Foxconn 520A Manuel utilisateur

Statement:

Thismanualistheintellectualpropertyof Foxconn,Inc.Althoughthe

informationinthismanualmaybechangedormodifiedatanytime,

Foxconn doesnot obligateitself toinformtheuser of these changes.

Trademark:

Alltrademarksarethepropertyoftheir respectiveowners.

Version:

User sManualV1.1for 560A/520ASeriesmotherboard.

Symboldescription:

Note: referstoimportantinformationthatcan helpyoutousemotherboard

better.

Attention: indicates thatitmaydamagehardwareorcause dataloss,

andtellsyou howtoavoidsuchproblems.

Warning: meansthat apotentialriskof propertydamageor physical

injuryexists.

Moreinformation:

If you want moreinformationaboutourproducts,pleasevisit Foxconn s

website: http://www.foxconnchannel.com

WEEE: The use of thesymbol indicates that thisproduct maynotbe

treatedashouseholdwaste.Byensuringthisproductisdisposedof

correctly,you willhelppreventpotentialnegativeconsequences forthe

environmentand human health,which couldotherwisebecausedby

inappropriatewastehandlingof thisproduct.Formoredetailedinforma-

tionabout recyclingofthisproduct, pleasecontact yourlocalcityoffice,

yourhouseholdwastedisposalservice ortheshopwhereyou pur-

chasedthe product.

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Declaration ofconformity

HONHAIPRECISIONINDUSTRYCOMPANYLTD

66,CHUNGSHAN RD.,TU-CHENGINDUSTRIALDISTRICT,

TAIPEI HSIEN,TAIWAN, R.O.C.

declaresthatthe product

Motherboard

560A/520A

isinconformitywith

(referencetothespecification under which conformityisdeclared in

accordance with89/336EEC-EMCDirective)

þEN55022:1998/A2:2003Limitsandmethodsofmeasurementsofradiodisturbance

characteristicsofinformationtechnologyequipment

þEN61000-3-2/:2000 Electromagneticcompatibility(EMC)

Part3: Limits

Section 2:Limitsforharmoniccurrent emissions

(equipmentinput current <=16Aperphase)

þEN61000-3-3/A1:2001 Electromagneticcompatibility(EMC)

Part3: Limits

Section2:Limitsof voltagefluctuationsand flickerin low-voltage

supplysystems forequipmentwithratedcurrent<= 16A

þEN55024/A2:2003 Informationtechnologyequipment-Immunitycharacteristicslimits

andmethodsof measurement

Signature: Place/ Date: TAIPEI/2007

PrintedName: JamesLiangPosition/Title: AssistantPresident

PDF 件使用 "pdfFactory" 试用版本创建 ³ ³www.fineprint.com.cn

Declaration ofconformity

Trade Name: FOXCONN

ModelName: 560A/520A

ResponsibleParty: PCE IndustryInc.

Address: 458 E.Lambert Rd.

Fullerton,CA92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classification: FCCClassBSubassembly

Type ofProduct: Motherboard

Manufacturer:HON HAIPRECISION INDUSTRY

COMPANYLTD

Address: 66,CHUNG SHANRD.,TU-CHENG

INDUSTRIALDISTRICT, TAIPEIHSIEN,

TAIWAN,R.O.C.

SupplementaryInformation:

ThisdevicecomplieswithPart15oftheFCC Rules. Operationissubjecttothefollow-

ingtwoconditions:(1) thisdevice maynotcauseharmfulinterference,and(2) this

devicemustacceptanyinterference received,includinginterferencethat maycause

undesiredoperation.

TestedtocomplywithFCC standards.

Signature: Date: 2007

PDF 件使用 "pdfFactory" 试用版本创建 ³ ³www.fineprint.com.cn

Specifications............................................................................................ 2

Jumpers...................................................................................................18

TableofContents

Enter BIOSSetup.................................................................................20

Mainmenu............................................................................................20

1.StandardCMOSFeatures..........................................................21

2. CentralControlUnit....................................................................23

3.AdvancedBIOSFeatures...........................................................26

4. AdvancedChipsetFeatures.......................................................27

5.IntegratedPeripherals...............................................................27

6.Power ManagementSetup........................................................28

7.PnP/PCIConfigurations.............................................................30

8. PCHealthStatus........................................................................30

9. LoadOptimizedDefaults...........................................................31

10.SetSupervisorPassword.........................................................31

11. Set User Password...................................................................31

12.Save &ExitSetup.......................................................................32

13. ExitWithout Saving....................................................................32

FOXONE...............................................................................................34

FOXLiveUpdate...................................................................................38

FOXLOGO............................................................................................40

FOXDMI................................................................................................41

Chapter 2BIOSDescription

Chapter 1

Chapter 3DirectionsforBundledSoftware

MainFeatures

PDF 件使用 "pdfFactory" 试用版本创建貌貌www.fineprint.com.cn

1.Attach the CPUand heatsinkusing silicageltoensurefullcontact.

2.Itissuggestedtoselecthigh-quality, certified fansinordertoavoid

damaging themotherboardandCPU duetohigh temperature.

3. Neverturnon thecomputerif the CPUfanisnotproperlyinstalled.

4.EnsurethattheDC powersupplyisturnedoff beforeinserting or

removingexpansioncardsorotherperipherals,especiallywhen

youinsert orremoveamemorymodule.Failuretoswitchoff the DC

powersupplymayresultinseriousdamagetoyoursystemor

memorymodule.

Since BIOSprogramsareupgratedfromtimetotime,theBIOS

description inthismanualisjustforreference.Wedo notguarantee

thatthecontentofthismanualwillremainconsistentwiththeactual

BIOSversion atanygiventimeinthefuture.

