Q57M Series Motherboard
User’s Manual
Statement:
This manual is the intellectual property of Foxconn, Inc. Although the information
in this manual may be changed or modied at any time, Foxconn does not obligate
itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
P/N: 3A2228H00-000-G
Version:
User’s Manual V1.0 for Q57M Series motherboard.
Symbol description:
Caution: refers to important information that can help you to use motherboard
better, and tells you how to avoid problems.
Warning: indicating a potential risk of hardware damage or physical injury may
exist.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could other-
wise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
More information:
If you want more information about our products, please visit Foxconn’s
website: http://www.foxconnchannel.com
CAUTION
!
W
A
R
N
I
N
G
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical motherboard for specic features.
Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard Q57M
is in conformity with
(reference to the specication under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
■ EN 55022: 1998/A2: 2003 Limits and methods of measurements of radio
disturbance characteristics of information technology
equipment
■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage uctuations and icker in low
voltage supply systems for equipment with rated current
<= 16A
■ EN 55024/A2:2003 Information technology equipment-Immunity
characteristics limits and methods of measurement
Signature : Place / Date : TAIPEI/2009
Printed Name : James Liang
Declaration of conformity
Trade Name: FOXCONN
Model Name: Q57M
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: 714-738-8868
Facsimile: 714-738-8838
Equipment Classication: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer: HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Tested to comply with FCC standards.
Signature : Date : 2009
Installation Precautions
Please carefully read the following procedures to install your computer :
■ It is suggested to select high-quality, certied fans in order to avoid damage
to the motherboard and CPU due to high temperature. Never turn on the
computer if the CPU fan is not properly installed.
■ We cannot guarantee that your system can operate normally when your
CPU is overclocked. Normal operation depends on the overclocking capac-
ity of your device.
■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or
S/PDIF cables to the internal connectors on the motherboard, make sure
their pinouts are matching with the connectors on the motherboard. Incorrect
connections might damage the motherboard.
■ When handling the motherboard, avoid touching any metal leads or connec-
tors.
■ If there is a PCI Express x16 graphics card installed in your system, we
recommend using a 24-pin ATX power supply to get the best performance.
■ Before turning on the power, please make sure the power supply AC input
voltage setting has been congured to the local standard.
■ To prevent damage to the motherboard, do not allow screws to come in contact
with the motherboard circuit or its components. Also, make sure there are no
leftover screws or metal components placed on the motherboard or within the
computer casing.
■ If you are uncertain about any installation steps or have a problem related to
the use of the product, please consult a certied computer technician.
CAUTION
!
■ Electrostatic discharge (ESD) is the sudden and momentary electric current
that ows between two objects at different electrical potentials. Normally it
comes out as a spark which will quickly damage your electronic equipment.
Please wear an electrostatic discharge (ESD) wrist strap when handling
components such as a motherboard, CPU or memory.
■ Ensure that the DC power supply is turned off before installing or removing
CPU, memory, expansion cards or other peripherals. It is recommended to
unplug the AC power cord from the power supply outlet. Failure to unplug
the power supply cord may result in serious damage to your system.
W
A
R
N
I
N
G
!
TABLE OF CONTENTS
Chapter 1 Product Introduction
Product Specications..............................................................................2
Layout.......................................................................................................4
Back Panel Connectors............................................................................5
Chapter 2 Hardware Install
Install the CPU and CPU Cooler ..............................................................8
Install the Memory ..................................................................................11
Install an Expansion Card ......................................................................13
Install other Internal Connectors ............................................................14
Jumpers..................................................................................................17
Chapter 3 BIOS Setup
Enter BIOS Setup...................................................................................20
Main Menu..............................................................................................20
Standard BIOS Faetures ........................................................................22
Advanced BIOS Features.......................................................................24
Advanced Chipset Features ...................................................................28
Boot Conguration Features ..................................................................31
Power Management Setup.....................................................................33
PnP/PCI Congurations..........................................................................35
PC Health Status....................................................................................36
BIOS Security Features..........................................................................37
Load Fail-Safe Defaults..........................................................................38
Load Optimal Defaults............................................................................38
Save & Exit Setup ..................................................................................38
Exit Without Saving ................................................................................38
Chapter 4 CD Instruction
Install driver and utility............................................................................40
FOX ONE
Main Page ........................................................................................43
CPU Page-CPU Control...................................................................47
Frequency Page-Frequency Control ................................................49
Limit Setting......................................................................................50
Voltage Page-Voltage Control ..........................................................52
Fan Page-Fan Control......................................................................53
FOX LiveUpdate
Local Update ....................................................................................54
Online Update ..................................................................................56
Congure .........................................................................................59
About & Help ....................................................................................61
FOX LOGO.............................................................................................62
FOX DMI ................................................................................................63
Chapter 5 RAID Conguration
RAID Conguration Introduction.............................................................66
Intel® Matrix Storage Manager ..............................................................68
Create a RAID Driver Diskette ...............................................................69
BIOS Conguration ................................................................................71
Create RAID in BIOS..............................................................................71
Install a New Windows XP .....................................................................99
Existing Windows XP with RAID built as data storage .........................103
Technical Support :
Website :
http://www.foxconnchannel.com
Support Website :
http://www.foxconnsupport.com
Worldwide online contact Support :
http://www.foxconnsupport.com/inquiry.aspx
CPU Support List :
http://www.foxconnsupport.com/cpusupportlist.aspx
Memory, VGA Compatibility List :
http://www.foxconnsupport.com/complist.aspx
Support
Thank you for buying Foxconn Q57M Series motherboard. Foxconn
products are engineered to maximize computing power, providing
only what you need for break-through performance.
