DFI BL330-BR Manuel utilisateur

BL330-BR

BL330-B

System Board

User’s Manual

A04830127

This publication contains information that is protected by copyright.

No part of it may be reproduced in any form or by any means or

used to make any transformation/adaptation without the prior writ-

ten permission from the copyright holders.

This publication is provided for informational purposes only. The

manufacturer makes no representations or warranties with respect to

the contents or use of this manual and specifically disclaims any ex-

press or implied warranties of merchantability or fitness for any par-

ticular purpose.The user will assume the entire risk of the use or the

results of the use of this document. Further, the manufacturer re-

serves the right to revise this publication and make changes to its

contents at any time, without obligation to notify any person or en-

tity of such revisions or changes.

Trademarks

Product names or trademarks appearing in this manual are for

identification purpose only and are the properties of the

respective owners.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

residential installation. This equipment generates, uses and can radi-

ate radio frequency energy and, if not installed and used in accord-

ance with the instruction manual, may cause harmful interference

to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

2. Shielded interface cables must be used in order to comply with

the emission limits.

Table of Contents

About this Manual................................................................................

Warranty.................................................................................................

Static Electricity Precaution................................................................

Safety Measures.....................................................................................

About the Package...............................................................................

Before Using the System Board.........................................................

Chapter 1 - Introduction....................................................................

Specifications...................................................................................................................................

Features..............................................................................................................................................

Chapter 2 - Hardware Installation....................................................

System Board Layout ..........................................................................................................

System Memory..........................................................................................................................

CPU.......................................................................................................................................................

Jumper Settings............................................................................................................................

Rear Panel I/O Ports.............................................................................................................

I/O Connectors..........................................................................................................................

Chapter 3 - BIOS Setup......................................................................

Award BIOS Setup Utility.................................................................................................

Intel RAID BIOS........................................................................................................................

Updating the BIOS..................................................................................................................

Chapter 4 - Supported Softwares.....................................................

Drivers, Utilities and Software Applications......................................................

Installation Notes.......................................................................................................................

Chapter 5 - RAID.................................................................................

Appendix A - Watchdog Timer.............................................................

Appendix B - System Error Messages...............................................

Appendix C - Troubleshooting..........................................................

108

109

116

118

120

About this Manual

An electronic file of this manual is included in the CD. To view the

user’s manual in the CD, insert the CD into a CD-ROM drive. The

autorun screen (Main Board Utility CD) will appear. Click “User’s

Manual” on the main menu.

Warranty

1. Warranty does not cover damages or failures that arised from

misuse of the product, inability to use the product, unauthorized

replacement or alteration of components and product specifica-

tions.

2. The warranty is void if the product has been subjected to physi-

cal abuse, improper installation, modification, accidents or unau-

thorized repair of the product.

3. Unless otherwise instructed in this user’s manual, the user may

not, under any circumstances, attempt to perform service, adjust-

ments or repairs on the product, whether in or out of warranty.

It must be returned to the purchase point, factory or authorized

service agency for all such work.

4. We will not be liable for any indirect, special, incidental or

consequencial damages to the product that has been modified

or altered.

Introduction

Static Electricity Precautions

It is quite easy to inadvertently damage your PC, system board,

components or devices even before installing them in your system

unit. Static electrical discharge can damage computer components

without causing any signs of physical damage. You must take extra

care in handling them to ensure against electrostatic build-up.

1. To prevent electrostatic build-up, leave the system board in its

anti-static bag until you are ready to install it.

2. Wear an antistatic wrist strap.

3. Do all preparation work on a static-free surface.

4. Hold the device only by its edges. Be careful not to touch any of

the components, contacts or connections.

5. Avoid touching the pins or contacts on all modules and connec-

tors. Hold modules or connectors by their ends.