Attention:

PleasevisittheFoxconnglobalEnglishwebsite(http://www.

foxconnchannel.com) todownloadthelatest BIOSfileanddrivers

forthismotherboard.

Attention:

Wecannotguarantee thatyoursystemwill operatenormallywhile

overclock.Normaloperation dependson the overclock capacityof

your device.

Attention:

The pictures of objectsusedinthismanualarejustforyour reference.

Pleaserefertothe physicalmotherboard.

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter

Thankyou forbuying Foxconn s560A/520ASeriesmotherboard.

Thisseriesofmotherboardisoneofournewproducts,and

offerssuperiorperformance,reliabilityandquality,atareason-

ableprice.Thismotherboardadoptsthe advancedNVIDIA

nForce560 MCP(MCP68D-GT) / nForce 520MCP(MCP68D-S)

chipset,providingacomputerplatformwithhigh integration,

powerfulcompatibilityand high performance-priceratiofor

users.

Thischapterincludes thefollowing information:

v Specifications

v Jumpers

PDF 件使用 "pdfFactory" 试用版本创建 × ÿ ×www.fineprint.com.cn

Specifications-- English

(continued on the nextpage)

·RealtekGigabit LANController /Realtek10/100Mb/s

LANController

·NVIDIAnForce560 MCP(MCP68D-GT)/ nForce520

MCP(MCP68D-S)

·ATXformfactor: 305mm x193mm

Size

CPU

Chipset

Memory

Expansion Slots ·1xPCI Expressx16slot

·2xPCIExpressx1slots

·3xPCIslots

Audio ·Realtek8-channelAudioCODEC /Realtek6-channel

Audio CODEC

·SupportsS/PDIFoutput,Jack-Sensing function, Intel®

HighDefinitionAudio

·2xUltraDMA133/100/66 devices

·4xSATA300MB/sdevices

·RAID0,RAID1,RAID10configuration

Storage

·2x240-pin DIMMslots

·SupportsDual-ChannelDDR2-800/667/533

·Supportsup to4GB

·HT1.0up to2000MT/sHyperTransport

·SupportAMD®latestSocketAM2+ PhenomTM / AthlonTM /

SempronTM seriesprocessors

·SupportAMD®SocketAM2AthlonTM 64X2/AthlonTM 64/

SempronTM seriesprocessors

·SupportsHyperTransportTM Technology

RearPanelI/O ·1xPS/2MousePort

·1xPS/2KeyboardPort

·1xSerialPort(COM1)

·1xSerialPort(COM2)(optional)

·1xParallelPort

·4xUSB2.0Ports

·1xRJ45LANPort

·8/6-channelAudioPorts

LAN

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter1Main Features

·Specificationsaresubjecttochangewithoutnotice

·2xUSB 2.0headers(supports4USB 2.0ports)

·4xSATAconnectors

·1xFloppyconnector

·1xIDEconnector

·1xChassisintruderheader(INTR)

·1xCD_INheader

·1xSpeakerheader

·1xS/PDIF_OUT header

·1xFrontAudioconnector

·1x24-pin ATXPowerconnector

·1x4-pinATX_12VPowerconnector

·1xIrDAheader

·1xCPUFanconnector

·1xSystemFanconnector

·1xFAN1Fanconnector

·Frontpanel connector

Internal I/O

Connectors

·Driver

·Utility

Support CD

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

一章

主要性能

品规格--

简体中文

(下页继续)

·Realtek Gigabit LAN /Realtek 10/100Mb/s LAN

·2 个240针脚内存插槽

·支持双通道 DDR2-800/667/533

·内存总容量最大可达 4GB

·ATX 结构:305mmx193mm

尺寸

中央处理器

芯片组

内存

LAN

扩展槽 ·1 个PCI Expressx16 插槽

·2 个PCI Expressx1 插槽

·3 个PCI 插槽

音频

存储 ·2 个Ultra DMA 133/100/66 设备

·4 个SATA 300MB/s 设备

·RAID 0, RAID1, RAID 10 configuration

系统总线 ·HT1.0 最高可达 2000MT/s

·支持 AMD®最新的SocketAM2+PhenomTM/AthlonTM/

SempronTM 系列处理器

·支持 AMD®SocketAM2AthlonTM 64 X2/AthlonTM 64/

SempronTM 系列处理器

·支持 HyperTransportTM 技术

·NVIDIAnForce 560 MCP(MCP68D-GT)/nForce520

MCP(MCP68D-S)

后面板I/O ·1 个PS/2 鼠标接口

·1 个PS/2 键盘接口

·1 个串行接口(COM1)

·1 个串行接口(COM2)(选配)

·1 个并行接口

·4 个USB 2.0 接口

·1 个RJ45 网络接口

·8/6声道音频接口

·Realtek8 声道音频编解码器 /Realtek 6 声道音

频编解码器

·支持 S/PDIF 输出,Jack-Sensing 功能,Intel®

High Definition Audio

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

一章

主要性能

·2 个USB 2.0 接头(提供 4USB2.0 接口)

·4 个SATA 接头

·1 个软驱接口

·1 个IDE 接口

·1 个机箱开启侦测接头(INTR)

·1 个CD_IN 接头

·1 个Speaker 接头

·1 个S/PDIF_OUT 接头

·1 个前置音频接头

·1 个24 针ATX 电源接口

·1 个4 针ATX_12V 电源接口

·1 个红外线通讯接头

·1 个CPU 风扇接头

·1 个系统风扇接头

·1 个FAN1 风扇接头

·前端面接头

内置连接器

·规格若有任何更改，恕不另行通知

·驱动程序

·应用程序

实用程序光盘

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn
