Foxconn 925XE7AA series Manuel utilisateur

This manual is the intellectual property of FOXCONN, Inc. Although the

information in this manual may be changed or modified at any time,

Foxconn does not obligate itself to inform the user of these changes.

Statement:

All trademarks are the property of their respective owners.

User’s Manual V1.1 in English for 925XE7AA series motherboard.

P/N: 91-181-U25-A2-1E

Symbol description:

Note: refers to important information that can help you to use motherboard

better.

Attention: indicates that it may damage hardware or cause data loss,

and tells you how to avoid such problems.

Warning: means that a potential risk of property damage or physical

injury exists.

More information:

If you want more information about our products, please visit FOXCONN

website: www.foxconnchannel.com

Version:

Trademark:

Item Checklist:

Thank for your purchasing FOXCONN 925XE7AA series motherboard. Please check

the package; if there are missing or damaged items, contact your distributor as

soon as possible.

925XE7AA Series Motherboard (x1)

FOXCONN Utility CD (x1)

925XE7AA User Manual (x1)

RAID User Manual (x1)

RAID Floppy (x3) (2 for SATA / 1 for IDE)

IDE Ribbon Cable (x3)

FDD Ribbon Cable (x1)

I/O Shield (x1)

S-ATA Signal Cable (x8)

S-ATA Power Cable (x4)

USB 2.0 Cable (x1)

1394 Cable (x1)

Wi-Fi Card (x1) (optional)

Wi-Fi Antenna (x1) (optional)

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard

925XE7AA series

is in conformity with

(reference to the specification under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

 EN 55022/A1: 2000 Limits and methods of measurements of radio disturbance

characteristics of information technology equipment

 EN 61000-3-2/A14:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

 EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage fluctuations and flicker in low-voltage

supply systems for equipment with rated current <= 16A

 EN 55024/A1:2001 Information technology equipment-Immunity characteristics limits

and methods of measurement

Signature : Place / Date : TAIPEI/2004

Printed Name : James Liang Position/ Title : Assistant President

Declaration of conformity

Trade Name: FOXCONN

Model Name: 925XE7AA

Responsible Party: PCEIndustryInc.

Address: 458E.LambertRd.

Fullerton,CA92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classification: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer:HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the follow-

ing two conditions : (1) this device may not cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

Tested to comply with FCC standards.

Signature : Date : 2004

Product Introduction

Installation Instructions

Supply ............................................................................................

BIOS Description

StandardCMOSFeatures .......................................................................... 35

BIOSFeatures ...........................................................................................

Advanced BIOS Features ..........................................................................

Advanced Chipset Features ......................................................................

IntegratedPeripherals ................................................................................

PowerManagementSetup .........................................................................

PnP/PCIConfigurations...............................................................................

PCHealthStatus ........................................................................................

Load Fail-Safe Defaults .............................................................................

LoadOptimizedDefaults ............................................................................

Set Supervisor/User Password ................................................................. 60

Save & Exit Setup ......................................................................................

ExitWithoutSaving ....................................................................................

Table of Contents

Chapter

Driver CD Introduction

UtilityCDcontent........................................................................................ 63

Start to install drivers ................................................................................. 64

Install Chipset Software............................................................................. 64

InstallIAARAID(optional) .......................................................................... 65

InstallDirectX 9.0b ..................................................................................... 65

InstallAudio Driver (optional) ..................................................................... 66

Install LAN Driver (optional) ....................................................................... 66

InstallIDERAID ........................................................................................... 67

InstallSIL3114RAID ................................................................................... 67

InstallSuperUtility....................................................................................... 68

InstallAdobeReader .................................................................................. 68

Install Norton Internet Security ................................................................... 69

Directions for Bundled Software

SuperStep ................................................................................................. 71

SuperLogo ................................................................................................. 74

SuperUpdate.............................................................................................. 76

Special BIOS Functions

SuperBoot ................................................................................................. 82

SuperBIOS-Protect .................................................................................... 83

SuperRecovery ......................................................................................... 84

SuperSpeed............................................................................................... 93

Appendix

Using 8-channelAudio (optional) ............................................................... 94

Table of Contents

Chapter

1. Attach the CPU and heatsink using silica gel to ensure full contact.

2. It is suggested to select high-quality, certified fans in order to avoid

damage to the motherboard and CPU due high temperatures.

3. Never turn on the machine if the CPU fan is not properly installed.

4. Ensure that the DC power supply is turned off before inserting or

removing expansion cards or other peripherals, especially when

you insert or remove a memory module. Failure to switch off the DC

power supply may result in serious damage to your system or

memory module.

Warning:

We cannot guarantee that your system will operate normally while

over-clocked. Normal operation depends on the over-clock capacity

of your device.

Warning:

Attention:

Since BIOS programs are upgraded from time to time, the BIOS

description in this manual is just for reference. We do not guarantee

that the content of this manual will remain consistent with the actual

BIOS version at any given time in the future.

Attention:

The pictures of objects used in this manual are just for your reference.

Please refer to the physical motherboard.

This manual is suitable for motherboard of 925XE7AA series.

Each motherboard is carefully designed for the PC user who

wants diverse features.

-L with onboard 100M LAN

-K with onboard 1G LAN

-6 with 6 channel audio

-8 with 8 channel audio

-E with 1394

-S with SATA

-R with RAID

You can find PPID label on the motherboard. It indicates the

functions that the motherboard has.

For example:

On the blue mark of the PPID label, it means the

motherboard supports 6-Channel Audio(-6), 1394 port(-E),

onboard 100M LAN (-L), SATA function(-S).

Chapter

Thank you for buying FOXCONN 925XE7AA series motherboard.

This series of motherboard is one of our new products, and

offers superior performance, reliability and quality, at a reason-

able price. This motherboard adopts the advanced Intel® 925XE+

ICH6R chipset, providing users a computer platform with a high

integration-compatibility-performance price ratio.

This chapter includes the following information:

Main Features

Motherboard Layout

Chapter 1 Product Introduction

2925XE7AA Series User Manual

Main Features

Size

ATX form factor of 9.6 inch x 12 inch

Microprocessor

Supports Intel® , Prescott-T processor in an LGA775 package

Supports FSB at 1066MHz/800MHz

Supports Hyper-Threading technology

Supports FSB Dynamic Bus Inversion (DBI)

Chipset

Intel®925XE (North Bridge) + ICH6R (South Bridge)

System Memory

Four 240-pin DIMM slots

Supports single channel or dual channel mode

Supports DDR2 type DIMMs

Supports unbuffered DIMMs only

Supports 256-Mb, 512-Mb, and 1-Gb DRAM densities

Supports up to 4 GB of DDR2 memory

Supports Performance Acceleration Technology (PAT)

Registered DIMMs not supported

USB 2.0 Ports

Supports hot plug

Eight USB 2.0 ports (four rear panel ports, two onboard USB connectors

providing four extra ports)

Supports wake-up from S1 and S3 mode

Supports USB 2.0 Protocol up to 480 Mbps transmission rate

Onboard Serial ATA

150MBps transfer rate

Intel ICH6R South Bridge supports 4 x Serial ATA with RAID 0, RAID 1, RAID

0+1, Matrix RAID

Silicon Image 3114 RAID controller supports 4 x Serial ATA with RAID 0,

RAID 1, RAID 5, RAID 10, JBOD
