Extech Instruments IR200 Manuel utilisateur

User’s Manual

Non-contact Forehead IR Thermometer

Model IR200

IR200 V1.0 5/09

Introduction

Congratulations on your purchase of the Model IR200 IR Thermometer. This thermometer

is intended for scanning groups of individuals or monitoring an individual for elevated

temperatures. It is not a substitute for a clinical thermometer. Always use a clinical

thermometer when high accuracy body temperature measurements are required.

Considerations and Warnings

Read all instructions before using this product.

For the most accurate results, make reading with an ambient (room) temperature of

73 to 82°F (23 to 27°C)

Make sure the skin is dry and that no hair interferes with the measurement.

Do not immerse the meter in water.

Avoid touching and/or scratching the infrared sensor lens.

Always use a clinical thermometer to verify any abnormal temperature

measurements.

Clean the lens area by gently blowing with compressed air and use a damp swab

to wipe the lens. Do not use any solvents to clean the lens.

Measurement Notes

1. If the meter has been stored in a cold or hot environment, allow it at least 20 minutes

to acclimate to room temperature before making measurements.

2. To prevent transmission of disease, avoid direct contact with the skin.

3. After heavy exercise always wait at least 10 minutes before taking forehead

temperature readings.

Warranty

EXTECH INSTRUMENTS CORPORATION (a FLIR company) warrants this instrument to be free of defects in

parts and workmanship for one year from date of shipment (a six month limited warranty applies on sensors

and cables). If it should become necessary to return the instrument for service during or beyond the warranty

period, contact the Customer Service Department at (781) 890-7440 ext. 210 for authorization or visit our

website at www.extech.com (click on ‘Contact Extech’ and go to ‘Service Department’ to request an RA

number). A Return Authorization (RA) number must be issued before any product is returned to Extech. The

sender is responsible for shipping charges, freight, insurance and proper packaging to prevent damage in

transit. This warranty does not apply to defects resulting from action of the user such as misuse, improper

wiring, operation outside of specification, improper maintenance or repair, or unauthorized modification. Extech

specifically disclaims any implied warranties or merchantability or fitness for a specific purpose and will not be

liable for any direct, indirect, incidental or consequential damages. Extech's total liability is limited to repair or

replacement of the product. The warranty set forth above is inclusive and no other warranty, whether written or

oral, is expressed or implied.

IR200 V1.0 5/09

Meter Description

1. IR sensor

2. Body – Surface switch

3. ▼button

4. ▲button

5. MODE button

6. Measurement trigger

7. LCD display

8. Battery compartment

DISPLAY

1. Surface mode

2. Body mode

3. Temperature display

4. Memory location

5. Alarm active

6. Temperature units

7. Low battery icon

8. Memory temperature display

IR200 V1.0 5/09

Operating Instructions

Body Temperature Measurements

1. Set the Body-Surface- switch for “Body” for accurate measurements in the range of

.86.0 to 109°F (30 to 43°C).

2. Hold the meter by its handle and point it toward the surface to be measured.

Measurement distance should be 2 to 6” (5 to 15cm).

3. Press the trigger to turn the meter on and take a temperature reading. The

temperature reading appears in the large display and the logged data number and

value appear in the smaller display.

4. Release the Trigger and the reading will hold for approximately 7 seconds after which

the meter will automatically shut off. Trigger presses can occur up to a rate of one a

second to quickly log samples.

5. If the temperature goes above 109°F or 43°C, Hi will appear in the display.

If the temperature goes below 86°F or 30°C, Lo will appear in the display.

Body Temperature Mode settings

1. With the meter OFF, press the MODE button once to set the C/F temperature units.

The temperature units will flash. Press the ▲or ▼buttons to change the units.

2. Press the MODE button a second time to set the alarm temperature limit. Press the ▲

or ▼buttons to change the value.

3. Press the MODE button a third time to enter the long term calibration drift correction

mode. On entering the mode, the previous temperature correction factor will appear

on the display. To make a correction, measure a known, fixed temperature source.

Enter the correction mode and press the ▲or ▼buttons to change the correction

value and minimize the difference in readings. Repeat and adjust the correction value

as needed until the measurement on the IR200 matches the known temperature.

4. Press the MODE button a fourth time to set the alarm buzzer status. Press the ▲or

▼buttons to switch from ON to OFF.

