FUJITSU Storage

ETERNUS DX

Configuration Guide -Server Connection-

(Fibre Channel) ETERNUS DX60/DX60 S2, DX80, DX90 Disk Storage System

Settings

P3AM-3182-15ENZ0

This page is intentionally left blank.

Preface

This manual briefly explains the operations that need to be performed by the user in order to connect an

ETERNUS DX to a server running Solaris OS, HP-UX, AIX, Windows®, Linux, VMware ESX, Egenera BladeFrame,

Citrix® XenServer®, Oracle Linux, or Oracle VM Server via a Fibre Channel interface.

This manual should be used in conjunction with any other applicable user manuals, such as those for the

ETERNUS DX, server, OS, Fibre Channel Card, Converged Network Adapter cards, and drivers.

Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Notations" for the notations

used in this manual such as product trademarks and product names. For storage systems that are supported

by the OS, refer to the Server Support Matrix of the ETERNUS DX.

15th Edition

June 2015

The Contents and Structure of this Manual

This manual is composed of the following two chapters.

•"Chapter 1 Workflow" (page 6)

This chapter describes the workflow when setting up an ETERNUS DX.

•"Chapter 2 Setting Up the ETERNUS DX" (page 8)

This chapter describes how to set up an ETERNUS DX.

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

Table of Contents

Chapter 1 Workflow 6

Chapter 2 Setting Up the ETERNUS DX 8

2.1 Common Settings ........................................................................................................................... 8

2.1.1 Setting the To-server Connection Type (Setting the FC Port Parameters) ..............................................................8

2.1.2 Sense Data Conversion (Setting the Host Responses)...........................................................................................9

2.1.3 Registering the WWNs of the Accessing Fibre Channel Cards or Converged Network Adapter Cards (Setting FC

Host).....................................................................................................................................................................11

2.1.4 Creating and Allocating LUN Groups (Setting Host Affinity Groups) ....................................................................12

2.2 Specific Settings ........................................................................................................................... 13

2.2.1 Setting the Reset Groups.....................................................................................................................................13

2.2.2 Setting the Subsystem Parameters (for HP-UX only)...........................................................................................14

2.3 Checking the WWNs ..................................................................................................................... 14

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

List of Tables

Table 2.1 FC port parameter settings (FC-AL connection) ..........................................................................................8

Table 2.2 Transfer rate setting values........................................................................................................................8

Table 2.3 FC port parameter settings (Fabric connection) .........................................................................................9

Table 2.4 Transfer rate setting values........................................................................................................................9

Table 2.5 Host response settings .............................................................................................................................10

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

Chapter 1

Workflow

This manual is used when performing the setup procedures described in the "Setting Up the ETERNUS DX"

section of the "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel)" for

each OS.

Required Documents

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel

Switch Settings"

•"Converged Enhanced Ethernet Administrator's Guide"

•"Fabric OS Administrator's Guide"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris"

•"ETERNUS Web GUI User's Guide"

Workflow

Setting the FC Port Parameters

Set the to-server connection type.

•"2.1.1 Setting the To-server Connection Type (Setting the FC Port Parameters)" (page 8)

Setting the Host Responses

Set the host responses to match the connection configuration.

•"2.1.2 Sense Data Conversion (Setting the Host Responses)" (page 9)

Setting the FC Host

•"2.1.3 Registering the WWNs of the Accessing Fibre Channel Cards or Converged Network Adapter

Cards (Setting FC Host)" (page 11)

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

Setting the Affinity Groups

Set the server accessible LUN groups.

•"2.1.4 Creating and Allocating LUN Groups (Setting Host Affinity Groups)" (page 12)

Setting the Host Affinity

Define the relationship between the registered Host Affinity and the FC host.

•"2.1.4 Creating and Allocating LUN Groups (Setting Host Affinity Groups)" (page 12)

Setting the Reset Groups

Assign the ports of the ETERNUS DX to the same reset group, depending on the connection conditions.

