D-Link DWR-932 Manuel utilisateur

4G/LTE MOBILE ROUTER

DWR-932

QUICK

INSTALLATION

GUIDE

КРАТКОЕ РУКОВОДСТВО ПО УСТАНОВКЕ

GUÍA DE INSTALACIÓN RÁPIDA

GUIA DE INSTALAÇÃO RÁPIDA

快速安裝指南

PETUNJUK PEMASANGAN CEPAT

Ver. 1.00(ME)_90x130 2017/02/08

DWR-932 3

ENGLISH

CONTENTS OF PACKAGING

LTE MOBILE ROUTER

DWR-932

USB CABLE

USB TYPE A TO MICRO USB A

If any of these items are missing from your packaging,

please contact your reseller.

CONTENTS

RECHARGEABLE BATTERY

• A SIM/UICC card with an active data plan.

• Computer with a minimum of:

• Internet Explorer 9, Firefox 28, Chrome 28, Safari 7, or higher with JavaScript

enabled

SYSTEM REQUIREMENTS

DWR-932

ENGLISH

HARDWARE SETUP

QUICK INSTALLATION

1. Remove the battery cover from the back of the device by

sliding it left, then remove the battery.

2. Note the SSID (network name) and password on the label

under the battery. If you want to connect to the DWR-932

wirelessly, you will need to enter this SSID and Password.

3. Slide the SIM card frame to the left and lift up. Insert the

SIM/UICC card into the SIM/UICC card slot as shown,

ensuring the gold contacts are facing down. Replace the

frame and slide it right to lock it in position.

Note: If you wish to use the onboard storage functionality,

you may install a microSD.

4. Reinsert the battery and replace the battery cover.

5. Connect the Micro USB end of the USB cable to the

Micro USB port on the bottom of the DWR-932 and plug

the other end into the USB port of the power adapter (not

included) or PC to charge the battery.

6. Press and hold the power button for ve seconds to turn

on the device and proceed with either the WI-FI ROUTER

MODE or 4G USB MODEM MODE installation procedure.

SIM

SIM SI M

DWR-932 5

ENGLISH

WI-FI ROUTER MODE

QUICK INSTALLATION

1. Use your PC's wireless adapter to connect to the

dlink_DWR-932_xxxx wireless network. The wireless

network name (SSID) and password are printed on the

label under the battery. You can also cycle through login

information on the LCD screen by briey pushing the power

button.

2. Use a web browser to go to http://192.168.0.1/ to log in to

the router's configuration page. The default username is

admin, and the default password is admin.

4G USB MODEM MODE

QUICK INSTALLATION

1. Connect the DWR-932 to your PC using the USB cable.

Follow the on-screen instructions to install the driver.

2. Use a web browser to go to http://192.168.0.1/ to log in to

the router's configuration page. The default username is

admin, and the default password is admin.

InstallShield Wizard

Welcome to the InstallShield Wizard for

DWR-932 USB Modem

DWR-932

ENGLISH

GETTING THE EZFi APP

The EZFi mobile app gives you an easy and convenient way to manage your

DWR-932. Easily check your data usage, set up a wireless network, or share your

mobile Internet connection with others.

You can download the free EZFi app on your smartphone or

tablet by scanning the QR code, or by searching for EZFi in the

app store for your device.

Note: Please refer to your device's app store to check whether

your device is compatible.

DWR-932 7

ENGLISH

1. WHY AM I UNABLE TO CONNECT TO MY MOBILE INTERNET SERVICE?

- Check to make sure the SIM card is installed properly, and that your SIM card has

3G/4G data service. Also, make sure that anti-virus software is not blocking your

connection and you are not connected to other Internet sources.

2. HOW DO I CONFIGURE MY DWR-932 ROUTER OR CHECK MY WIRELESS NETWORK

NAME (SSID) AND WIRELESS ENCRYPTION KEY?

- Power on the DWR-932 and connect it to your PC using the supplied Micro-USB

cable.

