, press CHAN+

(CHANNEL UP). If the VCR responds, no

further programming is required.

7. Enter your code here for easy reference.

VCR CODE

CHAN +

ON•OFF

123

456

789

(OFF)

(BLINK)

INDICATOR

LIGHT

VCR

SETUP

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 7

Programming For DVD

Most GE, RCA and ProScan DVD systems

will not require programming. Check to see

if your DVD system responds to the remote

before you begin programming.

1. Manually turn on the DVD system. Find

the three digit code for your DVD system in

the code list below.

2. Press and hold the

CODE SEARCH button

until the INDICATOR

LIGHT lights, then

release the CODE

SEARCH button.

3. Press and release the

DVD button (The INDI-

CATOR LIGHT will

blink then remain lit.

4. Enter the code using

the Number Buttons.

After your code is

entered, the INDICA-

TOR

LIGHT will turn off. If

the code is not valid, the

INDICATOR LIGHT

will blink. Check the

code list and repeat

process.

5. Aim the remote at

your DVD system and

press the ON•OFF but-

ton. Your DVD system

should turn off.

6. If the DVD System responds, no further

programming is required.

NOTE: If your DVD does not respond, try

all the codes for your brand. If the codes do

not work, or your brand is not listed, try the

Code Search method.

7. Enter your code here for easy reference.

CODE LIST

DVD CODE

ON•OFF

123

456

789

(OFF)

(BLINK)

INDICATOR

LIGHT

DVD

CODE

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 8

Programming For DBS Satellite System

Most GE, RCA and ProScan Satellite sys-

tems will not require programming. Check

to see if your DBS Satellite system responds

to the remote before you begin program-

ming.

1. Manually turn on the DBS system. Find

the three digit code for your DBS

system in the code list below.

2. Press and hold the

CODE SEARCH button

until the INDICATOR

LIGHT lights, then

release the CODE

SEARCH button.

3. Press and release the

DBS button (The INDI-

CATOR LIGHT will

blink then

remain lit.

4. Enter the code using

the Number Buttons.

After your code is

entered, the INDICA-

TOR LIGHT will turn

off. If the code is not

valid, the INDICATOR

LIGHT will blink.

Check the code list and

repeat process.

5. Aim the remote at

your DBS system and

press the

ON•OFF button. Your

DBS system should turn

off.

6. With your DBS System on, press

CHAN+ (CHANNEL UP). If the satellite

system responds, no further programming

is required.

NOTE: If your DBS system does not

respond, try all the codes for your brand. If

the codes do not work, or your brand is not

listed, try the Code Search method.

7. Enter your code here for easy reference.

SATELLITE CODE

CHAN +

ON•OFF

123

456

789

(OFF)

(BLINK)

INDICATOR

LIGHT

SAT

CODE

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 9

Programming For Cable

1. Manually turn on the Cable Box.

Find the three digit code for your Cable Box

in the code list below.

2. Press and hold the

CODE SEARCH but-

ton until the INDICA-

TOR LIGHT lights,

then release the CODE

SEARCH button.

3. Press and release

the CBL button (The

INDICATOR LIGHT

will blink then

remain lit.

4. Enter the code

using the Number

Buttons. After your

code is entered, the

INDICATOR LIGHT

will turn off. If the

code is not valid, the

INDICATOR LIGHT

will blink. Check the

code list and repeat

process.

5. Aim the remote at

your CABLE and press

the ON•OFF button.

Your CABLE should

turn off.

6. With your Cable Box on, press CHAN+

(CHANNEL UP). If the Cable Box responds,

no further programming is required.

NOTE: If your Cable Box does not respond,

try all the codes for your brand. If the codes

do not work, or your brand is not listed, try

the Code Search method.

7. Enter your code here for easy reference.

CABLE BOX CODE

LIST

CABLE BOX CODE

CHAN +

ON•OFF

123

456

789

(OFF)

(BLINK)

INDICATOR

LIGHT

CABLE

CODE

24927 Revised Size 7" x 2 3/4" 8/19/03 9:10 AM Page 10

Autres manuels pour RM24927

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Manuels Télécommande universelle populaires d'autres marques

Pronto

Pronto Peel Manuel utilisateur

Radio Shack

Radio Shack Wireless Remote Control System Manuel utilisateur

AUVIO

AUVIO Universal Home Theater Remote Manuel utilisateur

Philips

Philips Icon SRU4106 Manuel utilisateur

THOMSON

THOMSON ROC4309 Manuel utilisateur

Philips

Philips pm625S Manuel utilisateur

RCA

RCA RCU600WMS - Universal Remote Control Manuel utilisateur

Blackweb

Blackweb BWB17AV002 Manuel utilisateur

Marmitek

Marmitek DoorGuard 300 Manuel utilisateur

Chunghop

Chunghop RM-L618 Manuel utilisateur

Anderic

Anderic KTN828 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Manuel utilisateur

Medion

Medion E74023 Manuel utilisateur

intensity

intensity RM02A Manuel utilisateur

Sky

Sky MY Manuel utilisateur

RCA

RCA RCU600M - Universal Remote Control Manuel utilisateur

Savant

Savant SUR-0500 Guide de référence rapide

GDI

GDI GDI-WT2K Manuel utilisateur
