Universal Remote

Instruction Manual

29519

25040

7252

Congratulations on your purchase of the GE Universal

Remote. This remote is capable of operating

thousands of audio/video devices including TVs, DVD

players, cable, satellite receivers and more!

IMPORTANT:

SAVE THIS MANUAL AND CODE LIST FOR FUTURE

REFERENCE

Introduction..................................................................................... 2

Setup .................................................................................................. 3

Button Functions .......................................................................... 4

Programming Your Remote..................................................... 6

Direct Code Entry................................................................... 6

Auto Code Search ................................................................. 8

Master Volume Feature...........................................................10

Troubleshooting..........................................................................12

FCC Statement.............................................................................14

Table of Contents

Scan this to view remote

setup video

Mira a ver el video de

instalación remota

http://www.jascoproducts.com/remote

Techinical Support Group

1-800-654-8483 from 7:30 am - 5:00 pm CST

Your universal remote requires two (2) AAA

batteries (not included). Alkaline batteries are

recommend.

To Install the Batteries:

1. Remove the battery compartment cover by sliding

the cover down.

2. Match the (+) and (-) marks on the batteries to the

(+) and (-) marks inside the battery compartment,

then insert two (2) AAA Alkaline batteries. Be sure

to use fresh batteries.

3. Slide the battery compartment cover back

into place.

Note: If your remote stops operating properly, replace

the batteries with new ones. The remote will retain

the codes you have programmed for up to 10 minutes

after the batteries are removed.

Battery Precautions:

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc), or

rechargeable (Ni-Cd, Ni-MH, etc.) batteries.

• Always remove old, weak or worn-out batteries

promptly and recycle or dispose of them in

accordance with local and national regulations.

• Remove batteries if product is to be unused for an

extended period of time.

Battery Saver

Your remote automatically turns off if the buttons are

depressed more than 8 seconds. This will save your

batteries should your remote get stuck in a place

where the buttons remain depressed (e.g., between

the sofa cushions).

Code Saver

You will have up to 10 minutes to change the

batteries in your remote without losing codes you

have programmed. However, do not press any

buttons until batteries are installed in the remote. If

buttons are pressed without batteries in the remote,

all codes will be lost.

Setup

NUMBERS Enter

numbers for direct

channel selection.

(rewind), (PLAY),

(PAUSE), (fast

forward)

VOLUME UP/DOWN

Changes the volume

level of the device,

normally the TV.

ON•OFF Turns the

device on or off.

MUTE Turns off the TV

sound while the picture

remains.

TV, CBL, DVD

Selects the device

to control.

Button Functions

DOT (•) Used

to select digital

channels, e.g., 2.3.

Button Functions, cont.

(PREV. CH)

Returns to the

previously selected

channel.

SETUP Used to

setup the remote,

and for code search

function.

INPUT Selects the

video inputs from avail-

able viewing sources.

CHANNEL Up/

Down Changes the

channels.

ENTER

For some TV models, used

after direct channel number

entry to immediately change

to the selected channel.

Programming Your Remote

Your GE universal remote control is designed to

control up to 3 different audio/video devices such

as TV, DVD, VCR, satellite and cable using only one

remote. To use this remote, you will need to program

it to control the devices of your choice. There are two

ways to program the remote - direct code entry or

auto code search.

Direct Code Entry (Recommended)

1. Locate the Code List provided with this

manual. Find the DEVICE CATEGORY

you wish to program (for example TV,

DVD, CBL) and then ﬁnd the BRAND of

that device. Circle all the codes under

that brand. Example: For a GE TV,

locate the TV code section then circle

all of the GE TV codes.

2. Manually turn on the device you wish

to control.

3. Press and hold the SETUP button

until the red indicator light stays on

(approximately 2 seconds) and then

release the SETUP button.

4. Press and release the desired device

button on the remote (TV, DVD, CBL).

The red indicator will blink once and

then remain on.

5. Enter the ﬁrst 4-digit code previously

found in the code list using the

number buttons on the remote. If the

code entered is a valid code, the red

indicator light will turn off. If the code

entered is not a valid code, the red

indicator light will ﬂash and remain on

allowing you to re-enter the code.

Note: If no buttons are pressed for 35

seconds, the remote will exit the SETUP

mode and you will have to start over.

6. Point the remote at the device. Press

the POWER button—if the device turns

off and is fully functional, no further

Programming Your Remote

programming is required for that

device. If the device does not turn off,

or is not fully functional repeat steps

3-6 and use the next code found in

the code list. Continue this process

until a code for your device is found.

7. Repeat this process for each device

(for example TV, DVD, CBL) in your

home entertainment system you wish

to control.

Programming Notes

• If your device does not respond to the remote after

trying all codes listed or your brand is not listed in

the code list, use the Auto Code Search method to

program your remote.

