1 Introduction

1.1 Overview

The next generation master station is designed by Flowserve Limitorque speciﬁcally for use

with the Limitorque line of electric actuators equipped with Modbus DDC. The Master Station IV

(MSIV) acts as a single-source controller for up to 250 actuators.

The MSIV is a plug-and-play solution that provides complete control, monitoring, and diagnos-

tics of Limitorque electric actuators through a simple touch-panel display serving as a Human

Machine Interface (HMI).

1.2 User Role Overview

The MSIV requires users to login. Four user role levels are conﬁgurable for each user: 1) View,

2) Control, 3) Conﬁgure, and 4) Administrator. Each role includes the rights of the lesser roles

(i.e. Control includes View’s rights, and Conﬁgure includes Control’s rights and View’s rights).

VIEW: the user can view the network status and the activity log. No control

or conﬁguration functionality is available.

CONTROL: in addition to the View rights, the user has the ability to control

MOVs.

CONFIGURE: in addition to the Control rights, the user has the ability to conﬁgure

the Master Station and the Network.

ADMINISTRATOR: in addition to Conﬁgure rights, the user has the ability to add or

delete users, as well as modify user settings.

These roles can be changed by an Administrator user. See section the User Administration

section for details.

Limitorque

®Master StationI V EEP-SN4001 FCD LMENIM5010-00-AQ – 03/19

ﬂowserve.com

1.3 Login

When the MSIV completes the boot process, it loads the introduction screen (Figure 1.1).

Figure 1.1 - Introduction

Touching any part of the screen will load the Enter User name screen (Figure 1.2).

NOTE: If the screen is blank and the green power LED is illuminated, the MSIV is in screen saver mode.

Touch the display to exit the screen saver mode.

Figure 1.2 - Enter User Name

Once the user name has been entered, the Enter Password screen will be displayed (Figure 1.3).

NOTE: Each user name must have a unique password.

Figure 1.3 - Login

Limitorque

®Master Station IV EEP-SN4001 FCD LMENIM5010-00-AQ – 03/19

Passwords and user names are set via the User Administration menu, under System Conﬁguration.

The correct password entry for the respective user name will advance the screen to the Main Menu (Figure 1.4).

If passwords are lost or forgotten, please contact your Limitorque service coordinator at 1-434-528-4400.

1.4 Main Menu

Once logged in, the user will see the Main Menu (Figure 1.4).

Figure 1.4 - Main Menu

From here, the menu options are displayed based on the current user role. Each button represents a separate logical

section of the Master Station.:

SYSTEM STATUS (ALL USERS): View information related to the network status, status of the Master Station, and MOV

status.

SYSTEM CONTROL (CONTROL, CONFIGURE, AND ADMINISTRATOR): Access to MOV control and emergency

shutdown functions.

DIAGNOSTICS (CONFIGURE AND ADMINISTRATOR): Activate event logging, communication data analysis, or polling

statistics.

REBOOT: Restart the MSIV

SHUT DOWN: Shut down the MSIV

EXIT: Log out of the MSIV user mode.

Limitorque

®Master StationI V EEP-SN4001 FCD LMENIM5010-00-AQ – 03/19

ﬂowserve.com

1.5 System Technical Data

1. Power supply

1.1. Nominal: 24VDC to 48VDC (+/- 10%).

1.2. Absolute minimum: 21.6VDC.

1.3. Absolute maximum: 52.8VDC.

1.4. Maximum current draw is 2.0 amps.

2. Operating environment

2.1. It is recommended to install and operate the MSIV in an indoor, climate-controlled environment,

ideally in temperature range of 10 Celsius to 30 Celsius.

