Foxconn 661M03 Series Manuel utilisateur

This manual is the intellectual property of Foxconn, Inc. Although the

information in this manual may be changed or modified at any time,

Foxconn does not obligate itself to inform the user of these changes.

Statement:

All trademarks are the property of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS/2 is the registered trademarks of IBM, Inc.

Windows®95/98/2000/NT/XP is the registered trademark of Microsoft.

Award®is the registered trademark of Award, Inc.

User’s Manual V1.0 in English for 661M03 series motherboard.

P/N:91-181-613-11-43

Symbol description:

Note: refers to important information that can help you to use motherboard

better.

Attention: indicates that it may damage hardware or cause data loss,

and tells you how to avoid such problems.

Warning: means that a potential risk of property damage or physical

injury exists.

More information:

If you want more information about our products, please visit Foxconn’s

website: www.foxconnchannel.com

Version:

Trademark:

Item Checklist:

Thank for your purchasing Foxconn’s 661M03 series motherboard. Please check

the package; if there are missing or damaged items, contact your distributor as

soon as possible.

661M03 series motherboard (x1)

Foxconn Utility CD (x1)

User’s Manual (x1)

IDE Ribbon cable (x1)

FDD Ribbon cable (x1)

I/O Shield (x1)

SPDIF Cable (x1) (optional)

USB 2.0 Cable (x1) (optional)

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard

661M03 series

is in conformity with

(reference to the specification under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

EN 55022/A1: 2000 Limits and methods of measurements of radio disturbance

characteristics of information technology equipment

EN 61000-3-2/A14:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage fluctuations and flicker in low-voltage

supply systems for equipment with rated current <= 16A

EN 55024/A1:2001 Information technology equipment-Immunity characteristics limits

and methods of measurement

Signature : Place / Date : TAIPEI/2003

Printed Name : James Liang Position/ Title : Assistant President

Declaration of conformity

Trade Name: Foxconn

Model Name: 661M03

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton,CA92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classification: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer:HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions : (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

Tested to comply with FCC standards.

Signature : Date : 2003

Product Introduction

Main Features .............................................................................................. 2

Motherboard Layout .................................................................................... 5

Installation Instructions

CPU ............................................................................................................ 10

Memory ...................................................................................................... 14

Power Supply ............................................................................................ 17

Rear Panel Connectors .............................................................................. 18

Other Connectors ...................................................................................... 20

Expension Slots ......................................................................................... 26

Jumpers ..................................................................................................... 29

BIOS Description

Enter BIOS Setup ....................................................................................... 33

Mainmenu ................................................................................................. 33

Standard CMOS Features .......................................................................... 35

BIOS Features ........................................................................................... 38

Advanced BIOS Features .......................................................................... 39

Advanced Chipset Features ...................................................................... 43

Integrated Peripherals ................................................................................ 47

Power Management Setup ......................................................................... 51

PnP/PCIConfigurations ............................................................................... 55

PC Health Status ........................................................................................ 56

Frequency/Voltage Control ......................................................................... 57

Load Fail-Safe Defaults ............................................................................. 58

Load Optimized Defaults ............................................................................ 58

Set Password ............................................................................................ 58

Save & Exit Setup ...................................................................................... 59

Exit Without Saving .................................................................................... 59

Table of Contents

Chapter 1

Chapter 2

Chapter 3

Driver CD Introduction

Utility CD content ........................................................................................ 61

Start to install drivers ................................................................................. 62

Install IDE Driver ......................................................................................... 62

Install AGP Driver ....................................................................................... 63

Install VGA Driver ...................................................................................... 63

Install DirectX ............................................................................................. 64

Install USB 2.0 Driver ................................................................................. 65

Using 4-/6-Channel Audio .......................................................................... 65

Install LAN Driver ....................................................................................... 71

Install Norton Internet Security 2004 .......................................................... 72

Directions for Bundled Software

SuperStep ................................................................................................. 74

SuperLogo ................................................................................................. 77

SuperUpdate .............................................................................................. 79

Special BIOS Functions

SuperSpeed ............................................................................................... 85

SuperBoot ................................................................................................. 86

SuperBIOS-Protect .................................................................................... 87

SuperRecovery ......................................................................................... 88

Table of Contents

Chapter

1. Attach the CPU and heatsink using silica gel to ensure full contact.

2. It is suggested to select high-quality, certified fans in order to avoid

damage to the motherboard and CPU due to high temperatures.

3. Never turn on the machine if the CPU fan is not properly installed.

4. Ensure that the DC power supply is turned off before inserting or

removing expansion cards or other peripherals, especially when

you insert or remove a memory module. Failure to switch off the DC

power supply may result in serious damage to your system or

memory module.

Warning:

We cannot guarantee that your system will operate normally while

over-clocked. Normal operation depends on the over-clock capacity of

your device.

Warning:

Attention:

Since BIOS programs are upgraded from time to time, the BIOS

description in this manual is just for reference. We do not guarantee

that the content of this manual will remain consistent with the actual

BIOS version at any given time in the future.

Attention:

The pictures of objects used in this manual are just for your reference.

Please refer to the physical motherboard.

Chapter

Thank you for your buying Foxconn’s 661M03 series

motherboard. This series of motherboard is one of our new

products and offers superior performance, reliability and

quality, at a reasonable price. This motherboard adopts the

advanced SiS 661FX+ 963/963L chipset, providing users a

computer platform with a high integration-compatibility-

performance price ratio.

This chapter includes the following information:

Main Features

Motherboard Layout

Chapter 1 Product Introduction

2661M03 Series User Manual

Main Features

Size

mATX form factor of 9.6”x 8.5”

Microprocessor

Supports Intel® Pentium®4 socket 478 (Willamette/Northwood/Prescott)

processors

Supports Intel® Celeron®socket 478 (Willamette/Northwood) processors

Supports FSB at 400MHz/533MHz/800MHz

Support Hyper-Threading technology

Chipset

SiS chipset: 661FX (North Bridge) + 963/963L (South Bridge)

System Memory

Two 184-pin DIMM slots

Supports PC 3200/PC 2700/PC 2100 memory

Supports 128/256/512 Mb technology up to 2GB

Onboard IDE

Supports up to 4 independent drives

Supports Ultra DMA 133/100/66

Two fast IDE interfaces supporting four IDE devices, including IDE hard disk

and CD-ROM/DVD-ROM drives

Onboard FDD

One FDD interface

Supports two 3.5” or 5.25” FDDs with 360K/720K/1.2M/1.44M/2.88M format

USB 2.0 Ports:

Supports hot plug

Six USB 2.0 ports (four rear panel ports, one onboard USB headers providing

two extra ports)

Supports wake-up from S1 and S3 mode

Supports USB 2.0 Protocol up to 480 Mbps transmission rate
