User Manual

SL250W Sound Meter

Bluetooth® Connectivity with the ExView® Mobile App

Table of contents

1 Introduction........................................................................1

2 Safety ................................................................................2

3 FCC Compliance .................................................................3

4 Product Description ............................................................4

4.1 Meter Description .......................................................4

4.2 Function Buttons ........................................................ 4

4.3 Display Symbols.........................................................5

5 Operation...........................................................................6

5.1 Powering the Meter ..................................................... 6

5.2 Auto Power Off (APO)..................................................6

5.3 Taking Measurements .................................................6

5.4 Fast/Slow Response ................................................... 7

5.5 Data Hold Function .....................................................7

5.6 LCD Backlight............................................................ 7

5.7 MAX/MIN Readings .................................................... 7

5.8 Bluetooth Operation ....................................................7

6 Maintenance.......................................................................8

6.1 General Cleaning .......................................................8

6.2 Battery Replacement...................................................8

7 Specifications.....................................................................9

7.1 General Specifications................................................. 9

7.2 Measurement Specifications .........................................9

7.3 Environmental Specifications ........................................ 9

7.4 Connectivity Specifications ......................................... 10

8 Two-year Warranty............................................................. 11

8.1 Calibration and Repair Services................................... 11

8.2 Contact Customer Support ......................................... 11

#NAS100077; r. AA/78958/78963; en-US ii

Introduction

Thank you for selecting the Extech SL250W Sound Meter. This meter meas-

ures sound level with its built-in microphone, situated at the top of the meter.

Sound level measurements are shown on the backlit LCD in decibel (dBa)

units.

The meter includes Bluetooth connectivity, MAX/MIN memory, selectable

Fast/Slow response, auto power off, data hold, backlit LCD, and tripod mount.

Using the Extech ExView mobile app, you can pair your smart devices with

the meter using Bluetooth. The app and the W Series meters were developed

together for seamless integration. Download the free app from the App Store

(iOS®) or from Google Play (Android™).

This quality instrument is designed to provide years of reliable service, high

accuracy and simple operation. Please visit the Extech website for additional

information and world-class support.

#NAS100077; r. AA/78958/78963; en-US 1

Safety

Please read all safety information before using this device

CAUTION

• Check for damage to the device’s housing, sensor, display, and battery compartment

before use. If obvious damage or abnormalities are noticed, please discontinue use

and return the device for service.

• Do not attempt to open the meter housing or access the sensor module. There are no

user-serviceable components in this device.

• Replace the batteries immediately after the low battery symbol appears. If the device is

to be stored for a period of months, please remove the batteries and store separately.

• Do not store the device in high temperature or humidity environments, in flammable or

combustible areas, or where a strong electromagnetic field is present.

• This device is designed and produced following the strict requirements of SJ/T 10423

General Specification for Sound Level Meters.

• This device is CE certified.

#NAS100077; r. AA/78958/78963; en-US 2

FCC Compliance

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruc-

tions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television recep-

tion, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

WARNING

Changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.

#NAS100077; r. AA/78958/78963; en-US 3

Product Description

4.1 Meter Description

1. Microphone with wind screen attached

2. Backlit LCD (detailed below)

3. Function buttons (detailed below)

4. Tripod mount

5. Battery compartment

4.2 Function Buttons

Power / Bluetooth button

Long press to switch the device on. Short press to switch off.

With the meter powered, long press to switch Bluetooth on/off.

Short press to switch the meter off directly from the Bluetooth mode.

MAX/MIN button

Short press to cycle through MAX/MIN readings. The memories are

cleared each time meter power is cycled.

Data Hold / Backlight button

Short press to freeze/unfreeze the displayed reading. HOLD will display

when data hold is active.

Long press to switch the LCD backlight on/off.

