D-Link DSL-245GR Manuel utilisateur

Quick Installation Guide

DSL-245GR

Wireless Dual Band VDSL2 Router with

ASDL2+/3G/LT Support and USB Port

DSL-245GR Quick Installation Guide

BEFORE YOU BEGIN

Delivery Package

•Router DSL-245GR

•Power adapter DC 12V/1.5A

•RJ-11 telephone ca le

•Ethernet ca le

•Splitter

•“Quick Installation Guide” ( rochure).

If any of the items are missing, please contact your reseller.

The “User Manual” and “Quick Installation Guide” documents are availa le

on D-Link we site (see www.dlink.ru).

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

DSL-245GR Quick Installation Guide

Default Settings

Do ain na e of device dlinkrouter.local.

IP address of device 192.168.1.1

Userna e (login) admin

Password admin

Na e of wireless network

(SSID)

2.4GHz DSL-245GR

5GHz DSL-245GR-5G

Network key (PSK password)

see WPS PIN on the

arcode la el on the ottom

panel of the device

Router DSL-245GR with default settings cannot connect to the Internet.

To get started, please set your own password for access to the we -

ased interface and change the WLAN name (SSID); then, if needed,

configure other settings recommended y your ISP.

DSL-245GR Quick Installation Guide

System Requirements and Equipment

•A computer with any operating system that supports a we rowser.

•A we rowser to access the we - ased interface of the router:

◦Apple Safari 8 and later

◦Google Chrome 48 and later

◦Microsoft Internet Explorer 10 and later

◦Microsoft Edge 20.10240 and later

◦Mozilla Firefox 44 and later

◦Opera 35 and later.

•A NIC (Ethernet or Wi-Fi adapter) to connect to the router.

•An 802.11a, , g, n, or ac Wi-Fi adapter to create a wireless network.

•A USB modem (when it is necessary to connect to the Internet via mo ile

operators' networks).1

Your USB modem should e equipped with an active SIM card of your

operator.

Some operators require su scri ers to activate their USB modems prior

to using them. Please, refer to connection guidelines provided y your

operator when concluding the agreement or placed on its we site.

For some models of USB modems, it is required to disa le the PIN

code check on the SIM card prior to connecting the USB modem to the

router.

1 Contact your operator to get information on the service coverage and fees.

DSL-245GR Quick Installation Guide

CONNECTING TO PC

PC with Ethernet Adapter

1. Connect an Ethernet ca le etween any of LAN ports located on the ack

panel of the router and the Ethernet port of your PC.

2. To connect via USB modem: connect your USB modem to the USB port2

located on the ack panel of the router.

!In some cases you will need to re oot the router after connection of the

USB modem.

3. To connect the device to a DSL line: connect a phone ca le etween the

DSL port of the router and the MODEM port of the splitter. Connect your

phone to the PHONE port of the splitter. Then connect another phone

ca le etween a phone jack and the L NE port of the splitter.

4. To connect the device to an Ethernet line: please connect the router to

the ISP's Ethernet line only after setting the WAN port and creating the

Internet connection (see the Initial Confi uration Wizard section, page

16).

5. Connect the power cord to the power connector port on the ack panel of

the router, then plug the power adapter into an electrical outlet or power

strip.

6. Turn on the router y pressing the ON/OFF utton on its ack panel.

Then make sure that your PC is configured to o tain an IP address

automatically (as DHCP client).

2 It is recommended to use a USB extension ca le to connect a USB modem to the

router.

DSL-245GR Quick Installation Guide

Obtaining P Address Automatically

(OS Windows 7)

1. Click the Start utton and proceed to the Control Panel window.

2. Select the Network and Sharing Center section. (If the Control Panel

has the category view (the Category value is selected from the View by

drop-down list in the top right corner of the window), choose the View

network status and tasks line under the Network and Internet

section.)

3. In the menu located on the left part of the window, select the Change

adapter settings line.

4. In the opened window, right-click the relevant Local Area Connection

icon and select the Properties line in the menu displayed.

5. In the Local Area Connection Properties window, on the

Networking ta , select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties utton.

DSL-245GR Quick Installation Guide

6. Make sure that the Obtain an IP address auto atically and Obtain

DNS server address auto atically choices of the radio uttons are

selected. Click the OK utton.

7. Click the OK utton in the connection properties window.

DSL-245GR Quick Installation Guide

PC with Wi-Fi Adapter

1. To connect via USB modem: connect your USB modem to the USB port3

located on the ack panel of the router.

!In some cases you will need to re oot the router after connection of the

USB modem.

2. To connect the device to a DSL line: connect a phone ca le etween the

DSL port of the router and the MODEM port of the splitter. Connect your

phone to the PHONE port of the splitter. Then connect another phone

ca le etween a phone jack and the L NE port of the splitter.

3. To connect the device to an Ethernet line: please connect the router to

the ISP's Ethernet line only after setting the WAN port and creating the

Internet connection (see the Initial Confi uration Wizard section, page

16).

4. Connect the power cord to the power connector port on the ack panel of

the router, then plug the power adapter into an electrical outlet or power

strip.

5. Turn on the router y pressing the ON/OFF utton on its ack panel.

6. Make sure that the Wi-Fi adapter of your PC is on. As a rule, modern

note ooks with uilt-in wireless NICs are equipped with a utton or

switch that turns on/off the wireless adapter (refer to your PC documents).

If your PC is equipped with a plugga le wireless NIC, install the software

provided with your Wi-Fi adapter.

Then make sure that your Wi-Fi adapter is configured to o tain an IP address

automatically (as DHCP client).

3 It is recommended to use a USB extension ca le to connect a USB modem to the

router.

DSL-245GR Quick Installation Guide

Obtaining P Address Automatically and

Connecting to Wireless Network (OS Windows 7)

1. Click the Start utton and proceed to the Control Panel window.

2. Select the Network and Sharing Center section. (If the Control Panel

has the category view (the Category value is selected from the View by

drop-down list in the top right corner of the window), choose the View

network status and tasks line under the Network and Internet

section.)

3. In the menu located on the left part of the window, select the Change

adapter settings line.

4. In the opened window, right-click the relevant Wireless Network

Connection icon. Make sure that your Wi-Fi adapter is on, then select

the Properties line in the menu displayed.

5. In the Wireless Network Connection Properties window, on the

Networking ta , select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties utton.

DSL-245GR Quick Installation Guide

6. Make sure that the Obtain an IP address auto atically and Obtain

DNS server address auto atically choices of the radio uttons are

selected. Click the OK utton.

7. Click the OK utton in the connection properties window.

8. To open the list of availa le wireless networks, select the icon of the

wireless network connection and click the Connect To utton or left-

click the network icon in the notification area located on the right side of

the task ar.
