Datamax LP3 Manuel utilisateur

LP3 LABEL PRINTER

110149-006

User Guide

TABLE OF CONTENTS

Label Printer Views........................................ 1

Front View................................................... 1

Back View ................................................... 1

Right Side View............................................ 2

Left Side View.............................................. 2

Setting Up Your Printer ................................. 3

Unpacking Your Printer................................. 3

Installing Batteries ....................................... 3

Removing Batteries ..................................4

Charging the Batteries..............................5

Determining the Batteries' Condition.............. 6

Loading Printable Media ............................... 7

Using the Label Presenter ........................... 10

Printing a Self-Test..................................... 12

Connecting the Printer................................ 12

Installing a Data Cable ........................... 12

Bluetooth and/or 802.11

Parameters ..... 14

Configuring the Printer ............................... 14

Using the Control Panel............................... 15

Audio Indicators......................................... 15

Battery Status LED ................................... 16

Power Button/LED ................................... 17

Media Function Button/LED ..................... 17

Radio Button/LED ................................... 18

Maintenance and Troubleshooting ............. 19

Maintenance Guidelines .............................. 19

Preventative Maintenance........................... 19

Troubleshooting......................................... 20

Help Desk.................................................. 20

Supplies........................................................ 21

For more information .................................. 21

LP 3 LABEL PRINTER USER'S GUIDE

Label Printer Views

Front View

Back View

Printhead cover

(arrow) buttons

Control panel

Printhead cover

Handle strap

Data port

Figure 1

Figure 2

Label presenter

Roller

ABEL

RINTER

IEWS

Right Side View

Left Side View

Media ring

Media cavity

Security cover/

802.11X slot/

Bluetooth slot

Figure 3

Power port

Battery 2 cavity

Battery 1 cavity

Figure 4

LP 3 LABEL PRINTER USER'S GUIDE

Setting Up Your Printer

Use the following information to set up your printer:

• Unpacking Your Printer on page 3

• Installing Batteries on page 3

• Loading Printable Media on page 7

• Printing a Self-Test on page 12

• Connecting the Printer on page 12

• Configuring the Printer on page 14

In addition to the steps outlined in each section, additional

information may be included if it applies to, or expands upon,

the step being discussed.

Unpacking Your Printer

Before using the printer, remove all packaging material and

inspect the printer for possible shipping damage.

If the printer has been damaged:

• Contact the shipping company and file a damage report.

• Contact Datamax-O’Neil.

• Keep all shipping materials.

Installing Batteries

1. Remove any packaging material (if applicable).

2. Lift the silver battery tab and pull on the red tab to remove

the battery from the battery well (Figure 5).

3. Remove and discard the two red, battery isolator labels

(Figure 6).

Figure 6

Figure 5

ETTING

OUR

RINTER

4. Position the battery with its contacts facing up. The

battery contacts should face toward the back of the battery

cavity (Figure 7).

5. Insert the battery into the battery cavity. The printer beeps

one time when the first battery is installed.

Do not force the battery into the battery cavity. When

inserted properly, the battery easily slides into place and

the silver battery tab “locks” the battery (Figure 8). If the

battery does not easily slide into place, re-align the battery

based on step 2 above.

6. Repeat steps 1 to 5 to install the additional battery. Both

batteries must be installed for your printer to operate

properly

7. Charge the batteries (batteries are shipped uncharged). For

more information, see

Charging the Batteries on page 5

Removing Batteries

1. Lift the silver battery tab (Figure 9). If the battery does not

completely eject, slightly tilt the printer toward you to

remove the battery.

Figure 7 Figure 8

Silver battery tab

Figure 9

LP 3 LABEL PRINTER USER'S GUIDE

Charging the Batteries

If the batteries are low when the printer turns on, the battery

status LED displays red. For more information, see

Using the

Control Panel on page 15

. Perform the following procedure to

charge the batteries:

1. Verify both batteries are installed correctly.

2. Locate your AC adapter cable and verify the plug matches

the photo in Figure 10 (may or may not have tag attached).

3. Plug the AC adapter into the printer's power port

(Figure 11).

4. Plug the AC Adapter's power cord into an appropriate

power source.

5. Charge the batteries. The Battery Status LED turns red

while the batteries are charging and turns green when the

batteries are fully charged. One complete charge takes

4 to 5 hours.

Power port

Figure 11

Figure 10

ETTING

OUR

RINTER

Determining the Batteries' Condition

The battery status LED displays the batteries' condition. When

the battery status LED is solid red, the batteries must be

charged; when solid orange, the batteries are at low power;

when solid green, the batteries are charged.

The batteries'

voltage varies between 6.2 and 8.4 volts.

For information on battery error conditions, see

Using the

Control Panel on page 15

Caution: There is a risk of explosion if the battery is

replaced by an incorrect type. Dispose of used

batteries according to the instructions.

Caution: The operating temperature of this portable

printer is 45° C. However, the operating temperature

when used with Datamax-O’Neil power supply part

number 220240-100 for charging the portable printer

is limited to 40 degrees C. Please charge the printer in

a suitable location that meets this temperature

requirement.

Caution: Please only use the Datamax-O’Neil part

number 220240-100 power supply with this product.

Battery 1

Battery 2

Figure 12

LP 3 LABEL PRINTER USER'S GUIDE

Loading Printable Media

Use the following procedure to load printable media:

1. Move the printer so that the front of the printer is facing

toward you.

2. While steadying the printer, push the two arrow buttons

toward each other while opening the printhead cover

(Figure 13).

3. Move the printer so that the left side of the printer is facing

toward you.

4. Remove the media ring from the spindle by pressing the

media ring's latches while pulling the media ring toward

you (Figure 14).

5. Load the media onto the spindle. When loaded correctly,

the media should form a figure “6” as shown in Figure 15.

Media Guidelines

Media width 1” to 3.125”

Roll capacity diameter 3.5”

Media types Linered label media, thermal paper

* Depending on the type of media used, you

may need to configure your printer. For more

information, see

Configuring the Printer on

page 14

Figure 13 Figure 14