#NAS100077; r. AA/78958/78963; en-US 4

Product Description

FAST / SLOW button

Short press to toggle the Fast and Slow modes. In Fast mode (125 ms)

sounds that peak very quickly, such as a firework ignition or a rifle dis-

charge, can be captured. Slow mode (1 second) is intended for sounds

that are continuous, such as the drone of machinery.

APO ON/OFF With the meter on, long press the power and Hbuttons to switch APO

on/off. The APO symbol is displayed when APO is enabled. APO is

reset each time the meter power is cycled.

4.3 Display Symbols

1. Bluetooth active

2. A-weighted (dBa) sound level reading

3. Maximum reading

4. Minimum reading

5. Data Hold mode

6. Battery status icon

7. Slow response mode

8. Fast response mode

9. Auto Power Off (APO) symbol

#NAS100077; r. AA/78958/78963; en-US 5

Operation

5.1 Powering the Meter

The meter operates on three (3) 1.5 V (AAA) batteries, installed in the rear

compartment.

Long press the power button to switch the meter on. Short press the power

button to switch the meter off. If the meter does not switch on, check the bat-

teries for proper orientation.

When the battery icon appears on the display, replace the batteries immedi-

ately to ensure accurate readings.

5.2 Auto Power Off (APO)

The meter switches OFF automatically five (5) minutes after the last button

press.

The default mode for APO is ON (the APO symbol on the display indicates

that APO is enabled).

To switch the APO function off, with the meter switched on, long press the

power and Hbuttons. The APO symbol will switch off, indicating that the

function is disabled. APO is reset each time the meter’s power is cycled.

Repeat this process to switch APO back on manually.

5.3 Taking Measurements

1. Long press the power button to switch the meter on.

2. Hold the meter in hand, set it on a desk or table, or mount it on a tripod in

the area under test.

3. Read the sound level measurement on the LCD. Sound level measure-

ments are presented in A-weighted decibel units. A-weighted measure-

ments simulate the response curve of the human ear to sound.

4. If the measurement is over range, OL will appear on the display in place of

a typical reading. If the measurement is under range, UN will appear.

CAUTION

Do not touch or otherwise obstruct the microphone.

Do not allow liquids to come in contact with the microphone.

Do not allow dust or other particles to enter the microphone.

Use the windscreen to cover the microphone in windy environments.

#NAS100077; r. AA/78958/78963; en-US 6

Operation

5.4 Fast/Slow Response

Short press the Fast/Slow button to toggle the meter’s response time. Use the

Fast response mode (125 ms) to capture sounds that peak very quickly such

as fireworks. Use the Slow response mode (1 second) to monitor consistent

sounds such as the hum, or drone, of machinery.

5.5 Data Hold Function

Short press the Data Hold (H) button to freeze/unfreeze the displayed read-

ings. While Data Hold is active, HOLD will appear on the LCD.

5.6 LCD Backlight

Long press the backlight button to switch the display backlight on or off.

Excessive use of the backlight will shorten battery life.

5.7 MAX/MIN Readings

When the device is switched on, it begins tracking the highest (MAX) and low-

est (MIN) readings.

Short press the MAX/MIN button to step through the MAX/MIN memories.

The memories are cleared each time the meter power is cycled.

Press the MAX/MIN button again to exit this mode (MAX and MIN symbols

switch off when you exit).

5.8 Bluetooth Operation

Long press the Bluetooth button with the meter on, to switch Bluetooth on

or off. This communication symbol is shown when Bluetooth is on.

The Bluetooth utility allows you to remotely monitor readings on an iOS or An-

droid smart device using the Extech ExView mobile app designed for use with

this meter.

Download the ExView mobile app from the App Store for iOS devices or from

Google Play for Android devices. Instructions for mobile app use are available

from the ExView product page on the Extech website (link below).

http://www.extech.com

Switch APO off when using Bluetooth by pressing and holding the power

and Hbuttons for 2 seconds (the APO symbol will switch off). This will pre-

vent the meter from automatically switching off while you are logging data or

monitoring readings in real time on your smart device.

