1 to 2 HDMI Distribution Amplier with 4K support
OPERATION MANUAL
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2011 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 23/07/2013 First release
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features..................................................7
6. Operation Controls and Functions.......8
6.1 Front Panel................................................... 8
6.2 Rear Panel..................................................... 8
7. Connection Diagram .............................9
8. Specications...................................... 10
9. Acronyms............................................. 11
6
1. INTRODUCTION
The QU-12S Distribution Amplier (splitter) accepts one HDMI input
and splits this signal to two identical outputs. This device is v1.4 HDMI
compliant and now supports 4K resolutions, 3D Video signals, and‘Deep
Colour', together with High Denition Audio. Each buered output can
run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers..
2. APPLICATIONS
Simultaneously display one HDMI source on 2 displays
Showroom display
University lecture hall display
Retail sales display
Commercial presentation splitter
3. PACKAGE CONTENTS
1 input to 2 output HDMI splitter
5V DC Power Supply Adaptor
Operation Manual
4. SYSTEM REQUIREMENTS
HDMI equipped source devices such as a DVD/Blu-ray play with HDMI
cables or DVI to HDMI cables
HDMI equipped displays (HDTVs or projectors) or AV Receivers with
HDMI cables
7
5. FEATURES
v1.4 HDMI, HDCP 1.1 and DVI 1.0 compliant
HDMI 1 to 2 Splitter
Resolutions supported: PC - VGA to UXGA; HDTV - 480i to 1080p, plus
1080p24fps, & 4K
High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio plus LPCM
Auto signal amplication & equalisation improves signal transmission
distances
Supports CEC bypass
Supports Deep Colour (10 & 12 bit)
Power LED indicator
Supports xvYCC
Supports 3D signals
Supports 4K x 2K Ultra High Denition Resolutions
8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
OUTPUT 1 OUTPUT 2
1
1HDMI OUTPUT
Connect each of the output ports to the HDMI displays for
simultaneous HDMI distribution.
6.2 Rear Panel
INPUT SERVICE
POWER DC 5V
1 2 3 4
1HDMI INPUT: Connect the input port to the HDMI output of your
source equipment such as a DVD player or set-top box.
2SERVICE: Manufacturer use only.
3POWER LED: The power LED will illuminate when the unit is powered.
4DC 5V: Connect the 5V DC power supply into the splitter and Plug the
adaptor to AC wall outlet.
9
7. CONNECTION DIAGRAM
INPUT SERVICE
POWER DC 5V
OUTPUT 1 OUTPUT 2
HDTVProjector
Blu-ray Player
HDMI Input
Simultaneous
HDMI Outputs
Power
Supply
10
8. SPECIFICATIONS
Note: When displaying a 3D signal with a higher bandwidth than 225 MHz or
a 4K×2K resolution source, a High Speed HDMI cable is required.
