Hygro‐ThermometerAlert

ModelRH35

99 Washington Street

Melrose, MA 02176

Phone 781-665-1400

Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

EXTECHINSTRUMENTS

2 RH35‐en‐EU_v1.17/14

Introduction

ThankyouforselectingtheExtechInstrumentsModelRH35.Thisdeviceisshippedfullytested

andcalibratedand,withproperuse,willprovideyearsofreliableservice.Pleasevisitour

website(www.extech.com)tocheckforthelatestversionofthisUserGuide,ProductUpdates,

andCustomerSupport.

Safety

InternationalSafetySymbols

Thissymbol,adjacenttoanothersymbolorterminal,indicatestheusermustrefertothemanualfor

furtherinformation.

Doubleinsulation

SafetyNotes

oRemovethebatteryifthedeviceistobestoredforlongerthan60days.

oNeverdisposeofbatteriesinafire.Batteriesmayexplodeorleak.

oNevermixbatterytypes.Alwaysinstallnewbatteriesofthesametype.

Cautions

oIftheequipmentisusedinamannernotspecifiedbythemanufacturer,theprotection

providedbytheequipmentmaybeimpaired.

oBatteriescancontainharmfulacids.Lowbatteriesshouldbechangedassoonaspossibleto

preventdamagecausedbyleaking.

oNeveruseacombinationofoldandnewbatteriestogether,orbatteriesofdifferenttypes.

oWearchemical‐resistantprotectiveglovesandglasseswhenhandlingleakingbatteries.

oDonotplaceyourproductnearextremetemperatures,vibrations,orshocks.

oProtectdevicefrommoisture.

EXTECHINSTRUMENTS

3 RH35‐en‐EU_v1.17/14

MeterDescription

MeterFront

1. 24‐hourmoldradaranimation

2. Indoortemperature(°C/°F)andMIN‐

MAX/Dewpointtemperature

3. FacialIconsforcomfortlevelstatus

4. MIN‐MAXButton

5. DewPointButton

6. RelativeHumidity%display

7. WarningLEDwhenriskofmold

MeterBack

1. Wallmount

2. Batterycompartment

3. Batterycompartmentlatch

4. AlarmSoundON/OFFswitch(SpeakerSymbol)

5. RadarAnimationON/OFFswitch(Arrow

Symbol)

6. Supportstand(removestandtoaccessAlarm

soundandRadaranimationswitches)

EXTECHINSTRUMENTS

4 RH35‐en‐EU_v1.17/14

Operation

GettingStarted

Removetheprotectivefoilfromthedisplay.

Openthebatterycompartmentandremovethebatteryinsulationstrip.Thedevicewill

soundthealarmandallLCDsegmentswillbedisplayedfortwosecondsasthedevice

switchesON.

Theindoortemperature,relativehumidity,andcorrespondingfacialsymbolwillappear

onthedisplay.Thisindicatesthatthemeterisnowreadyforuse.

Note:DonotattachthesupportstanduntiltheswitchesfortheRadarAnimationandAlarm

Soundaresetasdesired.Thesetwoswitchesareconcealedbythesupportstandwhenitis

attached.RefertotheDescriptionsectionofthisguideforthelocationoftheswitchesand

refertothededicatedsectionsbelowformoredetail.

24HourMoldRadarDisplay

Thedevicemeasurestherelativehumidity%every30secondsandcalculatestheaverage

valueevery10minutes.Theinnovativemoldradardisplaygraphicallydepictstheaverageon

a24‐hourtime‐line.

Thetime“0h”representsthevalueforthecurrenthour.“‐1”representsthelasthour,“‐3”

forthepast2‐3hours,“‐6”forthepast4‐6hours,“‐12”forthepast7‐12hours,and“‐24”for

thepast13‐24hours.

Therelativehumidityvaluesareshownongridlinesfrom15to85%.

Areadinghigherthan65%RHindicatesapotentialformold.

RadarAnimationON/OFFSwitch

RemovethesupportstandtoaccesstheRadarAnimationON/OFFswitchonthebackofthe

unit(theswitchisontherightidentifiedbythearrowicons).SlidetheswitchUPtoactivate

theRadarAnimation.SlidetheswitchDOWNtodeactivatetheRadarAnimation.

AlarmSoundON/OFFSwitch

RemovethesupportstandtoaccesstheAlarmSoundON/OFFswitchonthebackoftheunit

(theswitchisontheleftidentifiedbytheaudioicons).SlidetheswitchUPtoactivatethe

AlarmSoundbeeper.SlidetheswitchDOWNtode‐activatetheAlarmSoundbeeper.