#NAS100077; r. AA/78958/78963; en-US 7

Maintenance

CAUTION

Warning: Do not open the housing or microphone module. Service should only be per-

formed by factory personnel, there are no user-serviceable components in this device.

6.1 General Cleaning

Wipe the housing with a damp cloth as necessary to clean. Do not use abra-

sives or solvents to clean this device. Do not allow moisture to enter the mi-

crophone or the meter housing.

6.2 Battery Replacement

This device is powered by three (3) 1.5 V (AAA) batteries. When the low bat-

tery symbol appears, replace the batteries immediately, as explained below.

1. Switch the meter off and remove the rear battery compartment cover.

2. Replace the batteries, observing correct polarity. Always use batteries of

the same type.

3. Secure the battery compartment before use.

Do not dispose of used batteries or rechargeable batteries in house-

hold waste.

#NAS100077; r. AA/78958/78963; en-US 8

Autres manuels pour SL250W

Table des matières

Autres manuels Extech Instruments Thermomètre

Extech Instruments

Extech Instruments 445713-TP Manuel utilisateur

Extech Instruments

Extech Instruments RH490 Manuel utilisateur

Extech Instruments

Extech Instruments RH250W Manuel utilisateur

Extech Instruments

Extech Instruments 42540A Manuel utilisateur

Extech Instruments

Extech Instruments IR260 Manuel utilisateur

Extech Instruments

Extech Instruments 392050 Manuel utilisateur

Extech Instruments

Extech Instruments IR255 Manuel utilisateur

Extech Instruments

Extech Instruments RH490-NIST Manuel utilisateur

Extech Instruments

Extech Instruments 42512 Manuel utilisateur

Extech Instruments

Extech Instruments 445703 Manuel utilisateur

Extech Instruments

Extech Instruments 407907 Manuel utilisateur

Extech Instruments

Extech Instruments 42560 Manuel utilisateur

Extech Instruments

Extech Instruments 445715 Manuel utilisateur

Extech Instruments

Extech Instruments EasyView EA11A Manuel utilisateur

Extech Instruments

Extech Instruments 421508 Manuel utilisateur

Extech Instruments

Extech Instruments HD550 Manuel utilisateur

Extech Instruments

Extech Instruments 42545-NIST Manuel utilisateur

Extech Instruments

Extech Instruments 42500 Manuel utilisateur

Extech Instruments

Extech Instruments EzSmart RHT3 Manuel utilisateur

Extech Instruments

Extech Instruments VIR50 Manuel utilisateur

Extech Instruments

Extech Instruments 445715-NIST Manuel utilisateur

Extech Instruments

Extech Instruments HD500 Manuel utilisateur

Extech Instruments

Extech Instruments RH200W Manuel utilisateur

Extech Instruments

Extech Instruments EA15-NIST Manuel utilisateur

Manuels Thermomètre populaires d'autres marques

Delton

Delton 981A Manuel utilisateur

Baker

Baker MM2P Manuel utilisateur

Tarmo

Tarmo 320281 Manuel utilisateur

Citizen

Citizen CTD 504 Manuel utilisateur

TFA

TFA 14.1500 Manuel utilisateur

Vive

Vive DMD1010 Manuel utilisateur

Gotemp

Gotemp THB4002 Manuel utilisateur

GREISINGER

GREISINGER G 1202 Manuel utilisateur

Amprobe

Amprobe TMD-53W Manuel utilisateur

Trotec

Trotec BP10 Manuel utilisateur

Radiance instruments

Radiance instruments RT616 Series Manuel utilisateur

Eurolec

Eurolec IR151 Manuel utilisateur

Scaneo

Scaneo TS42B Manuel utilisateur

Sper scientific

Sper scientific 800043 Manuel utilisateur

Microlife

Microlife NC 200 Mode d’emploi

Motorola

Motorola MBP69SN Guide de configuration

The MeatStick

The MeatStick The MeatStick Manuel utilisateur

Hama

Hama TH35-A Manuel utilisateur