2.2. Absolute minimum operating ambient temperature: 0 degrees Celsius

2.3. Absolute maximum operating ambient temperature: 40 degrees Celsius

2.4. Humidity: maximum 85% RH non-condensing

3. Storage

3.1. Store the MSIV in a cool, dry area, out of direct sunlight.

3.2. Minimum storage temperature: -20 degrees Celsius

3.3. Maximum storage temperature: 60 degrees Celsius

3.4. Humidity: maximum 95% RH non-condensing

4. Human machine interface

4.1. 6.5” diagonal touch panel LCD

4.2. 640x480 resolution

4.3. Multiple language support: English, Spanish, and Chinese

5. Communication Protocols

5.1. MSIV to Field Units

5.1.1. Modbus RTU

5.1.1.1. EIA-485 (RS-485) physical layer

5.1.1.2. Bi-directional redundant loop or multi-drop network topologies

5.1.1.3. Maximum communication rate of 38.4 Kbaud

5.2. MSIV to DCS

5.2.1. Modbus RTU

5.2.1.1. TIA-232 (RS-232) physical layer

5.2.1.2. If RS-485 or RS-422 physical layers are required, an external converter can be speciﬁed.

5.2.1.3. Maximum communication rate of 115.2 Kbaud

5.2.2. Modbus TCP/IP

5.2.2.1. 10/100Mbit ethernet physical layer

6. System Redundancy

6.1. A completely modular, redundant system can be setup using two EEP-SN4001 modules.

6.2. Wire the modules in parallel to the same Modbus RTU actuator network and conﬁgure one module as

Active and one as Standby.

6.3. The Standby module will monitor network communications and if the Active module fails, the Standby

module will become active and take over the actuator network communications.

7. Electromagnetic Compatibility (EMC) Compliance

7.1. EN 61326-1:2013

7.2. EN 55011:2009+A1(2010) Class A

7.3. EN 61000-4-2:2009

7.4. EN 61000-4-3:2006+A1(2008)+A2(2010)

7.5. EN 61000-4-4:2004+A1(2010)

7.6. EN 61000-4-5:2006

7.7. EN 61000-4-6:2009

7.8. EN 61000-4-8:2010

7.9. EN 61000-4-11:2004

Limitorque

®Master Station IV EEP-SN4001 FCD LMENIM5010-00-AQ – 03/19

2 Function Flowchart

The following ﬂowchart graphics illustrate the main functional categories of the MSIV.

Table des matières

Autres manuels Flowserve Unité de contrôle

Flowserve

Flowserve APS1 Manuel

Flowserve

Flowserve Valtek GS Manuel utilisateur

Flowserve

Flowserve Valtek Mark Two Manuel utilisateur

Flowserve

Flowserve NAF ProCap Instructions d'installation

Flowserve

Flowserve Argus Series Manuel utilisateur

Flowserve

Flowserve MaxFlo4 Manuel utilisateur

Flowserve

Flowserve NAF Duball DL Manuel utilisateur

Flowserve

Flowserve Kammer 132000 Series Manuel utilisateur

Flowserve

Flowserve NORDSTROM HYPREGUN PLUS 5Q Instructions d'installation

Flowserve

Flowserve atomac ARV/SG Series Manuel utilisateur

Flowserve

Flowserve CPT 44 Manuel

Flowserve

Flowserve Valtek Mode d’emploi

Flowserve

Flowserve Valtek Mode d’emploi

Flowserve

Flowserve atomac AKH7 Series Manuel utilisateur

Flowserve

Flowserve Valtek ShearStream Mode d’emploi

Flowserve

Flowserve Argus EK Series Mode d’emploi

Flowserve

Flowserve Valtek CavControl Trim Mode d’emploi

Flowserve

Flowserve Valtek FlowTop V746 Manuel utilisateur

Flowserve

Flowserve Valtek Tek-Check Mode d’emploi

Flowserve

Flowserve Worcester V-Flow 51 Series Manuel utilisateur

Flowserve

Flowserve Durco Sleeveline G4XZ Manuel utilisateur

Flowserve

Flowserve R6 Manuel

Flowserve

Flowserve Valtek Mark 100 Manuel utilisateur

Flowserve

Flowserve AKH2.2 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
