Fujitsu Eternus DX80 S2 Manuel utilisateur

FUJITSU Storage

ETERNUS DX

Configuration Guide -Server Connection-

(Fibre Channel) ETERNUS DX80 S2/DX90 S2,

ETERNUS DX410 S2/DX440 S2,

ETERNUS DX8100 S2/DX8700 S2 Disk Storage System Settings

P3AM-5332-15ENZ0

This page is intentionally left blank.

Preface

This manual briefly explains the operations that need to be performed by the user in order to connect an

ETERNUS DX to a server running Solaris OS, HP-UX, AIX, Windows®, Linux, VMware ESX, PAN Manager, Citrix®

XenServer®, Oracle Linux, or Oracle VM Server for x86 via a Fibre Channel interface.

This manual should be used in conjunction with any other applicable user manuals, such as those for the

ETERNUS DX, server, OS, Fibre Channel cards, and drivers.

Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Notations" for the notations

used in this manual such as product trademarks and product names. For storage systems that are supported

by the OS, refer to the Server Support Matrix of the ETERNUS DX.

15th Edition

June 2015

The Contents and Structure of this Manual

This manual is composed of the following two chapters.

•"Chapter 1 Workflow" (page 6)

This chapter describes the workflow when setting up an ETERNUS DX.

•"Chapter 2 Setting Up the ETERNUS DX" (page 8)

This chapter describes how to set up an ETERNUS DX.

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0

Table of Contents

Chapter 1 Workflow 6

Chapter 2 Setting Up the ETERNUS DX 8

2.1 Common Settings ........................................................................................................................... 8

2.1.1 Setting the To-server Connection Type (Setting the FC Port Parameters) ..............................................................8

2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups).................................................................10

2.1.3 Setting the Host Responses ................................................................................................................................10

2.1.4 Setting the Host Response for the ETERNUS DX8000 S2 series using the ETERNUS Multipath Driver...................11

2.1.5 Setting the CA Port Groups..................................................................................................................................11

2.1.6 Registering the WWNs of the Accessing Fibre Channel Cards (Setting FC Host)...................................................11

2.1.7 Allocating LUN Groups (Setting the Host Affinity)...............................................................................................12

2.2 Specific Settings ........................................................................................................................... 12

2.2.1 Setting the CA Reset Groups................................................................................................................................12

2.2.2 Setting the Subsystem Parameters .....................................................................................................................12

2.3 Checking the WWNs ..................................................................................................................... 13

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0

List of Tables

Table 2.1 FC port parameter settings (FC-AL connection) ..........................................................................................8

Table 2.2 Transfer Rate setting values (for FC-AL connection) ...................................................................................9

Table 2.3 FC port parameter settings (Fabric connection) .........................................................................................9

Table 2.4 Transfer Rate setting values (for Fabric connection) ..................................................................................9

Table 2.5 Host response settings .............................................................................................................................10

Table 2.6 Host response settings for the ETERNUS DX8000 S2 series when using the TPG Referrals function ..........11

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0

Chapter 1

Workflow

This manual is used when performing the setup procedures described in the "Setting Up the ETERNUS DX"

section of the "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel)" for

each OS.

Required Documents

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel

Switch Settings"

•"Fabric OS Administrator's Guide"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris"

•"ETERNUS Web GUI User's Guide"

Workflow

Setting the FC Port Parameters

Set the to-server connection type.

•"2.1.1 Setting the To-server Connection Type (Setting the FC Port Parameters)" (page 8)

Setting the LUN Groups

Set the server accessible LUN groups.

•"2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)" (page 10)

Setting the Host Responses

Set the host responses to match the connection configuration.

•"2.1.3 Setting the Host Responses" (page 10)

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0

Setting the CA Port Groups

Create a group of ports for each CA type.

•"2.1.5 Setting the CA Port Groups" (page 11)

Setting the FC Host

•"2.1.6 Registering the WWNs of the Accessing Fibre Channel Cards (Setting FC Host)" (page 11)

Setting the Host Affinity

Define the relationship between the FC host, the CA port group, and the LUN group.

•"2.1.7 Allocating LUN Groups (Setting the Host Affinity)" (page 12)

Setting the Specific Parameters

Set the required parameters according to the OS and the connection configuration.

•"2.2 Specific Settings" (page 12)

Checking the WWNs

Check information that is necessary for connecting to the server.

•"2.3 Checking the WWNs" (page 13)

After completing all the required procedures in this manual, follow the procedures in "FUJITSU Storage

ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel)" for each OS.

Chapter 1 Workflow

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0

Chapter 2

Setting Up the ETERNUS DX

2.1 Common Settings

This section explains the settings required for all server OSs, regardless of the connection configuration.

See the "ETERNUS Web GUI User's Guide" for details of how to set up and operate ETERNUS Web GUI.

