D-Link DIR-506L Manuel utilisateur

Quick Install Guide

DIR-506L

SharePort™ Go

Your Mobile Companion

Version 1.10 | August 7, 2012

2 D-Link DIR-506L Quick Install Guide

Table of Contents

Package Contents .....................................................................3

LEDs .............................................................................................3

Insert and Charge Battery .......................................................4

User Scenarios ...........................................................................5

What is SharePort Mobile? ......................................................5

Download the SharePort Mobile App ..................................6

Connect USB ash drive and turn on power .......................7

Connect your Mobile Device Wirelessly to the DIR-506L 7

Using The SharePort Mobile App ..........................................8

Device Modes ......................................................................... 11

Wireless Router Mode .............................................................. 11

Wi-Fi HotSpot Mode ................................................................. 11

Download QRS (Quick Router Setup) Mobile APP .......... 12

Using QRS Mobile APP ......................................................... 13

Wireless Router Mode ............................................................. 14

Wi-Fi HotSpot Mode ................................................................. 15

Technical Support .................................................................. 16

D-Link DIR-506L Quick Install Guide 3

Package Contents

SharePort™ Go Your Mobile Companion

USB Cable (for power/battery charge only)

Battery

• SharePort Mobile App Requires iOS 4.3 or higher, and Android 2.0 or higher

• QRS Mobile App Requires iOs 4.2 or higher, and Android 2.0 or higher

Mobile Apps:

LEDs

Power LED - A solid amber light indicates a proper connection to

the power supply. The light will blink green when the USB cable is

disconnected. A solid red light indicates a low battery. When the

light is ashing red, you need to charge the device soon.

USB LED - A solid green light indicates that the USB cable is

attached and the SharePort is ready for use. A ashing green will

indicate your USB is processing the le.

Wi-Fi LED - A blinking green light indicates data is being

transmitted. A solid green shows that the Wi-Fi is on.

Ethernet LED - A green light indicates the Ethernet connection

has been established. A blinking green indicates data is being

transferred.

4 D-Link DIR-506L Quick Install Guide

1. The battery must be installed for the device to operate. Slide o

the cover and insert the battery. Make sure the gold contacts

align with the gold terminals. Slide the cover back on.

2. Connect the USB cable to the DIR-506L and then connect to a

USB port on your computer.

Note: Charge the device using the USB cable for at least 4 hours

or until it is fully charged before usage.

LAN

OFF

LAN

OFF

Insert and Charge Battery

D-Link DIR-506L Quick Install Guide 5

Insert and Charge Battery User Scenarios

The Internet does not need to be available in order to view photos,

watch movie or play music from your device. With the SharePort Mo-

bile App you will be able to:

• Watch movies and play music

• View photos and PowerPoint presentations

• View PDF les

• Upload your videos and photos to a USB ash drive.

What is SharePort Mobile?

The SharePort Mobile makes it simple to access media saved on your

USB drive right from your iPhone, iPad or Android device. Just follow

the three simple steps below:

1. Download the SharePort Mobile App from the Apple App store or

the Google Play store to your mobile device.

2. Plug the USB ash drive with media content such as movies (mov

or mp4), music (mp3 or wav), photos (jpg, bmp, gif or png), or

documents (key, pages, numbers, txt, ref, doc, PPt, XIS, or Pdf) to

the DIR-506L. *

3. Connect your Mobile device wirelessly to the DIR-506L. Then,

open the SharePort Mobile App, and you will be able to stream

your movies, music, and photos to all your mobile devices.

* Note: supports formats

Vdeo: iOS supports MP4 and MOV. Android supports MP4 and MOV video for-

mats.

Music: iOS support MP3 & WAV. Android supports MP3 & WAV.

Image: iOS & Android both support : JPG, BMP,GIF, PNG.

Document: iOS & Android both support: html, key, pages, numbers, txt, ref, doc,

PPt, XIS, Pdf.

6 D-Link DIR-506L Quick Install Guide

Download the SharePort Mobile App

Scan this code using a barcode scanner App (e.g. Bakodo or

RedLaser) from your iOS or Android device. If you do not have the

App, search for D-link SharePort Mobile from the App Store or

Google play. You will be directed to the App Store or the Google

play store to begin the Installation process. Please make sure you

have Internet connection before downloading the app.

D-Link DIR-506L Quick Install Guide 7

Download the SharePort Mobile App Connect USB ash drive and turn on power

Insert your USB drive into the

USB port on the DIR-506L.

Turn on the power switch

and wait until the power LED

turns green. Please allow 3-4

minutes to complete the boot-

up process before accessing

your USB drive.

Connect your Mobile Device Wirelessly to

the DIR-506L

Please connect your mobile device wirelessly to DIR-506L.

SharePort

WIFI SSID: dlink_DIR-506L

Password: “” (leave it blank)

LAN

OFF

LAN

OFF

SharePort

LAN

OFF

SharePort

LAN

OFF

8 D-Link DIR-506L Quick Install Guide

Using The SharePort Mobile App

1. Open the SharePort Mobile App.

2. Please wait for Wireless icon

on the bottom of the screen

to turn blue, then begin to

use.

3. Click on the Settings icon located on the right top corner of the

screen. Then, click Edit to enter your User Name and Password

(refer to the Create User section below). Once you nish,

click Done to continue. By default, User Name is “admin” and

Password is blank.

Note: If you set the password for the “admin” in your DIR-506L, you

need to enter the password.

Settings

D-Link DIR-506L Quick Install Guide 9

For the Movie section, click the Movie icon to

play your movie from your USB ash drive.

Movie

For the Music section, click the Music icon to

play your music from your USB ash drive.

Music

For the Photo section, click the Photo icon to

open your photo from your USB ash drive.

For the Files section, click on the Files icon to

open your le from your USB ash drive.


File

10 D-Link DIR-506L Quick Install Guide

For the Folder section, click on the Folder icon to

open a le from your USB ash drive. To upload a

photo le from your mobile device to your USB go

to + sign located on the upper right.

Once you open a le, you may add this le to your

Favorite folder by selecting the “Star” icon. For the

Favorite section, click on the Favorite icon to open

your favorite le from your USB ash drive.

Folder

You can access les from a USB hard drive that is plugged into the

DIR-506L from a web browser: http://dlinkrouter.local. :8181

Note: If you change your device/admin password, you will also

need to change your password in the SharePort Mobile app.
