Digitus DS-45311 Manuel utilisateur

1.0

This

inpu

func

assis

This

4Kx2

inpu

com

signa

INTRODU

is a high-p

s and one

ion, but al

ant both at

HDMI UHD

@60Hz) a

s accommo

atible well f

ls to a high

TION

rformance

utput. Thi

o has intel

home and i

Switcher r

d digital au

ate the co

r video dis

efinition dis

and small-

HDMI UH

ligent func

n the work

utes high

io from an

nections of

lay, graphic

lays.

１

I Swi

anual

-45311

ized HDMI

Switcher

ion and h

lace.

definition

one of th

the high de

card, outpu

tch,

UHD Switc

ot only ha

t pluggabl

ideo (in m

several so

inition vide

sends the

her with ir

the key-pr

function.

ultiple reso

urces to dis

sources si

igh definitio

n shell, fi

ess-switchi

t is an ide

utions up

play units.

ultaneousl

n audio/vid

２

2.0 FEATURES

This HDMI UHD Switcher has many features that enable it to perform in a superior manner.

Among of those features, you will find:

Enable both mechanical and intelligent switching

Own excellent compatibility

Support highest video resolution up to 4Kx2K@60Hz

Support Full 3D

HDCP pass through

Support compressed audio such as DTS Digital, Dolby Digital (including DTS-HD

and Dolby True HD)

EDID bypass

Compatible well with other device

3.0 SPECIFICATIONS

Signal Inputs/Output

Input Video HDMI

Maximum Single Link Range Full 3D and 4Kx2K@60Hz

Output Video HDMI

Operating Frequency

Vertical Frequency Range 24/30/50/60Hz

Video Amplifier Bandwidth 6Gbps/600MHz

Resolutions (HDTV)

Interlaced (50&60Hz) 480i, 576i, 1080i

Progressive (50&60Hz) 480p, 576p, 720p, 1080p, 4Kx2K@30Hz,

4Kx2K@60Hz

Mechanical

Size (L-W-H) 123x51x20mm

Weight (Net) 154g

Environmental

Operating Temperature 0°C to +40°C

Operating Humidity 10% to 85% RH (no condensation)

Storage Temperature -10°C to +80°C

Storage Humidity 5% to 90% RH (no condensation)

Power Requirement

External Power Supply 5V/2A

Power consumption (Max) 2W

Accessories Adapter

IR remote 38KHz NEC Standard

Note: Specifications are subject to change without notice.

３

4.0 PACKAGE CONTENTS

Before attempting to use this unit, please check the packaging and make sure the

following items are contained in the shipping carton:

Main units

User Manual

Remote control

Power Adapter

5.0 CONNECTION AND OPERATION

Connection

A. Connect the HDMI input source into the HDMI switcher. (HDMI cables are optional)

* Please refer to connection diagram section.

B. Press the button to select the inputs.

C. Turn on the power

Attention: Insert/Extract cable gently.

Operation Notes

1. Once the source device is turned on or plugged in (should stay power-on mode),

the switcher will automatically select this source.

2. Once the source device is turned off or plugged out, the switcher will select the

next power-on source depending on the sequence automatically.

3. When the source devices are on the stand-by mode, its power supply should be

turned off.

4. When plugged in or out, this switcher is completely intelligent.

４

6.0 CONNECTION DIAGRAM

Hereby ASSMANN Electronic GmbH, declares that this device is in compliance with the requirements

of Directive 2014/30/EU (EMC), Directive 2014/35/EU (LVD) and the Directive 2011/65/EU for RoHS

compliance. The complete declaration of conformity can be requested by post under the below

mentioned manufacturer address.

Warning:

This device is a class B product. This equipment may cause some radio interference in living

environment. In this case, the user can be requested to undertake appropriate measures to prevent

interference.

www.assmann.com

Assmann Electronic GmbH

Auf dem Schüffel 3

58513 Lüdenscheid

Germany

HDMI UHD switch 5x1

HDMI CABLE

HD Display