2.1.1 Setting the To-server Connection Type (Setting the FC Port Parameters)

For each connection configuration, set the indicated items only. Retain the default values for all of the pa-

rameters that are not described below.

•Specify "Fabric connection" for connections to the Fibre Channel switches.

•Specify "FC-AL connection" for direct connections to the Fibre Channel cards. Specify "Fabric connection" for

direct connections to 16Gbit/s Fibre Channel cards (maximum transfer rate) with a transfer rate of 16Gbit/s.

Table 2.1 FC port parameter settings (FC-AL connection)

Parameter Solaris OS

HP-UX, AIX, Windows®, Linux, VMware

ESX, PAN Manager, Citrix XenServer,

Oracle Linux, Oracle VM Server for x86

Connection FC-AL

Set Loop ID Manual

Loop ID Values from 0x10 upwards

(Except 0x7D)

0x00

Transfer Rate See the table below (*1)

FC Frame Size 2048

Reset Scope I_T_L

Release Reservation if Chip is Reset Disable

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0

*1: Set the appropriate value from the following table. Do not use [Auto-negotiation].

Table 2.2 Transfer Rate setting values (for FC-AL connection)

Fibre Channel card maxi-

mum speed

Transfer rate setting value

16Gbit/s CA 8Gbit/s CA 4Gbit/s CA

16Gbit/s — 8Gbit/s 4Gbit/s

8Gbit/s 8Gbit/s 8Gbit/s 4Gbit/s

4Gbit/s 4Gbit/s 4Gbit/s 4Gbit/s

2Gbit/s — 2Gbit/s 2Gbit/s

Table 2.3 FC port parameter settings (Fabric connection)

Parameter Setting value

Connection Fabric

Transfer Rate See the table below (*1)

FC Frame Size 2048

Reset Scope I_T_L

Release Reservation if Chip is Reset Disable

*1: Set the appropriate value from the following table.

Table 2.4 Transfer Rate setting values (for Fabric connection)

Fibre Channel switch maxi-

mum speed

Transfer rate setting value

16Gbit/s CA 8Gbit/s CA 4Gbit/s CA

16Gbit/s 16Gbit/s (*1) 8Gbit/s 4Gbit/s

8Gbit/s 8Gbit/s 8Gbit/s 4Gbit/s

4Gbit/s 4Gbit/s 4Gbit/s 4Gbit/s

2Gbit/s — 2Gbit/s 2Gbit/s

*1: Specify "Auto Negotiation" for direct connections to 16Gbit/s Brocade Fibre Channel cards.

When using a Fabric connection, complete the preparatory work and set up the Fibre Channel switch be-

forehand. For setting details, refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connec-

tion- (Fibre Channel) Fibre Channel Switch Settings" or "Fabric OS Administrator's Guide".

Chapter 2 Setting Up the ETERNUS DX

2.1 Common Settings

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0

2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)

Create LUN groups for the server to access. Refer to "Connectivity Management" in "ETERNUS Web GUI User's

Guide" for details, and set the LUN groups.

Depending on the OS version, the server may not recognize the ETERNUS DX unless a LUN group is as-

signed from LUN0. In this case, assign a LUN group starting from LUN0 in ascending order.

2.1.3 Setting the Host Responses

The host response parameters for the ETERNUS DX must be set to match the way the server processes the

responses to requests from the ETERNUS DX. Setting of the host response must be done before connecting

the ETERNUS DX to the server.

Set the parameters that are described below for each OS.

Retain the default values for all of the parameters that are not described below.

•When setting the access path using the ETERNUS SF Storage Cruiser, the host responses for FC host will

be set to default values. Set the host response after setting the access path using the ETERNUS SF Stor-

age Cruiser.

•Since "Windows EMPD", "Linux EMPD", "Solaris EMPD", or "Others" cannot be selected after applying the

latest firmware, select "Default" for the Host Response setting.

Note that these items are displayed as the existing setting, but do not need to be changed.

Table 2.5 Host response settings

OS Conditions Host response selec-

tion Parameter Setting value

Solaris (*1) When all of the following con-

ditions are met

•The OS standard Multipath

Driver (MPxIO) is used

•The Multipath Diagnostic

Program (or Enhanced Sup-

port Facility 5.1 or later) is

installed

None

(Create a new host re-

sponse)

Reservation Conflict Re-

sponse for Test Unit

Ready

Conflict

Sense Data Conversion 4/*/* g 6/*/*

B/*/* g 6/*/*

When an MPxIO that is differ-

ent from the above is used

Solaris MPxIO – –

When the ETERNUS Multipath

Driver or the Symantec Stor-

age Foundation is used

Default – –

Windows®

Linux

VMware ESX

PAN Manager

Citrix XenServer

Oracle VM Server for

x86

– Default – –

HP-UX – HP-UX – –

Chapter 2 Setting Up the ETERNUS DX

2.1 Common Settings

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5332-15ENZ0
