Flowserve atomac ARV/SG Series Manuel utilisateur
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 1
Date: 04.1995
Revision: 06.2020
Technical Manual
Register 9
CONTENTS - ARV/SG
Contents Page
Technical Data ARV/SG-DIN ................................................................................. 2
Technical Data ARV/SG-ANSI............................................................................... 3
Material Specication ARV/SG.............................................................................. 4
Dimensions ARV/SG-DIN...................................................................................... 5
Dimensions ARV/SG-ANSI.................................................................................... 6
Spare Parts ARV/SG ............................................................................................ 7
Assembly Instructions ARV/SG ............................................................................. 8
Disassembly Instructions ARV/SG ........................................................................ 8
ARV/SG - Recommended Tightening Torques...................................................... 9
ARV/SG - Kv and Cv - Data .................................................................................. 9
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 2
Date: 04.1995
Revision: 06.2020
Technical Manual
Technical Data ARV/SG
Face-to-Face Dimensions DIN EN 558 (Basic series 1)
Flange Connections DIN EN 1092-2 PN 16
weight
DN / DIN L ØD Ød A
025 mm 160 25 30 33 kg 5,2
inch 6,3 0,98 1,18 1,3 lbs 11,5
040 mm 200 32 40 45 kg 11,0
inch 7,87 1,26 1,57 1,77 lbs 24,1
050 mm 230 40 50 65 kg 12,2
inch 9,06 1,57 1,97 2,56 lbs 26,9
080 mm 310 65 80 80 kg 21,2
inch 12,2 2,56 3,15 3,15 lbs 46,7
100 mm 350 80 100 100 kg 28,6
inch 13,78 3,15 3,94 3,94 lbs 62,9
150 mm 480 150 145 162,5 kg 64,0
inch 18,9 5,91 5,71 6,4 lbs 141,1
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 3
Date: 04.1995
Revision: 06.2020
Technical Manual
Technical Data ARV/SG
Flange Connections ANSI B 16.5 Cass 150,
Min. Flange thickness acc.
to ASME B 16.5 Cass 150,
Table 9 (Flanged Fittings)
weight
DN / ANSI L ØD Ød A
1“ inch 6 0,98 1,18 1,3 lbs 10,4
mm 152,4 25 30 33 kg 4,7
1½“ inch 7 1,26 1,57 1,77 lbs 19,8
mm 178 32 40 45 kg 9,0
2“ inch 8 1,57 1,97 2,56 lbs 23,8
mm 203 40 50 65 kg 10,8
3“ inch 9,5 2,56 3,15 3,15 lbs 40,1
mm 241 65 80 80 kg 18,2
4“ inch 11,5 3,15 3,94 3,94 lbs 62,0
mm 292 80 100 100 kg 28,2
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 4
Date: 04.1995
Revision: 06.2020
Technical Manual
Material specication ARV/SG
No. Designation Pieces Material Material-No. / DIN ASTM / AISI
010 body 1 ductile iron / PFA EN-JS1049 (GGG-40.3) / DIN EN 1563 A 395
1 ductile iron / PFA conductive EN-JS1049 (GGG-40.3) / DIN EN 1563 A 395
020 ange 1 ductile iron / PFA EN-JS1049 (GGG-40.3) / DIN EN 1563 A 395
1 ductile iron / PFA conductive EN-JS1049 (GGG-40.3) / DIN EN 1563 A 395
030 glass 2 borosilicate-glass DIN 7080
040 at gasket 2 UNITEC 300 green DIN 3535-6
050 stud bolt 1 set stainless steel 1.4301-K70 / DIN EN 10088-3 A 193 B8
060 hexagon nut 1 set stainless steel 1.4301-K70 / DIN EN 10088-3 A 194 8
100 ball 1 PTFE-solid ball
1 PTFE-solid ball conductive
110 ball guide 2 PTFE pure-PTFE
Valves with conductive lining only contain components with conductive materials
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 5
Date: 04.1995
Revision: 06.2020
Technical Manual
Dimensions ARV/SG
DN / DIN L b D k nxØd S1 S2
025 mm 160 20 115 85 4x14 4 4
inch 6,3 0,79 4,53 3,35 4x0,55 0,16 0,16
040 mm 200 21,5 150 110 4x18 4 4
inch 7,87 0,85 5,91 4,33 4x0,71 0,16 0,16
050 mm 230 23 165 125 4x18 4 4
inch 9,06 0,91 6,5 4,92 4x0,71 0,16 0,16
080 mm 310 25 200 160 4x18 5 4
inch 12,2 0,98 7,87 6,3 4x0,71 0,2 0,16
100 mm 350 25 220 180 4x18 5 4
inch 13,78 0,98 8,66 7,09 4x0,71 0,2 0,16
150 mm 480 29 285 240 8x19 5,5 4
inch 18,9 1,14 11,22 9,45 8x0,75 0,22 0,16
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 6
Date: 04.1995
Revision: 06.2020
Technical Manual
Dimensions ARV2/SG
DN / ANSI L b D k nxØd S1 S2
1“ inch 6 0,63 4,25 3,12 4x0,63 0,16 0,16
mm 152,4 16 107,9 79,2 4x16 4 4
1½“ inch 7 0,85 5 3,88 4x0,63 0,16 0,16
mm 178 21,5 127 98,5 4x16 4 4
2“ inch 8 0,87 6 4,74 4x0,75 0,16 0,16
mm 203 22 152,4 120,5 4x19 4 4
3“ inch 9,5 0,94 7,5 6 4x0,75 0,2 0,16
mm 241 24 190,5 152,5 4x19 5 4
4“ inch 11,5 1,08 9 7,5 8x0,75 0,2 0,16
mm 292 27,5 228,6 190,5 8x19 5 4
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 7
Date: 04.1995
Revision: 06.2020
Technical Manual
Spare Parts (item n°) - ARV/SG
Glass Flat gaskets
Set Set
Ball
DIN ANSI PTFE
025 1“ 0001451
040 1½“ 0001457
050 2“ 0001452
080 3“ 0001458
100 4“ 0001454
150 --- 0009495
DIN ANSI
025 1“ 0009537 0009543
040 1½“ 0009538 0009544
050 2“ 0009539 0009545
080 3“ 0009540 0009546
100 4“ 0009541 0009547
150 --- 0009542 0009548
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 8
Date: 04.1995
Revision: 06.2020
Technical Manual
ASSEMBLY INSTRUCTIONS ARV/SG
DISASSEMBLY INSTRUCTIONS ARV/SG
The general installation and maintenace instructions must be observed.