- Open a web browser and enter the router's IP address: http://192.168.0.1

- Log into the router using the default username admin and default password admin.

- Once logged in, you can use the wizard to view the wireless network name and

password of your router or make changes manually.

Note: If you have changed the password and cannot remember it, you will need to

reset the router to factory defaults. See bellow.

3. HOW DO I RESET MY DWR-932 TO FACTORY DEFAULT SETTINGS?

- If you cannot remember your router's administrator password or wireless network

settings, you may reset the DWR-932 to default settings by removing the battery

cover (do not remove the battery itself) and using a long, thin object (such as a

straightened paperclip), press and hold the reset button on the router for 5 seconds.

Note: Resetting the router to factory default will erase the current configuration

settings.

TROUBLESHOOTING

SETUP AND CONFIGURATION PROBLEMS

Reset button

DWR-932

TECHNICAL SUPPORT

Australia:

Tel: 1300-700-100

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: +91-832-2856000

Toll Free 1800-233-0000

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand, Indonesia,

Malaysia, Philippines, Vietnam:

Singapore - www.dlink.com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to 6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South

Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

D-Link Middle East - Dubai, U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai, U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 / 8809069

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

1, Makram Ebeid Street -

City Light Building - oor 5

Nasrcity - Cairo, Egypt

Tel.: +2 02 23521593 - +2 02 23520852

Technical Support: +2 02 26738470

General Inquiries: [email protected]

Tech Support: [email protected]

Kingdom of Saudi Arabia

Ofce # 84 ,

Al Khaleej Building ( Mujamathu Al-Khaleej)

Opp. King Fahd Road, Olaya

Riyadh - Saudi Arabia

Tel: +966 1121 70008

Technical Support:

+966 1121 70009

General Inquiries: info.sa@ dlinkmea.com

Tech Support: support.sa@ dlinkmea.com

Pakistan

Islamabad Ofce:

61-A, Jinnah Avenue, Blue Area,

Suite # 11, EBC, Saudi Pak Tower,

Islamabad - Pakistan

Tel.: +92-51-2800397, 2800398

Fax: +92-51-2800399

Karachi Ofce:

D-147/1, KDA Scheme # 1,

Opposite Mudassir Park, Karsaz Road,

Karachi – Pakistan

Phone: +92-21-34548158, 34326649

Fax: +92-21-4375727

Technical Support: +92-21-34548310, 34305069

General Inquiries: [email protected]

Tech Support: [email protected]

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

DWR-932 9

ENGLISH

TECHNICAL SUPPORT

Iran

Unit 1, 1st Floor, Plot No 3, Pazhoheshgah (2)

Alley, Ahmad Ghasir (Bokharest) St. , Shahid

Beheshti (Abbas Abad) St. , Tehran, Iran.

Postal Code : 1514615911

Tel: +98-21-88880918,19

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

M.I.T.C

Route de Nouaceur angle RS et CT 1029

Bureau N° 312 ET 337

Casablanca , Maroc

Phone : +212 663 72 73 24

Email: [email protected]

Lebanon RMA center

Dbayeh/Lebanon

PO Box:901589

Tel: +961 4 54 49 71 Ext:14

Fax: +961 4 54 49 71 Ext:12

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait:

Technical Support: + 965 22453939 / +965

22453949

DWR-932

РУССКИЙ

КОМПЛЕКТ ПОСТАВКИ

МОБИЛЬНЫЙ БЕСПРОВОДНОЙ

МАРШРУТИЗАТОР С ПОДДЕРЖКОЙ LTE

DWR-932

USB-КАБЕЛЬ

USB ТИПА А И MICRO-USB ТИПА А

Если что-либо из перечисленного отсутствует,

обратитесь к вашему поставщику.

СОДЕРЖИМОЕ

АККУМУЛЯТОР

• SIM/UICC-карта с действующим тарифным планом

• Компьютер:

• Internet Explorer 9, Firefox 28, Chrome 28, Safari 7 или выше с поддержкой

JavaScript

СИСТЕМНЫЕ ТРЕБОВАНИЯ