Important:

Electrostatic discharge (ESD) can damage your processor,

disk drive and other components. Perform the upgrade in-

struction procedures described at an ESD workstation

only. If such a station is not available, you can provide

some ESD protection by wearing an antistatic wrist strap

and attaching it to a metal part of the system chassis. If a

wrist strap is unavailable, establish and maintain contact

with the system chassis throughout any procedures requir-

ing ESD protection.

Safety Measures

To avoid damage to the system:

• Use the correct AC input voltage range.....

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis

cover for installation or servicing. After installation or servicing,

cover the system chassis before plugging the power cord.

Battery:

• Danger of explosion if battery incorrectly replaced.

• Replace only with the same or equivalent type recommend

the manufacturer.

• Dispose of used batteries according to local ordinance.

Introduction

About the Package

The system board package contains the following items. If any of

these items are missing or damaged, please contact your dealer or

sales representative for assistance.

;The system board

;A user’s manual

;One IDE cable

;One FDD cable

;Two USB port cables

;Two Serial ATA data cables

;Two Serial ATA power cables

;One bracket mounted with a serial port

;One “Main Board Utility” CD

;Two RAID driver floppy diskettes (BL330-BR only)

;One I/O shield

;One QR (Quick Reference)

The system board and accessories in the package may not come

similar to the information listed above. This may differ in accordance

to the sales region or models in which it was sold. For more infor-

mation about the standard package in your region, please contact

your dealer or sales representative.

Before Using the System Board

Before using the system board, prepare basic system components.

If you are installing the system board in a new system, you will need

at least the following internal components.

•A CPU

•Memory module

•Storage devices such as hard disk drive, CD-ROM, etc.

You will also need external system peripherals you intend to use

which will normally include at least a keyboard, a mouse and a video

display monitor.

Introduction

Processor

Chipset

System Memory

Expansion Slots

Graphics

Audio

LAN

Serial ATA

Chapter 1 - Introduction

Specifications

• LGA 775 socket for:

- Intel®

CoreTM2 Quad / Intel®

CoreTM2 Duo

- Intel®

Wolfdale 45nm processors

• Supports Intel Enhanced Memory 64 Technology (EMT64T)

• Supports Enhanced Intel SpeedStep Technology (EIST)

• 1333*/1066/800MHz FSB

*Available on CPUs that support 1333MHz FSB

• Intel®

chipset

- Intel®

Q35 Express chipset

- Intel®

ICH9R I/O Controller Hub (BL330-BR)

Intel®

ICH9 I/O Controller Hub (BL330-B)

• Four 240-pin DDR2 DIMM sockets

• Supports dual channel (128-bit wide) memory interface

• Supports 667MHz and 800MHz DDR2 SDRAM

• Supports maximum of 8GB system memory using 512Mbit or

1Gbit technology for x8 and x16 devices

*ECC DDR2 DIMMs are not supported

• 1 PCI Express x16 slot

• 1 PCI Express x4 slot

• 2 PCI slots

• Integrated Intel GMA3100

- Up to 384MB maximum video memory

- 2048x1536 at 75 Hz maximum resolution

• Realtek ALC662 High Definition audio CODEC

• Six channel DAC supports 16/20/24-bit PCM format for 5.1

channel audio solution

• All DAC support independent 44.1k/48k/96kHz sample rate

• All ADC support independent 44.1k/48k/96kHz sample rate

• Supports 44.1k/48k/96kHz S/PDIF output

• One Realtek RTL8111DL PCI Express Gigabit controller

• Supports 10Mbps, 100Mbps and 1Gbps data transmission

• IEEE 802.3 (10/100Mbps) and IEEE 802.3ab (1Gbps) compliant

• Supports Serial ATA interfaces which are compliant with SATA

1.0 specification

• BL330-BR

- Supports up to 6 SATA devices

- SATA speed up to 3Gb/s

- RAID 0, RAID 1, RAID 0+1 and RAID 5 (SATA ports 1/2/3/4

only)