•"2.2.1 Setting the Reset Groups" (page 13)

Setting the Subsystem Parameters (for HP-UX only)

Set whether to enable [Disable Load Balance], a function that restricts retry-required sense responses

when the ETERNUS DX is in overload.

•"2.2.2 Setting the Subsystem Parameters (for HP-UX only)" (page 14)

Checking the WWNs

Check information that is necessary for connecting to the server.

•"2.3 Checking the WWNs" (page 14)

After completing all the required procedures in this manual, follow the procedures in "FUJITSU Storage

ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel)" for each OS.

Chapter 1 Workflow

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

Chapter 2

Setting Up the ETERNUS DX

2.1 Common Settings

This section explains the settings required for all server OSs, regardless of the connection configuration.

See the "ETERNUS Web GUI User's Guide" for details of how to set up and operate ETERNUS Web GUI.

2.1.1 Setting the To-server Connection Type (Setting the FC Port Parameters)

For each connection configuration, set the indicated items only. Retain the default values for all of the pa-

rameters that are not described below.

Table 2.1 FC port parameter settings (FC-AL connection)

Parameter Solaris OS

HP-UX, AIX, Windows®, Linux, VMware

ESX, PAN Manager, Citrix XenServer,

Oracle Linux, Oracle VM Server

Connection FC-AL

Set Loop ID Manual

Loop ID (*1) Values from 0x10 upwards (except

0x7D)

0x00

Frame Size 2048 bytes (Default value)

Transfer Rate See the table below (*2)

Host Affinity Enable

Reset Scope I_T_L (Default value)

Release Reservation if Chip is Reset Disable (Default value)

*1: Assign Loop IDs that are unique within each Loop, in ascending order.

*2: Set the appropriate value from the following table. Do not use [Auto].

Table 2.2 Transfer rate setting values

Fibre Channel card maximum speed Transfer rate setting value

8Gbit/s CA 4Gbit/s CA

8Gbit/s 8Gbit/s 4Gbit/s

4Gbit/s 4Gbit/s 4Gbit/s

2Gbit/s 2Gbit/s 2Gbit/s

1Gbit/s — 1Gbit/s

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

Table 2.3 FC port parameter settings (Fabric connection)

Parameter Setting value

Connection Fabric

Frame Size 2048 bytes (Default value)

Transfer Rate See the table below (*1)

Host Affinity Enable

Reset Scope I_T_L (Default value)

Release Reservation if Chip is Reset Disable (Default value)

*1: Set the appropriate value from the following table. Do not use [Auto].

Table 2.4 Transfer rate setting values

Fibre Channel switch or CEE/FCoE

switch maximum speed

Transfer rate setting value

8Gbit/s CA 4Gbit/s CA

8Gbit/s 8Gbit/s 4Gbit/s

4Gbit/s 4Gbit/s 4Gbit/s

2Gbit/s 2Gbit/s 2Gbit/s

1Gbit/s — 1Gbit/s

When setting a Fabric connection, complete the preparatory work and set up the Fibre Channel switch or

the CEE/FCoE switch beforehand. For setting details, refer to "FUJITSU Storage ETERNUS DX Configuration

Guide -Server Connection- (Fibre Channel) Fibre Channel Switch Settings", "Converged Enhanced Ethernet

Administrator's Guide", or "Fabric OS Administrator's Guide".

2.1.2 Sense Data Conversion (Setting the Host Responses)

The ETERNUS DX sense data conversion must be set to match the way in which the server will process the

ETERNUS DX request responses.

Set the parameters according to the conditions that are described in Table 2.5.

Retain the default values for all of the parameters that are not described below. If multiple conditions apply,

set the parameters so that all of these conditions are met.

When setting the access path using the ETERNUS SF Storage Cruiser, the host responses for FC host will be

set to default values. Set the host responses after setting the access path using the ETERNUS SF Storage

Cruiser.