• Sometimes the ﬁrst code that “works” with your

device may operate only a few functions of your

device. There may be another code in the code list

that controls more functions. Try other codes from

the code list for more functionality.

• You can use any device button to control other

devices in your home entertainment system. For

example, you can use the CBL device button to

control an audio receiver or a DVD, VCR, satellite,

etc.

• For combination devices, you may have to enter a

code for each device. For example, for a VCR/DVD

device, you may have to enter a code for the DVD

under the DVD button and enter a code for the

VCR using a different device button on the remote.

• Write down the code found to operate your device

for future reference.

Programming Your Remote

Auto Code Search

The Auto Code Search, searches automatically through

all of the codes stored in this remote. Read all the

following steps prior to starting the auto code search

as you will need to be prepared to lock-in the proper

code when found.

1. Manually turn on the device you wish

to control.

2. Press and hold the SETUP button

until the red indicator light stays on

(approximately 2 seconds) and then

release the button.

3. Press and release the desired device

button on the remote (TV, DVD, CBL).

The red indicator will blink once and

then remain on.

4. Point the remote at the device and press

and release the POWER button (for TV)

or PLAY button (for DVD, VCR, etc.) to

start the search. The red indicator will

ﬂash (approximately every 2 seconds) as

the remote searches. Note: The remote

must be pointed at the device for the

duration of this search.

5. Place your ﬁnger on the #1 button so

you are prepared to lock-in the code.

6. When the device shuts off or begins

playing, press the #1 button to lock-in

the code. The red indicator light will

turn off. Note: You have approximately

two seconds after the device shuts off or

begins playing to lock-in the code.

Programming Your Remote

7. Point the remote at the device and check to see

if the remote operates the device as desired. If it

does, no further programming is required for that

device. If it does not, return to step 2 and start the

auto search again.

8. Repeat this process for each device (for example

TV, DVD, CBL) in your home entertainment system

you wish to control.

Programming Notes

• This process may take several minutes as the

remote contains many codes.

• When using the Audio Code Search programming

method, the device you want to control must be

selected (for example, the TV device button must

be selected in step 3 if you want to control a TV,

the DVD device button for a DVD player, etc.)

• The SETUP button can be used during the search

process to reverse the direction of the search of

the remote codes. For example, if you miss the

code for your device and the remote is continuing

to search (as indicated by the blinking red light),

press the SETUP button and the code search will

reverse direction and return to the code.

• Sometimes the ﬁrst code that “works” with your

device may operate only a few functions of your

device. There may be another code in the code list

that controls more functions. Continue the code

search as directed above until the best code is

found.

Master Volume Feature

The Master Volume Feature allows you to select a

single device (TV, cable box or audio receiver) that

the volume control always controls. For example, the

remote can be in TV mode while the volume buttons

control the volume on your cable box instead

of your TV.

Enabling the Master Volume Feature

1. Press and hold the SETUP button

until the red indicator stays on

(approximately 2 seconds) and then

release the button.

2. Press and release desired device

button (TV, DVD, CBL) for the device

you wish to control the volume.

3. Press and release the

MUTE button.

4. Press and release the VOL + button.

The red indicator will blink twice and

then go off.

To test the feature put the remote in

another mode such as the TV mode if

you programmed the cable box to be the

Master Volume Device. Point the remote

at the cable box, press and hold either

the VOL + or the VOL - button. If the cable

box volume changes then the remote is

programmed correctly. If the TV volume

changes and not the cable box, you will

have to repeat the steps above and test

again.

Disabling the Master Volume Feature

1. Press and hold the SETUP button

until the red indicator stays on

(approximately 2 seconds) and then

release the button.

2. Press and release the device button

(TV, DVD, CBL) which is programmed

to control the Master Volume Feature.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Manuels Télécommande universelle populaires d'autres marques

Pronto

Pronto Peel Manuel utilisateur

Radio Shack

Radio Shack Wireless Remote Control System Manuel utilisateur

AUVIO

AUVIO Universal Home Theater Remote Manuel utilisateur

Philips

Philips Icon SRU4106 Manuel utilisateur

THOMSON

THOMSON ROC4309 Manuel utilisateur

Philips

Philips pm625S Manuel utilisateur

RCA

RCA RCU600WMS - Universal Remote Control Manuel utilisateur

Blackweb

Blackweb BWB17AV002 Manuel utilisateur

Marmitek

Marmitek DoorGuard 300 Manuel utilisateur

Chunghop

Chunghop RM-L618 Manuel utilisateur

Anderic

Anderic KTN828 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Manuel utilisateur

Medion

Medion E74023 Manuel utilisateur

intensity

intensity RM02A Manuel utilisateur

Sky

Sky MY Manuel utilisateur

RCA

RCA RCU600M - Universal Remote Control Manuel utilisateur

Savant

Savant SUR-0500 Guide de référence rapide

GDI

GDI GDI-WT2K Manuel utilisateur
