Flashforge ADVENTURER 3 Manuel utilisateur

本手册仅适用于闪铸科技 Adventurer3 3D打印机

This guide is only applicable to FLASHFORGE Adventurer3 3D printer

快速启动指南

ADVENTURER 3 /冒险家 3

Quick Start Guide

中文P11

SZ16-ZN/EN-A05

Unpacking

1. Open the box. 2. Remove wrapping paper box on the top,

there is a Quick start, an after-sales service,

an accessory kit, a power cable and a roll

of material on the plastic box.

3. Take out the printer of the carton, remove

bubble pack outside the printer.

4. Tear off fixed tapes and front door

protective bag.

5. Take power cable out and plug it into power

input.

6. Plug the other end of power cable into socket,

turn on the power switch.

9. Tap [Tools]-[Setting] on the touch screen as the picture

showed above, tap [Move].

Move Camera

FilamentCheck Led

2/3

Status Language

Calibration Home

1/3

Build

Tools

Filament

Network Preheat

Setting About

7. Turn on the power switch. 8. Open the front door.

10. Tap the upper arrow in the moving page to make the extruder raises for removing the

paper box on the bottom easier.

11. Squeeze wrapping paper box to the

middle slighly and take it out.

X: 20.00 Y: 45.00 Z: 36.00

12. Unboxing completed! Recommended that

you take good care of packing materials for

furthur carrying and keeping.

3D Printer Filament After-sales

service card

Allen WrenchScrewdriverQuick Start Guide Unclogging Pin Tool

Power Cable

Kit Contents

本手册仅适用于闪铸科技 Adventurer3 3D打印机

快速启动指南

Thisguide is only applicable to FLASHFORGEAdventurer3 3D printer

ADVENTURER3 发明家 3

SZ16-ZN/EN-A01

1. 高温危险！打印机喷嘴和打印平台在工作时会被加热，请避免接触!

1.Hot! Avoid touching the heating nozzle and heating build plate in operation.

Pleaserefer to FlashForge official websitewww.flashforge.com to download

thenewest User Guide and Quick Start Guide.

(SUPPORT-SupportCenter - Select a Product)

2.Moving parts in printer may cause injury. Do not weargloves or other

sourcesof entanglement in operation.

2. 可动部件可能造成卷入挤压和切割伤害。操作机器时请不要佩戴手套或缠绕物。

最新版本说明书请前往闪铸科技官方网站www.sz3dp.com下载。

（技术支持 - 下载中心 - 说明书/快速启动指南下载）

Grease

Getting to know your Adventurer 3

1. Filament guide tube 2. Filament guide tube joint 3. Extruder base 4.Cooling Fan

5. Removable nozzle 6. Extruder cables 7. Clip 8. Led light

9. Turbo Fan Baffle 10. Front door 11.Y-Axis sliding slot 12.Platform base

13. Removable build plate 14.Touch-screen 15.USB stick input 16.Power switch

17. Power input 18. Spool holder 19.Filament cover 20. Filament cover handle

21. Moto 22. Filament intake 23.Filament feeding wheel 24. Top cover

25. Air outlet 26. Ethernet input

14 15

3. Open the filament cover, insert the filament into the

filament intake, push filament into the feeding wheel

until some resistance is sensed.

Note: Please make sure filament has been pushed into

the feeding wheel!

First Print

1. Tap [Filament], tap [Load], after load completed, tap [OK].

2. As shown on the left, loading starts when the extruder

heated to target temperature.

Build

Tools

Filament

Load

Change

200 /235℃

Heating extruder...

Cancel

235 /235℃

Preheat completed,

Begin loading...

4. Load completed when you see filament come out of

extruder, tap [OK]. Put the spool of filament on the spool

holder, close the filament cover.

Mind the loading direction of filament, make sure to be clockwise as the picture

showed.

235 /235℃

Press ok when new color appears

1. Tap [Build], choose the file path: Print from local memory card.

2. Locate the model file in the model list, Tap on its right to start printing;

or tap model file picture or file name to enter model details page, tap to start printing.

3. Extruder will heat up and printer will start printing after heating completed. After model

printing finished, printer will sound a beep and pop out notice on touch screen.

Model Print

Build

Tools

Filament

6.67GB

No job

Not Available

1/3

...

0h10 min

Time Remaining

7.49

20mm_Box-

PLA.gx

20mm_Box-PLA.gx

20mm_Box-P...

0 h 10 min

0.70M

Build completed!
