Digitus DN-650102 Manuel utilisateur

8 10/100TX + 2 10/100/1000T/100/1000 SFP

Combo with 8 PoE Injectors Industrial Switch

User Manual

DN-650102

FCC Warning

This Equipment has been tested and found to comply with the limits for a

Class-A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance

with the instructions. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Content

Introduction................................................................ 1

Features................................................................... 1

Package Contents.................................................... 2

Hardware Description ............................................... 3

Physical Dimension.................................................. 3

Front Panel .............................................................. 3

Top View .................................................................. 4

LED Indicators ......................................................... 5

Ports......................................................................... 6

Cabling..................................................................... 8

Wiring the Power Inputs......................................... 11

Wiring the Fault Alarm Contact .............................. 11

Mounting Installation .............................................. 13

DIN-Rail Mounting.................................................. 13

Wall Mount Plate Mounting .................................... 15

Hardware Installation .............................................. 16

Installation Steps.................................................... 16

Network Application................................................ 17

Troubles shooting ................................................... 19

Technical Specification........................................... 20

Introduction

The 8 10/100TX + 2 10/100/1000T/100/1000 SFP Combo with 8 PoE Injectors Industrial

Switch is a cost-effective solution and meets the high reliability requirements demanded

by industrial applications. Using fiber port can extend the connection distance that

increases the network elasticity and performance.

Features

System Interface/Performance

RJ-45 ports support Auto MDI/MDI-X Function

Embedded 8-port PoE Injection

SFP (Mini-GBIC) supports 100/1000 Dual Mode

Store-and-Forward Switching Architecture

Back-plane (Switching Fabric): 5.6Gbps

1Mbits Packet Buffer

8K MAC Address Table

Supports Wide Operating Temperature (-40oC ~ 75oC)

Power Supply

Redundant Power Design

Case/Installation

IP-30 Protection

DIN Rail and Wall Mount Design

Relay Alarm

Relay output for port breakdown, power fail and alarm

Package Contents

Please refer to the package contents list below to verify them against the checklist.

8 10/100TX + 2 10/100/1000T/100/1000 SFP Combo with 8 PoE Injectors Industrial

Switch

User manual

Pluggable Terminal Block

2 wall mount plates and 6 screws

One DIN-Rail (attached on the switch)

8 10/100TX + 2 10/100/1000T/100/1000 SFP Combo with 8 PoE Injectors Industrial Switch

User Manual block connector

WallMountPlate Screws DIN-Rail

Compare the contents of the industrial switch with the standard checklist above. If any

item is damaged or missing, please contact the local dealer for service.

Hardware Description

In this paragraph, the Industrial switch’s hardware spec, port, cabling information, and

wiring installation will be described.

Physical Dimension

8 10/100TX + 2 10/100/1000T/100/1000 SFP Combo with 8 PoE Injectors Industrial

Switch dimension (W x D x H) is 72mm x 105mm x 152mm

Front Panel

The Front Panel of the 8 10/100TX + 2 10/100/1000T/100/1000 SFP Combo with 8 PoE

Injectors Industrial Switch is shown as below:

Front Panel of the PoE Injectors Industrial Switch

Top View

The top view of the 8 10/100TX + 2 10/100/1000T/100/1000 SFP Combo with 8 PoE

Injectors Industrial Switch has one terminal block connector of two DC power inputs.

Top View of the PoE Injectors Industrial Switch

LED Indicators

The diagnostic LEDs located on the front panel of the industrial switch provide real-time

information of system and optional status. The following table provides the description of

the LED status and their meanings for the switch.

LED Status Meaning

PWR1

Green Power 1 is active

OFF No power inputs

PWR2

Green Power 2 is active

OFF No power inputs

Fault

Red Power input 1 or 2 is inactive

OFF Power 1 & Power 2 are both active or no power

inputs

P9, P10 (RJ-45)

Upper

LED

Green Connected to network

Blinking Networking is active

OFF Not connected to network

Lower

LED

Green The port is operating at speed of 1000M

OFF The port is disconnected or not operating at

speed of 1000M

Link/Active

(P9, P10)

Green SFP port is linking

Blinks Data is transmitting or receiving

OFF Not connected to network

P1 ~ P8

(Green)

Green Connected to network

Blinking Networking is active

OFF Not connected to network

P1 ~ P8

(Yellow)

Yellow Ethernet port full duplex

Blinking Collision of packet occurs

OFF Ethernet port half duplex or not connected to

network

FWD (P1 ~ P8)

Green A powered device is connected utilizing Power

over Ethernet on the port

OFF No device is connected or power forwarding fails

Ports

RJ-45 ports

The UTP (RJ-45) Fast Ethernet ports will auto-sense for 10Base-T or 100Base-TX

connections. Auto MDI/MDIX means that the switch can connect to another switch or

workstation without changing straight through or crossover cabling. See the below

figures for straight through and crossover cable schematic.

RJ-45 Pin Assignments

Pin Number Assignment

1 Tx+

2 Tx-

3 Rx+

6 Rx-

[NOTE] “+” and “-” signs represent the polarity of the wires that make up each wire pair.

All ports on this industrial switch support automatic MDI/MDI-X operation, user can use

straight-through cables (See figure below) for all network connections to PCs or servers,

or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of

the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the

cable. The table below shows the 10BASE-T/100BASE-TX MDI and MDI-X port pin outs.

Pin MDI-X Signal Name MDI Signal Name

1 Receive Data plus (RD+) Transmit Data plus (TD+)

2 Receive Data minus (RD-) Transmit Data minus (TD-)

3 Transmit Data plus (TD+) Receive Data plus (RD+)

6 Transmit Data minus (TD-) Receive Data minus (RD-)

Straight Through Cable Schematic

Cross Over Cable Schematic

2 Mini-GBIC combo port: 2 auto-detect Giga port—UTP or fiber. The gigabit

Ethernet ports are shared with the mini-GBIC ports. UTP (Gigabit Ethernet) ports

can operate in half/full-duplex modes and work at speeds of 10/100/1000Mbps that

support auto-sensing technology to enable each port to detect the connecting speed.

The mini-GBIC port is a joint for a mini-GBIC (SFP) transceiver, so the switch can

be uplinked through fiber to another one.