Surface Temperature Measurements

1. Set the Body-Surface- switch for “Surface” for wide range surface measurements of

most materials.

2. Hold the meter by its handle and point it toward the surface to be measured.

3. Press the trigger to turn the meter on and take a temperature reading. The

temperature reading appears in the large display and the logged data number and

value appear in the smaller display.

4. Release the Trigger and the reading will hold for approximately 7 seconds after which

the meter will automatically shut off. Trigger presses can occur up to a rate of one a

second to quickly log samples.

5. If the temperature goes above 140°F or 60°C, “Hi” will appear in the display.

If the temperature goes below 32°F or 0°C, “Lo” will appear in the display.

IR200 V1.0 5/09

SurfaceTemperature Mode settings

1. With the meter OFF, press the MODE button once to set the C/F temperature units.

The temperature units will flash. Press the ▲or ▼buttons to change the units.

2. Press the MODE button a second time to set the alarm temperature limit. Press the

▲or ▼buttons to change the value.

3. Press the MODE button a third time to set the alarm buzzer status. Press the ▲or

▼buttons to switch from ON to OFF.

Data memory

To review the logged data points, press both the ▲and ▼buttons while the unit is OFF.

Use the ▲or ▼buttons to scroll through the memory locations. To clear logged data,

select the “0” memory location and press the MODE button. The unit will beep twice to

indicate memory has been cleared.

Field of View

The meter’s field of view is 8:1. For example, if the meter is 8” (20cm) from the target

(spot), the diameter of the target must greater than 1” (2.5cm). Other distances are

shown in the field of view diagram. Measurements should normally be made as close as

possible to the device under test. The meter can measure from greater distances but the

measurement may be affected by external sources of light. In addition, the spot size

may be so large that it encompasses surface areas not intended to be measured.

Battery Replacement

When the low battery symbol appears on the display, replace the meter’s battery. The

battery compartment is located on the bottom of the handle. Open the compartment by

removing one screw and sliding the cover off. Replace the (2) “AA” batteries and close the

battery compartment cover.

IR200 V1.0 5/09

IR Measurement Notes

1. The object under test should be larger than the spot (target) size calculated by the field

of view diagram (printed on the side of the meter and in this guide).

2. Before measuring, be sure to clean surfaces that are covered with frost, oil, grime, etc.

3. If an object's surface is highly reflective, apply masking tape or flat black paint to the

surface before measuring. Allow time for the paint or tape to adjust to the temperature

of the surface it is covering.

4. Measurements through transparent surfaces such as glass may not be accurate.

5. Steam, dust, smoke, etc. can obscure measurements.

6. The meter automatically compensates for deviations in ambient temperature. However,

it can take up to 30 minutes for the meter to adjust to extremely wide changes.

Specifications

Range Accuracy

Body Temp 86.0 to 109°F (30 to 43°C) ±0.5°F/0.3°C

Surface Temp 32.0 to 140°F (0 to 60°C) ±1.5°F/0.8°C

Emissivity 0.95 fixed

Field of View D/S = Approx. 8:1 ratio (D = distance; S = spot or target)

IR Spectral response 6 to 14 μm (wavelength)

Display Backlit LCD display with function indicators

Response time 500ms

Over range indication “Hi“ or “Lo”

Operating Temperature 32oF to 122oF (0oC to 50oC)

Operating Humidity 10% to 90%RH operating, <80%RH storage.

Storage Temperature -4 to 140oF (-20 to 60oC)

Power Supply (2) AA” Batteries

Automatic Power Off 7 seconds (approx.),

Weight 6.24oz. (177g)

Dimensions 6.3 x 3.2 x 1.7” (160 x 82 x 42mm)

Calibration and Repair Services

Extech offers repair and calibration services for the products we sell. Extech also

provides NIST certification for most products. Call the Customer Service Department for

information on calibration services available for this product. Extech recommends that

annual calibrations be performed to verify meter performance and accuracy.

IR200 V1.0 5/09



Support line (781) 890-7440

Technical support: Extension 200; E-mail: [email protected]m

Repair & Returns: Extension 210; E-mail: [email protected]

Product specifications subject to change without notice

For the latest version of this User’s Guide, Software updates, and other

up-to-the-minute product information, visit our website: www.extech.com

Extech Instruments Corporation, 285 Bear Hill Rd., Waltham, MA 02451

IR200 V1.0 5/09
