DCT-23

Integrated Zone Amplier

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person to walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

RDV1 26/12/12 Preliminary Release

RDV2 16/05/13 RS-232 Commands

VS0 20/06/13 Updated text/diagrams

CONTENTS

1. Introduction............................................1

2. Applications...........................................1

3. Package Contents ................................1

4. System Requirements............................1

5. Features..................................................2

6. Operation Controls and Functions.......3

6.1 Front Panel.........................................3

6.2 Rear Panel .........................................4

6.3 Remote Control.................................5

6.4 RS-232 Protocols................................6

6.5 RS-232 and Telnet Commands........7

6.6 OLED Menu........................................8

7. Connection Diagram ..........................10

8. Specications ......................................11

9. Acronyms.............................................12

1. INTRODUCTION

The Integrated Zone Amplier accepts analog and digital stereo

audio signals via RCA, 3.5mm mini-jack, optical and coaxial digital,

and HDMI with an additional microphone input. As well as speaker

outputs, it boasts line level output, optical and digital outputs, and

HDMI outputs for wider systems integration. Suitable for use at musical

events, sound presentation and sound amplication. With audio

sampling rate support up to 48 kHz and I/O data rate support up to

24-bit, it provides a high quality sound reproduction.

2. APPLICATIONS

• Public speech

• Corporate Events

• Home systems

• Ceiling Speaker Systems

• Matrix zone amplication

3. PACKAGE CONTENTS

• 1×Integrated Zone Amplier

• 1×24 V/ 3.75 A DC Power Adaptor

• 1×Remote Control (CR-126)

• 1×IR Receiver

• 1×Power Cable

• Operations Manual

4. SYSTEM REQUIREMENTS

Audio source equipment such as DVD/Blu-ray players, PC, CD player,

MP3 etc. with output display TV/monitor and active speakers.

5. FEATURES

• 30 watts per channel Digital Stereo Amplier

• Supports Digital to Analog audio Conversion (DAC) and Analog to

Digital audio Conversion (ADC)

• HDMI Audio Embedding and de-embedding

• Supports input sampling rates up to 96kHz and output at 48kHz

• Dedicated XLR microphone input with independent volume control

• Supports microphone sound being embedded into audio output

• Simultaneous output of sound on both digital and analog

• Supports control via IR (Remote and IR Receiver input), RS-232 or IP

(Telnet)

• Analog line output selectable to be either xed or variable output

level

• Compact design and easy to use

Note: Does not support the decoding of Dolby® Digital signals

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

PUSH

EXIT POWER

UPDATE

Integrated Zone Amplifier

CONTROL

MIC

Coaxial In -20.0 dB

44.1K -> 44.1K

1 2 3 4 5 6 7

1MIC: Connect to a microphone or a mono balanced source.

2UPDATE: Manufacturer use only.

3LCM Display: Display current source selection and volume setting.

4IR Window: Accepts the IR signal from the supplied remote control.

5CONTROL: Control and direct volume adjustment. Turn the wheel

to directly adjust the volume level when not in the menu or press it

to enter into the menu. Turn the wheel to navigate the menu and

press it again to enter or conrm the selection.

6EXIT Button: Press this button to exit the menu. When not in the

menu press this button to mute the output, the LED will illuminate in

red. Press it again to unmute.

7POWER Button: Press this button to turn on the device, the LED will

illuminate in blue to indicate that it is powered. Press it again to

switch to standby mode, the LED will turn red to indicate that it is in

standby.

6.2 Rear Panel

CONTROL

HDMI OUT HDMI IN 1 HDMI IN 2

RS-232 LINE IN

OUTOPT.COAX.

INOPT. COAX.

OUTR

SPEAKER

RCA

IN DC 24V

IR IN

OUT

IN RLRL

1 3 7 129

4 5 6 8 10 11

1CONTROL: Connect to an active network with RJ-45 cable for

telnet control.

2HDMI OUT: Connect to HDTV/monitor for both audio and video

display.

3HDMI IN 1/2: Connect to HDMI source equipment such as a Set-

top Box or Blu-ray player.

4IR IN: Connect the IR receiver included in the package for

receiving the IR signal from the device’s remote control.

5RS-232: Connect to a PC/Laptop or control system with D-Sub

15pin cable for RS-232 control.

6LINE IN: Connect to an audio source with 3.5mm mini-jack cable

for stereo audio signal input.

7OPT. and COAX. OUT: Digital audio output. Connect to additional

ampliers or active speakers.

8OPT. and COAX. IN: Connect to source equipment such as a Set-

top-box or games console with an optical or coaxial digital output.

9SPEAKER L/R: Connect to speakers with standard speaker cable.

10 RCA IN: Connect to audio source equipment with an RCA cable

for analogue stereo audio input.

11 RCA OUT: Connect L/R output to active speakers or an additional

AU-A300 with an RCA cable for analogue stereo audio output.

12 DC 24V: Connect the 24V DC power supply to the unit and plug

the adaptor into an AC outlet.

6.3 Remote Control

1POWER: Press this button to turn the

device On or to set it into standby mode.

2MUTE: Press this button to mute the audio

output.

3 Vol. Up or Down (▲▼): Press these

buttons to turn the output volume up or

down.

4INPUT: Press these hot keys to switch the

required input source directly.

5MENU: Press this button to enter the OSD

MENU then press the up or down buttons

to select the required option and press it

again to conrm the selection.

6EXIT: Press this button to go back one

step or exit from the menu.

CR-126

MUTE

POWER

VOL.

EXIT

HDMI 1 HDMI 2

OPTICAL

COAXIAL LINE

INPUT

6.4 RS-232 Protocols

INTEGRATED ZONE AMPLIFIER

►

◄

REMOTE CONTROL

PIN Assignment PIN Assignment

1 NC 1 NC

2Tx 2Rx

3Rx 3Tx

4 NC 4 NC

5 GND 5 GND

6 NC 6 NC

7 NC 7 NC

8 NC 8 NC

9 NC 9 NC

Baud Rate: 115200bps

Data bit: 8 bits

Parity: None

Flow Control: None

Stop Bit: 1
