COM630-B

System Board

User’s Manual

A01430151

This publication contains information that is protected by copyright. No part of it

may be reproduced in any form or by any means or used to make any transfor-

mation/adaptation without the prior written permission from the copyright hold-

ers.

This publication is provided for informational purposes only. The manufacturer

makes no representations or warranties with respect to the contents or use

of this manual and specifically disclaims any express or implied warranties of

merchantability or fitness for any particular purpose. The user will assume the

entire risk of the use or the results of the use of this document. Further, the

manufacturer reserves the right to revise this publication and make changes to

its contents at any time, without obligation to notify any person or entity of such

revisions or changes.

Trademarks

All trademarks and registered trademarks of products appearing in this manual

are the properties of their respective holders.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or televi-

sion reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio TV technician for help.

Notice:

1. The changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

2. Shielded interface cables must be used in order to comply with the emission

limits.

Table of Contents

Trademarks........................................................................................2

FCC and DOC Statement on Class B..............................................3

About this Manual .............................................................................6

Warranty ..........................................................................................6

Static Electricity Precautions.............................................................7

Safety Measures.................................................................................7

About the Package ............................................................................8

Before Using the System Board........................................................8

Chapter 1 - Introduction ..................................................................9

Specifications..................................................................................9

Chapter 2 - Hardware Installation.................................................. 11

System Board Layout .................................................................... 11

Jumper Settings............................................................................. 12

PS/2 Power Select.................................................................... 12

USB Power Select..................................................................... 13

Panel Power Select................................................................... 14

Power-on Select....................................................................... 15

CompactFlash Socket Setting..................................................... 16

Rear Panel I/O Ports..................................................................... 17

PS/2 Ports and S/PDIF Ports...................................................... 18

Serial (COM) Ports ................................................................... 19

VGA Port................................................................................. 20

RJ45 LAN Port ......................................................................... 21

Universal Serial Bus Connectors................................................. 22

Audio...................................................................................... 23

Internal I/O Connectors................................................................ 25

CD-in Internal Audio Connector ................................................. 25

S/PDIF Connector..................................................................... 26

LVDS LCD Panel Connector and LCD/Inverter Power Connector...... 27

Digital I/O Connector and Digital I/O Power Connector................. 29

Parallel Connector (optional)...................................................... 30

Floppy Disk Drive Connector...................................................... 31

SATA (Serial ATA) Connectors.................................................... 32

IDE Connector ......................................................................... 33

IrDA Connector........................................................................ 35

Cooling Fan Connectors............................................................. 36

Chassis Intrusion Connector ...................................................... 37

Power Connectors .................................................................... 38

Wake-On-Ring Connector .......................................................... 39

Standby Power LED.................................................................. 40

Front Panel Connectors............................................................. 41

GPIO Connector....................................................................... 42

Expansion Slots ....................................................................... 43

Battery ................................................................................... 44

CompactFlash Socket................................................................ 45

COM Express Connectors .......................................................... 46

Introduction

About this Manual

An electronic file of this manual is included in the CD. To view the user’s manual

in the CD, insert the CD into a CD-ROM drive. The autorun screen (Main Board

Utility CD) will appear. Click “User’s Manual” on the main menu.

Warranty

1. Warranty does not cover damages or failures that arised from misuse of the

product, inability to use the product, unauthorized replacement or alteration

of components and product specifications.

2. The warranty is void if the product has been subjected to physical abuse,

improper installation, modification, accidents or unauthorized repair of the

product.

3. Unless otherwise instructed in this user’s manual, the user may not, under

any circumstances, attempt to perform service, adjustments or repairs on the

product, whether in or out of warranty. It must be returned to the purchase

point, factory or authorized service agency for all such work.

4. We will not be liable for any indirect, special, incidental or consequencial

damages to the product that has been modified or altered.

Introduction

Static Electricity Precautions

It is quite easy to inadvertently damage your PC, system board, components

or devices even before installing them in your system unit. Static electrical dis-

charge can damage computer components without causing any signs of physical

damage. You must take extra care in handling them to ensure against electro-

static build-up.

1. To prevent electrostatic build-up, leave the system board in its anti-static bag

until you are ready to install it.

2. Wear an antistatic wrist strap.

3. Do all preparation work on a static-free surface.

4. Hold the device only by its edges. Be careful not to touch any of the compo-

nents, contacts or connections.

5. Avoid touching the pins or contacts on all modules and connectors. Hold

modules or connectors by their ends.

