Creality HALOT-LITE Manuel utilisateur
HALOT-LITE
3D Printer User Manual
V1.4
HALOT-LITE
CREATE REALITY，ACHIEVE DREAMS
Dear Consumers,
Firmware Upgrade
Please login the official website https://www.creality.com/download, switch the language and select the relevant printer and
model and download the required firmware, you can use it after the installation is finished.
Thank you for choosing our products.For the best experience,please read the instructions before operating the Printer. Our
teams will always be ready to render you the best services. Please contact us via the phone number or e-mail address
provided at the end when you encounter any problem with the Printer. For a better experience in using our product,
you can also learn how to use the printer in the following ways:
View the accompanied instructions and videos in the U disk.
Visit our official website www.creality.com to find relevant software/hardware information,contact details and operation and
maintenance instructions.
NOTES
1
2
3
4
5
6
7
8
9
10
Do not use the printer any way other than described here in order to avoid personal injury or property damage.
Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment.
Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.
Please use recommended resin to in case damage of machine.
Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet.
Please do not open the plastic cover during usage, otherwise the printing will be interrupted.
Do not wear cotton gloves when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage.
Please wait a moment after the print is finished. And please wear gloves to take out the print by tools.
Children under 10 years should not use the printer without supervision.
11
12
Tips：Do not plug or unplug the power cord when power on.
Clean the printer frequently. Always turn the power off when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material off the frame,
guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface.
Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety
obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any circustance.
Contents
Introduction 01-01
Parameters 02-02
Parts List 03-03
04-09
Use the 3D Printer
10-12
Start Printing
14-14
Wiring Connection
13-13
15-17
Troubleshooting
Control remote printing
Hexalobular socket screw
6
Resin vat
7
Touch screen
8
9USB port
Power socket
10
Limit switch
2
Protective cover
1
Hexalobular socket screw
3
Leveling screw
4
Buliding platform
5
1. Introduction
1
2
3
4
5
6
7
8
9
10
01
2.Equipment parameters
02
Model Name HALOT-LITE
USB Disk, Creality Cloud
3840*2400
0.05mm
1-4S/layer
250W
330*301*572mm
425*393*685mm
13.5KG
5 inch touch screen
Common rigid photosensivie resin, Standard resin, Hight hardness,High toughness, Dental model resin.
Integral light source (wavelength 405nm)
Win7/Win8/Win 10 64bit, Mac system (32-bit is not supported)
192*120*200mm（length,width and height）
Slicing Software Operation System
Rated Power
Build Size
Touch Screen
Machine Size
Package size
Gross Weight
Machine Language
Print Method
Print speed
Compatible Resin
Rated Voltage
Light Source Type
XY Axis Resolution
XY Axis Accuracy
Basic Parameters
100-240Va.c, 50/60Hz
10.6KGNet Weight
中文(简/繁)/ English/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk/Nederlands/Polskie/日本語/한국어
Layer Thickness 0.01-0.2mm
3. Package Content
Print platform x 1 Resin vat x 1 3D printer x 1
Screwdrivers x 1set
Tool list
U disk x 1 Plastic blade x 1
Metal blade x 1 Release film x 1
1
5
4
8
3
7
Brush x 1
2
6
Resin filter x 4 Power cord x 1
9Vat cover x 1
Tips: the above accessories are for reference only, in kind prevail!
10 Calibration card x 1
Calibration Card
校准卡片
03
4. Interface Information
Note: The current interface is for reference only, due to the continuous upgrading
of functions, the actual to the official website of the latest firmware UI as the standard.
Print
04
4. Interface Information
Note: The current interface is for reference only, due to the continuous upgrading
of functions, the actual to the official website of the latest firmware UI as the standard.
Setting
05
5. Level Platform
1. To calibrate the printing platform, first raise the platform, loosen the
fixing screws on the left and right sides of the material trough, and
take out the material trough;
2. Loosen the four Leveling screw
of the prototyping platform, attach Calibration
card tightly to the print screen, press
Settings → Z Axis Motion → Levelling（Refer
to operating steps of levelling platform 2 for
operation.）, to check whether the platform
fits evenly with the paper.
3. After confirming that Calibration card
fits evenly with the platform, screw up
the four screws of the platform.
Note: The printing platform has been leveled at the factory. If it needs leveling due to transportation or other reasons, please follow the steps
below to adjust the printing platform.
06