Iftherelativehumiditymeasurementishigherthan65%,thealarmbeepersoundsforone

minuteandtheredwarninglight(frontpanel,right)flashes.Pressanybuttontostopthe

alarmsound.Thewarninglightcontinuesflashinguntilthemeasuredhumidityfallsbelow

65%.

ComfortLevel

Thedevicedisplaysoneoftwofacialindicatorsrepresentingthecomfortleveloftheindoor

climate.Asmilingfaceindicatesanidealrelativehumidityrange(40‐60%).Afrowningface

indicatesanoverlywetordrycondition(<40%or>60%).

EXTECHINSTRUMENTS

5 RH35‐en‐EU_v1.17/14

DewPointTemperatureDisplay

PresstheDewPointbuttontodisplaytheDewPointTemperaturefor5seconds.Thedisplay

willreverttotheAirTemperature/RelativeHumiditydisplaymodeafter5seconds,

automatically.

TemperatureUnitsSelection

PressandholdtheDewPointbuttonfor5secondstotogglethetemperatureunits(°Cand°F).

Note:InMIN/MAXmodepressingandholdingtheDewPointbuttonclearstheMINorMAX

memory(dependingonwhichoneisselected)anddoesnotchangethetemperatureunits.

EnsurethatMIN/MAXmodeisnotactivatedwhenchangingthetemperatureunits.

MinimumandMaximumValues

PresstheMIN/MAXbuttonandtheMAXiconwillappearalongwiththehighestindoor

temperatureandhumidityreadingscapturedsincethelastreset.

TodisplaytheMINvalues,presstheMIN/MAXbuttonagain.TheMINiconwillappear

alongwiththelowestindoortemperatureandhumidityreadingscapturedsincethelast

reset.

TheinstrumentwillautomaticallyexittheMIN/MAXmodeifnobuttonispressed.

Toexittothenormaldisplaymodemanually,presstheMIN/MAXbuttonagain(theMIN

andMAXindicatorswillswitchOFF).

TocleartheMINorMAXmemory,pressandholdtheDewPointbuttonforthree

secondswhiletheMINorMAXiconisshowing.TheMINortheMAXindicatorwillflash

asitsmemoryiscleared.

TableTopandWallmountingConsiderations

Theunitcanbewallmountedusingthewallmountaccessholelocatedontherearofthe

device.Usethesupportstandfortabletopuse.Notethatthehumiditylevelcanvarygreatly

accordingtolocation;mounttheunitasclosetotheareaofconcernaspossible.

EXTECHINSTRUMENTS

6 RH35‐en‐EU_v1.17/14

Maintenance

Cleaning

Cleantheinstrumentwithasoftdampcloth.Donotusesolventsorabrasives.

Batteryreplacement

Removethebatteriesiftheproductisnottobeusedforlongperiods.Changethebatteries

whenthebatterysymbolappearsemptyonthedisplay.Opentherearbatterycompartmentand

inserttwonewbatteries1.5VAAAobservingcorrectpolarity.Closethebatterycompartment

beforeuse.

BatterySafetyReminders

oPleasedisposeofbatteriesresponsibly;observelocal,state,andnationalregulations.

oNeverdisposeofbatteriesinafire;batteriesmayexplodeorleak.

oNevermixbatterytypes;installnewbatteriesofthesametype.

Neverdisposeofusedbatteriesorrechargeablebatteriesinhouseholdwaste.

Asconsumers,usersarelegallyrequiredtotakeusedbatteriestoappropriate

collectionsites,theretailstorewherethebatterieswerepurchased,orwherever

batteriesaresold.

Disposal:Donotdisposeofthisinstrumentinhouseholdwaste.Theuserisobligatedtotake

end‐of‐lifedevicestoadesignatedcollectionpointforthedisposalofelectricalandelectronic

equipment.

Specifications

TemperatureRange‐10°Cto60°C(14°Fto140°F)

TemperatureAccuracy±1°C(±1.8°F)from0to50°C(32to122°F),otherwise±1.5°C(2.7°F)

RelativeHumidityRange10to99%

RHAccuracy ±4%from30%to80RH%,otherwise±5%

Batteries Batteries2x1.5VAAA

Dimensions 98x23[50]x98mm(3.86x0.91[2.04]x3.86in.)

Weight 87g(3.1oz.)

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com