1. When assembling ARV/SG special care must be taken. In particular, the sealing surface has
to be absolutely clean and free from any damage.
2. Screw in stud bolts (050).
3. Press in rst ball guide (110).
4. Insert rst glass (030).
5. Insert rst gasket (040).
6. Put on rst ange (020).
7. Assemble hexagon nuts (060).
8. Insert ball (100).
9. Press in second ball guide (110).
10. Insert second glass (030).
11. Insert second gasket (040).
12. Put on sexond ange (020).
13. Tighten hexagon nuts (060) by criss-cross method acc. to recommended torques.
For all jobs which are to be carried out on an installed valve, the works safety requirements and
the general installation and maintenance instructions for uorcarbon resin lined atomac valves
must be observed.
1. Prior to disassembly, the valve must be drained of all line media, acc. to the
abovementioned instructions.
2. Remove hexagon nuts (060).
3. Remove parts as follows:
a. ange (020)
b. gasket (040)
c. glass (030)
d. ball guide (110)
e. ball (100)
f. ball guide (110)
4. Remove stud bolts (050).
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
ARV/SG - atomac check valve / sight glass combination
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 9
Page: 9
Date: 04.1995
Revision: 06.2020
Technical Manual
ARV/SG- recommended tightening torques*
ARV/SG - KvData and CvData
(DIN EN 60534-2-3)
* max. value
When bolting together dissimilar materials, always tighten
to the lowest recommended torque of the components in
the joint. Using higher torques may cause excessive defor-
mation of the „softer“ material in the joint
tie rods connection ange
DN Nm lbf · in Nm lbf · in
025 13,7 121 25 221
1“ 14,2 126 15 133
040 19 168 50 442
1½“ 20 177 26 230
050 38,5 341 65 575
2“ 39 345 60 531
080 52 460 55 487
3“ 52,5 465 100 885
100 44,5 394 64 566
4“ 45 398 76 673
150 61,6 545 123,6 1094
DIN ANSI
KVCV
m³/h gal/min
025 1“ 12,5 14,5
040 1 ½“ 25,9 30,1
050 2“ 48,1 55,9
080 3“ 95,4 110,9
100 4“ 159,3 185,2
150 --- At time not available
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
Your distribution partner:
Blindeisenweg 31 • D-41468 Neuss • Tel.: +49 2131 / 15 39 28-0 • Fax: +49 2131 / 15 39 28-99 • info@fergo.eu • www.fergo.eu
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Flowserve Unité de contrôle
Flowserve
Flowserve Valtek MaxFlo 4 Manuel utilisateur
Flowserve
Flowserve MASTER STATION IV EEP-SN4001 Manuel utilisateur
Flowserve
Flowserve Series 081000 Manuel utilisateur
Flowserve
Flowserve AKH2.2 Manuel utilisateur
Flowserve
Flowserve Edward 602Y Manuel utilisateur
Flowserve
Flowserve Valtek Tek-Check Mode d’emploi
Flowserve
Flowserve NAF 8886 Series Manuel utilisateur
Flowserve
Flowserve AKH2A Manuel utilisateur
Flowserve
Flowserve T4E-1 Manuel utilisateur
Flowserve
Flowserve Valtek Mark Six Mode d’emploi
Flowserve
Flowserve Valtek GS Manuel utilisateur
Flowserve
Flowserve 94 Series Manuel
Flowserve
Flowserve NAF Trunnball DL Series Manuel utilisateur
Flowserve
Flowserve 035 000 Series Mode d’emploi
Flowserve
Flowserve FlowTop V726 Instructions d'installation
Flowserve
Flowserve Argus EK 71 Manuel utilisateur
Flowserve
Flowserve NORDSTROM HYPREGUN PLUS 5Q Instructions d'installation
Flowserve
Flowserve Valtek Three-way Mode d’emploi
Flowserve
Flowserve NAF-Setball Manuel utilisateur
Flowserve
Flowserve Valtek MaxFlo 3 Manuel du propriétaire
Manuels Unité de contrôle populaires d'autres marques
Festo
Festo Compact Performance CP-FB6-E Manuel de la liste des pièces
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur
JS Automation
JS Automation MPC3034A Manuel utilisateur
JAUDT
JAUDT SW GII 6406 Series Guide rapide
Spektrum
Spektrum Air Module System Manuel utilisateur
BOC Edwards
BOC Edwards Q Series Manuel utilisateur