Important:

Electrostatic discharge (ESD) can damage your processor, disk drive and

other components. Perform the upgrade instruction procedures described

at an ESD workstation only. If such a station is not available, you can

provide some ESD protection by wearing an antistatic wrist strap and

attaching it to a metal part of the system chassis. If a wrist strap is

unavailable, establish and maintain contact with the system chassis

throughout any procedures requiring ESD protection.

Safety Measures

To avoid damage to the system:

• Use the correct AC input voltage range.

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis cover for instal-

lation or servicing. After installation or servicing, cover the system chassis

before plugging the power cord.

Battery:

• Danger of explosion if battery incorrectly replaced.

• Replace only with the same or equivalent type recommend by the manufac-

turer.

• Dispose of used batteries according to local ordinance.

Introduction

About the Package

The system board package contains the following items. If any of these items are

missing or damaged, please contact your dealer or sales representative for as-

sistance.

One system board

One USB port cable

One Serial ATA data cable

One Serial ATA power cable

One IDE cable

One FDD cable

One I/O shield

One QR (Quick Reference)

The system board and accessories in the package may not come similar to the

information listed above. This may differ in accordance to the sales region or

models in which it was sold. For more information about the standard package in

your region, please contact your dealer or sales representative.

Before Using the System Board

Before using the system board, prepare basic system components.

If you are installing the system board in a new system, you will need at least the

following internal components.

• A CPU

• Memory module

• Storage devices such as hard disk drive, CD-ROM, etc.

You will also need external system peripherals you intend to use which will nor-

mally include at least a keyboard, a mouse and a video display monitor.

Introduction

Chapter 1 - Introduction

Specifications

Audio

Serial ATA

IDE

BIOS

(optional)

I/O Chip 1

I/O Chip 2

Damage Free

Intelligence

Temperature

Humidity

Rear Panel I/O

Ports

• Realtek ALC262 audio codec (ALC655 optional)

• 6-channel audio output

• SATA speed up to 3Gb/s

• Four SATA ports

• Supports up to Ultra ATA 100

• One IDE channel supports up to 2 IDE devices

• FWH/LPC interface

• Supports up to 4Mbit flash ROM

• PLCC32 socket

• Supports WP# jumper

• Carrier board ROM enable/disable function supported

• Winbond 83627HG-AW controller

• LPC interface

• Supports Smart fan

• Default I/O port address “2eh”

• Fintek F81216D controller

• LPC interface

• Supports 4 COM ports

• Supports IrDA

• Watchdog timer function

• Default I/O port address “4eh”

• Monitors system temperature and overheat alarm

• Monitors system fan speed and failure alarm

• Operating: 0oC to 60oC

• Storage: -20oC to 85oC

• Operating: 10% to 90%

• 1 mini-DIN-6 PS/2 mouse port

• 1 mini-DIN-6 PS/2 keyboard port

• 3 DB-9 serial ports

• 1 DB-15 VGA port

• 1 RJ45 LAN port

• 4 USB 2.0/1.1 ports

• Mic-in, line-in and line-out

Introduction

I/O Connectors

Expansion Slots

COM Express

Connectors

Dimensions

• 2 connectors for 4 additional external USB 2.0/1.1 ports

• 1 connector for an external serial port

• 1 LVDS LCD panel connector

• 1 LCD/inverter power connector

• 1 Digital I/O connector

• 1 Digital I/O power connector

• 1 front audio connector for line-out and mic-in jacks

• 1 CD-in internal audio connector

• 1 S/PDIF-in/out connector

• 1 GPIO connector

• 1 connector for IrDA interface

• 4 Serial ATA connectors

• 1 40-pin IDE connector

• 1 FDD connector

• 1 parallel connector (optional)

• 1 24-pin ATX power connector

• 1 4-pin 12V power connector

• 1 Wake-On-Ring connector

• 1 chassis open connector

• 1 front panel connector

• 3 fan connectors

• 1 diagnostic LED (optional)

• 1 CompactFlash socket

• 1 PCI Express x16 (Graphics or Dual SDVO)

• 2 PCI Express x1

• 4 PCI slots (PCI 2.3, 32-bit, 33MHz)

• Two 220-pin COM Express standard connectors

• Module connector pin: Tyco 3-631849-6

• Dimensions

- ATX form factor

- 305mm (12”) x 244mm (9.6”)

• Compliance

- PICMG COM Express R1.0, Type 2

Autres manuels pour COM630-B

Table des matières

Autres manuels DFI Carte mère

Manuels Carte mère populaires d'autres marques

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
