Flashforge Hunter Manuel utilisateur

This guide is only applicable to FLASHFORGE Hunter 3D printer

The User Guide is in the USB stick.

WARNING

USERGUIDE

2. To ensure the printing quality, please don't open the light shield

unless it's necessary.

3. Unused photopolymer resin needs to be stored in a dark, dry,

and cool place.

4. Please clean the finished model with isopropyl alcohol (IPA).

1. Please put on gloves while using photopolymer resin to avoid

direct contact with hands.

HUNTER

Quick Start Guide

SZ09-EN-A02

BBB

C C

DO NOT loosen the screws marked

A, B, C, D in the diagram on the right,

as it will lead to printing failure and

pose injury risk to the user.

WARNING

Four screws marked in B locates in printer internally to fixed light engine. Four screws

marked in D locates in Z-Axis internally.

Kit Contents

3D Printer Quick Start Guide After-sales Service Card

Power Adapter Power Cable USB Cable

Rinse Bucket

Vinyl Gloves

VAT Film

Soft Cloth Brush

Metal Scraper Plastic Scraper

Photopolymer Resin

Spare Screw Kits Contents：

Hexagon Screws, Flat Washer, Spring Washer

Wrench Accessory Kit Contents：

Hexagon wrench, Phillips Screwdriver, USB stick,

Plastic Tweezers

Light Shield

Z-Axis

Platform Screw

Built Plate

Vat Film Screw

Resin Vat

Touch Screen Button

Touch Screen

Getting to Know Your Hunter

9 10 USB Cable

Input

USB Stick Input

Power Switch

11 12

The Back of the Printer

Power Input

Unpacking

1. Please lay flat the printer on a clean platform,

open the box from the bottom.

2. Set the Hunter upright, lay the white foam on

the floor and lift the carton.

3. Remove foam and accessory box from top.

The foam should contain: Quick start guide,

After-sales service card, and spare Vat film.

4. Accessory box contains USB cable, power

cable, scraper, plastic scraper, brush, soft

cloth, spare screw kits, plastic tweezers,

hexagon wrench, Phillips screwdriver, USB stick.

5. Tilt the Hunter left to remove the foam on the

right, and vice versa.

6. Each foam piece contains a cardboard box;

one holds a 500ml bottle of Photopolymer

Resin, the other holds a power adapter.

7. Remove the plastic bag (the seal is on the

bottom).

8. Remove the clear protection film.

9. Open the light shield. 10. Tear off the protection film as shown.

11. Tear off the protection film on the foam. 12. Hold the circled place with hands, then lift

it up until the bottom foam is raised above

the resin vat.

13. Take out the foam block. 14. The foam should hold a rinse bucket, which

contains a pair of vinyl gloves.

15. Cut the plastic white buckles that hold

the z-axis.

16. Congratulations! You've unpacked your Hunter.

MAX

Pour Photopolymer Resin into Vat

1. Tear off the seal, then open the cap. 2. There is a rubber plug at the mouth of the

bottle. Lift the ring to open and take out the

rubber plug.

3. Pour the photopolymer resin into the resin vat, filling it one-third of the way. Do not exceed the

maximum scale mark. Pour slowly to avoid spilling.

Put gloves on and pour photopolymer resin slowly to prevent spillage.

WARNING

First Print

Internal Memory

Select Driver

Hunter

File List

20mm_Box-Standard

1/1

Model View

FileName:

Material: FH1100(Stan...

Total Layer: 204

Layer Height: 0.05 MM

Build Time: 0 H 45 M

20mm...dard

Name:

Layer: 0/204

Time Remaining:

20mm_B...andard

1. Connect power cable and power adapter. 2. Plug the power cable into the input on the

back of Hunter and turn on the power switch.

3. Insert the attached USB stick into Hunter.

Settings

USB Memory

0H 45M

4. Press stand-by switch, then tap [Print].

5. Tap [ USB Memory ]. 6. Tap [20mm_box-Standard].

7. Then tap start icon to start printing.

Remove the Build Plate

1. After finishing printing, please put on vinyl

gloves and open the light shield.

2. Hold the build plate and loosen the bolt

until the build plate can move.

3. Carefully remove the build plate horizontally. 4. Hold the build plate on top of the vat for

the residue resin to run out.