• BL330-B

- Supports up to 4 SATA devices

- SATA speed up to 3Gb/s

Introduction

IDE

Rear Panel I/O

Ports

I/O Connectors

BIOS

Energy Efficient

Design

Damage Free

Intelligence

Temperature

Humidity

PCB

• JMicron JMB368 PCI Express to PATA host controller

• Supports up to 2 UltraDMA 33/66/100Mbps IDE devices

• 1 mini-DIN-6 PS/2 mouse port

• 1 mini-DIN-6 PS/2 keyboard port

• 1 DB-25 parallel port

• 1 DB-9 serial port

• 1 DB-15 VGA port

• 1 RJ45 LAN port

• 4 USB 2.0/1.1 ports

• 3 audio jacks for line-in, line-out and mic-in

• 2 connectors for 4 additional external USB 2.0/1.1 ports

• 1 connector for external serial port

• 1 DIO connector

• 1 front audio connector for line-out and mic-in jacks

• 1 CD-in internal audio connector

• 1 S/PDIF-out connector

• 1 connector for IrDA interface

• 6 Serial ATA connectors (BL330-BR)

4 Serial ATA connectors (BL330-B)

• 1 40-pin IDE connector and 1 floppy connector

• 1 24-pin ATX power connector

• 1 4-pin 12V power connector

• 1 chassis open connector

• 1 front panel connector

• 3 fan connectors

• Award BIOS

• 8Mbit flash memory

• Supports ACPI specification and OS Directed Power

Management

• Supports ACPI STR (Suspend to RAM) function

• Wake-On-Events include:

- Wake-On-PS/2 KB/Mouse / Wake-On-USB KB/Mouse

- Wake-On-LAN and Wake-On-Ring

- RTC timer to power-on the system

• System power management supported

• Microsoft®

/Intel®

APM 1.2 compliant

• Soft Power supported - ACPI v1.0a specification

• AC power failure recovery

• Monitors CPU/system/AUX temperature and overheat alarm

• Monitors CPU(V)/5V/1.5V/dimm(V)/12V/VBAT(V)/3.3V/

V3.3sb(V) voltages and failure alarm

• Monitors CPU/system/2nd fan speed and failure alarm

• Read back capability that displays temperature, voltage and fan speed

• Watchdog timer function

•0

oC to 60oC

• 10% to 90%

• 4 layers, microATX form factor

• 24.4cm (9.6") x 24.4cm (9.6")

Introduction

S/PDIF

Features

The Watchdog Timer function allows your

application to regularly “clear” the system at

the set time interval. If the system hangs or fails to function, it will

reset at the set time interval so that your system will continue to

operate.

DDR2 is a higher performance DDR technology

whose data transfer rate delivers bandwidth of 4.3

GB per second and beyond. That is twice the speed of the conven-

tional DDR without increasing its power consumption. DDR2

SDRAM modules work at 1.8V supply compared to 2.6V memory

voltage for DDR modules. DDR2 also incorporates new innovations

such as the On-Die Termination (ODT) as well as larger 4-bit pre-

fetch against DDR which fetches 2 bits per clock cycle.

The graphics flexibility of the built-in Intel GMA3100

delivers exceptional 3D graphics performance. It sup-

ports analog CRT interface.

The audio jacks at the rear panel will support 5.1-

channel audio only when the audio utility is configured

to support this function. Both mic-in and line-in jacks will function as

center/subwoofer and rear right/left audio outputs respectively. The

front audio connector which allows connecting to the front panel of

the system will only support mic-in and line-out audio output.

S/PDIF is a standard audio file transfer format that

transfers digital audio signals to a device without

having to be converted first to an analog format. This prevents the

quality of the audio signal from degrading whenever it is converted

to analog. S/PDIF is usually found on digital audio equipment such as

a DAT machine or audio processing device.The S/PDIF connector on

the system board sends surround sound and 3D audio signal out-

puts to amplifiers and speakers and to digital recording devices like

CD recorders.

watchdog timer

DDR2

graphics

audio

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels DFI Carte mère

Manuels Carte mère populaires d'autres marques

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