Chapter 2 Setting Up the ETERNUS DX

2.1 Common Settings

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

Table 2.5 Host response settings

OS Conditions Parameter Setting value

Solaris (*1) When MPxIO is used and the Multi-

path Diagnostic Program or En-

hanced Support Facility 5.1 or later

is installed

Reservation Conflict Response for

Test Unit Ready

Conflict

Sense Data Conversion MPxIO Recommended

When MPxIO is used for purposes

other than described above

Reservation Conflict Response for

Test Unit Ready

Conflict

Sense Data Conversion Linux Recommended

(When not using

GRMPD)

When the ETERNUS Multipath Driver

or VxVM is used

All parameters Default value

HP-UX Common (required setting) Host Specific Mode HP-UX Mode

When Integrity VM is used Sense Data Conversion Linux Recommended

(When not using

GRMPD)

AIX (*2)

VIOS

Common (required setting) Host Specific Mode AIX Mode

When one of the following condi-

tions applies

•ETERNUS Multipath Driver 2.0 is

used

•When FJspio is used and PowerHA

or HACMP is used for a single path

configuration

Reservation Conflict Response for

Test Unit Ready

Conflict

Windows® (*3) When one of the following condi-

tions applies

•The OS standard multipath driver

(msdsm) is used

•VxVM is used

Sense Data Conversion Windows Recommen-

ded (When not using

GR/ETERNUS MPD or

Device Driver)

When one of the following condi-

tions applies

•SAN Boot is configured with the

PRIMEQUEST 1000 series

•SAN Boot is configured with the

PRIMEQUEST 500/400 series

Sense Data Conversion Linux Recommended

(When not using

GRMPD)

When the ETERNUS Multipath Driver

is used

All parameters Default value

When MSCS is used on Windows

Server® 2003

Reservation Conflict Response for

Test Unit Ready

Conflict

Linux When one of the following condi-

tions applies

•The OS standard multipath driver

(device mapper) is used

•VxVM is used

•SAN Boot is configured with the

PRIMEQUEST 1000 series

•SAN Boot is configured with the

PRIMEQUEST 500/400 series

Sense Data Conversion Linux Recommended

(When not using

GRMPD)

Conditions that are not listed above All parameters Default value

Chapter 2 Setting Up the ETERNUS DX

2.1 Common Settings

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-3182-15ENZ0

Autres manuels pour ETERNUS DX60

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Fujitsu Stockage

Fujitsu

Fujitsu GRANPOWER5000 Manuel utilisateur

Fujitsu

Fujitsu ETERNUS Manuel utilisateur

Fujitsu

Fujitsu ETERNUS LT260 Manuel utilisateur

Fujitsu

Fujitsu teamserver Series Manuel utilisateur

Fujitsu

Fujitsu RDX USB 3.0 QuikStor Drive Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX60 S3 Manuel utilisateur

Fujitsu

Fujitsu MHV2080AS - Extended Duty Mobile 80 GB Hard... Manuel utilisateur

Fujitsu

Fujitsu DYNAMO 640AI Manuel utilisateur

Fujitsu

Fujitsu MHY2120BH - Mobile 120 GB Hard Drive Guide de l'utilisateur

Fujitsu

Fujitsu MAU3147FC Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX100 S3 Manuel utilisateur

Fujitsu

Fujitsu MAN3184MC - Enterprise 18.4 GB Hard Drive Manuel utilisateur

Fujitsu

Fujitsu ETERNUS AF Series Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX S5 Series Manuel utilisateur

Fujitsu

Fujitsu C141-E280 Manuel utilisateur

Fujitsu

Fujitsu PG-HD9G1C Manuel utilisateur

Fujitsu

Fujitsu RE25U Manuel utilisateur

Fujitsu

Fujitsu FD-1100MT Manuel utilisateur

Fujitsu

Fujitsu MAX3036NC Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX Disk Manuel utilisateur

Fujitsu

Fujitsu MPF3XXXAT Manuel utilisateur

Fujitsu

Fujitsu MHM2100AT - Mobile 10 GB Hard Drive Manuel utilisateur

Fujitsu

Fujitsu SLR 50 GBYTE Manuel utilisateur

Fujitsu

Fujitsu ETERNUS SF Express V16.6 Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
