Creality Halot-Sky Manuel utilisateur

HALOT-SKY

3D Printer User Manual

V1.1

HALOT-SKY

CREATE REALITY，ACHIEVE DREAMS

Dear Consumers

Thank you for choosing our products.For the best experience,please read the instructions before operating the Printer. Our

teams wiss

always be ready to render you the best services. Please contact us via the phone number or e-mail address provided at the end

when you encounter any problem with the Printer.

For a better experience in using our product, you can also learn how to use the printer in the following ways:

View the accompanied instructions and videos in the U disk.

Visit our oﬃcial website www.creality.com to ﬁnd relevant software/hardware information,contact details and operation and

Firmware Upgrade

Please login the oﬃcial website https://www.creality.com/download, switch the language and select the relevant printer and

maintenance instructions.

model and download the required ﬁrmware, you can use it after the installation is ﬁnished.

NOTES

Do not use the printer any way other than described herein in order to avoid personal injury or property damage.

Do not place the printer near any heat source or ﬂammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment.

Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.

Please use recommended resin to in case damage of machine.

Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet.

Please do not open the plastic cover during usage, otherwise the printing will be interrupted.

Do not wear cotton gloves when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage.

Please wait a moment after the print is ﬁnished. And please wear gloves to take out the print by tools.

Children under 10 years should not use the printer without supervision.

This machine is equipped with a security protection mechanism. Do not manually move the nozzle or printing platform mechanism manually while booting

up, otherwise the device will automatically power oﬀ for safety.

Clean the printer frequently. Always turn the power oﬀ when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material oﬀ the frame,

guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface.

Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to

safety obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any circustance.

Contents

Introduction 01-01

Parameters 02-02

Parts List 03-03

04-04

Assemble the 3D Printer

05-11

Use the 3D Printer

12-14

Start Printing

16-16

Wiring Connection

15-15

17-17

Troubleshooting

18-20

LCD 3D PRINTING FILAMENTS

21-22

Warranty Card

Control remote printing

Resin vat

Air ﬁlter

Hexalobular socket screw

Touch screen

Power socket

USB port

Limit switch

Hexalobular socket screw

Leveling screw

Buliding platform

1. Introduction

2.Equipment parameters

Model Name HALOT-SKY

192*120*200mm（length,width and height）

3840*2400

0.05mm

1-4s/layer

0.01-0.2mm

100-240Va.c, 50/60Hz

22.45KG

USB Disk, Creality Cloud

中文(简/繁)/ English/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk/Nederlands/Polskie/日本語/한국어

Win7/Win8/Win 10 64bit, Mac system (32-bit is not supported)

Common rigid photosensivie resin, Standard resin, Hight hardness,Compatible Resin High toughness, Dental model resin.

Integral light source (wavelength 405nm)

450*390*705mm

Package size

Rated Voltage

250W

Rated Power

Net Weight

Compatible Resin

Machine Language

Print Method

Gross Weight

Slicing Software Operation System

Build Size

XY Axis Resolution

Touch Screen

Light Source Type

340*292*552mm

Machine Size

XY Axis Accuracy

Print speed

Layer Thickness

Basic Parameters

5 inch touch screen

16.5KG

3. Package Content

Print platform x 1 Resin vat x 1 3D printer x 1

Screwdrivers x 1set

Tool list

U disk x 1 Plastic blade x 1

Metal blade x 1 Release ﬁlm x 1

Brush x 1

Resin ﬁlter x 4 Power cord x 1

9Vat cover x 1

Tips: the above accessories are for reference only, in kind prevail!

10 Calibration card x 1

Calibration Card

校准卡片

4. Assemble the 3D Printer

Machine body x 1

Plastic cover x 1

4.Lock the screws

1.Remove the screws

2.Place the acrylic protective cover

3.Note here that the iron piece is inserted

from the slot of the lower part

Note: The current interface is for reference only, due to the continuous upgrading

of functions, the actual to the oﬃcial website of the latest ﬁrmware UI as the standard.

Setting

5. Interface Information

Note: The current interface is for reference only, due to the continuous upgrading

of functions, the actual to the oﬃcial website of the latest ﬁrmware UI as the standard.

Setting