With advanced overclocking capability and a range of connectivity
features for today multi-media computing requirements, Q57M
enables you to unleash more power from your computer.
This chapter includes the following information:
■ Product Specications
■ Layout
■ Back Panel Connectors
1
2
CPU
Support LGA1156 for Intel Lynneld/Clarkdale series CPU
Support CPU TDP 95W/92W/79W
Support Intel® Hyper-Threading technology
For the latest CPU information,
please visit：
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset
Intel®
Q57
Memory 4 x 240-pin DDR3 DIMMs
Support up to 16GB of system memory
Dual channel DDR3 1333/1066 MHz architecture
Expansion Slots 1 x PCI Express x16 slots
1 x PCI Express x1 slots
2 x PCI slots
VGA Intel Integrated GF
Storage 1 x Floppy connector
6 x SATA 2.0 connectors
600MB/s data transfer rate
Support RAID 0, 1, 5,10, Recovery
Support hot plug and NCQ (Native Command Queuing )
LAN Intel Boazman GbE 82578DM with Intel AMT6.0
Audio Realtek ALC888S Colay ALC662
- High Denition Audio
- 2/4/5.1/7.1-channel
- Support for S/PDIF Out
- Support Jack-Sensing function
USB Support hot plug
Support up to 14 x USB 2.0 ports (6 rear panel ports, 4 onboard USB
headers supporting 8 extra ports)
Support USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
6 x SATA connectors
4 x USB 2.0 connectors (supporting 8 x USB devices)
1 x TPM header
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front panel connector
1 x Front Audio connector
1 x Buzzer connector (Speaker header Reserved)
1 x COM connector
1-1 Product Specications
(Continued on the next page)
1
3
Back Panel 1 x PS/2 Keyboard port
Connectors 1 x Parallel port
1 x Display port
1 x VGA port
6 x USB 2.0 ports
1 x RJ-45 LAN port
8-channel Audio ports
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan speed control
PCI Express x1 Support 250MB/s (500MB/s concurrent) bandwidth
Low power consumption and power management features
PCI Express x16 Gen2.0 Support 8GB/s (16GB/s concurrent) bandwidth
Low power consumption and power management features
Green Function Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),
S4 (suspend to disk), S5 (soft - off)
Support EuP Function
Bundled Software FOX ONE
FOX LiveUpdate
FOX LOGO
FOX DMI
Operating System Support for Microsoft® Windows® 7/Vista/XP
Form Factor Micro ATX Form Factor, 9.6 inches x 9.6 inches (24.4cm x 24.4cm)
Table des matières
Autres manuels Foxconn Carte mère
Foxconn
Foxconn Renaissance II Manuel utilisateur
Foxconn
Foxconn G41MX 2.0 Manuel utilisateur
Foxconn
Foxconn P31A-S Manuel utilisateur
Foxconn
Foxconn 520A Manuel utilisateur
Foxconn
Foxconn A76GMV Manuel utilisateur
Foxconn
Foxconn A6VMX Series Manuel utilisateur
Foxconn
Foxconn 761GXK8MC Manuel utilisateur
Foxconn
Foxconn 875A02 Manuel utilisateur
Foxconn
Foxconn H55M-S Manuel utilisateur
Foxconn
Foxconn 661MXPro Fiche technique
Foxconn
Foxconn H81MXV Series Manuel utilisateur
Foxconn
Foxconn MARS Manuel utilisateur
Foxconn
Foxconn Cinema Deluxe Manuel utilisateur
Foxconn
Foxconn G41AP Series Manuel utilisateur
Foxconn
Foxconn A85GM Series Manuel utilisateur
Foxconn
Foxconn H67A Series Manuel utilisateur
Foxconn
Foxconn NF4UK8AA series Manuel utilisateur
Foxconn
Foxconn M61PMP-K Manuel utilisateur
Foxconn
Foxconn NF4K8MC Manuel utilisateur
Foxconn
Foxconn H55A Series Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
