Clarke CHT259 Mode d’emploi

WARNING: READ THESE INSTRUCTIONS BEFORE USE

OPERATION & MAINTENANCE

INSTRUCTIONS

LS0819 - ISS 1

ORIGINAL INSTRUCTIONS

3 LEGGED GLAZE BREAKER

MODEL NO: CHT259

PART NO: 1801259

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE 3 legged glaze breaker.

The tool must be attached to a variable speed (400-800 rpm) drill and has been

designed to De-glaze and remove uneveness from the inside surfaces of

engine cylinders up to a diameter of 180 mm.

If you do not use the tool as described, you may damage the tool or the

engine on which you are working. You may also injure yourself.

We cannot consider any warranty claim if you have used the tool in any way

other than that described in these instructions, or if you have used it for any

other purpose than that for which it is intended nor can we be held responsible

in any way for injury caused while using the tool.

Read these instructions through carefully before you use the tool.

PERSONAL PROTECTION EQUIPMENT (PPE)

The operator and any bystanders must wear eye and respiratory

protection and work gloves during use.

HOW TO USE THE 3 LEGGED GLAZE BREAKER

EXAMINE

Examine each cylinder. If they are badly scored, show signs of excessive wear,

out of true or tapered, the cylinder block will have to be re-bored and fitted

with new oversized pistons.

HONING THE CYLINDERS

1. Mount the cylinder to a study bench and secure in place.

2. Attach the tool to a suitable variable speed drill (400-800 rpm).

• Make sure that the chuck is fully tightened.

• Do this with the drill disconnected from the mains electricity supply or

compressed air line.

3. Turn the knurled nut anti-clockwise until it reaches the top of the shaft.

• This reduces the spring tension to minimum to allow easy access to the

cylinder

4. Now squeeze the three arms together and insert into the first cylinder.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

5. Release the arms.

• The arms will spring out and make contact with the walls of the cylinder.

6. Turn the knurled nut at the top of the shaft clockwise to increase the

pressure of the stones against the cylinder wall.

7. Connect the drill to the mains electricity supply or air line.

8. Pour light oil down the cylinder wall to act as a cutting lubricant and switch

on the drill, making sure you have a secure grip.

• Allow the glaze breaker to rotate inside the cylinder while moving it up

and down the cylinder. There should be a fine cross hatch pattern on the

cylinder wall with the lines intersecting at about 50° to 60° or at 20° to 35°

to the horizontal.

• Some piston manufacturers may specify a different cross hatch pattern,

so check with the instructions supplied with the new piston rings.

• Use plenty of light oil and try to remove as little metal as possible from the

cylinder wall to achieve the specified finish.

• Do not exceed the maximum speed

9. Squeeze the arms together before removing them from the cylinder.

10. Wipe the cylinder clean of excess oil and steel dust. Then block it with a

cotton cloth while you work on the other cylinders.

11. It is most important to remove all traces of the abrasive grit produced during

the honing operation. Use a suitable cleaner to clean the whole engine

block thoroughly and brush out all oil holes.

12. You can detect any remaining residues by using a clean white lint-free cloth

dampened with clean engine oil to wipe each cylinder until no dirt or grit

collects on the cloth.

13. Finally, when you have cleaned the cyclinder properly, dry it and then

lightly oil the exposed machined surfaces to prevent rust forming.

REPLACEMENT GRINDING STONES

The grinding stones are a consumable item, Replacement stones are available

from your CLARKE dealer.

WARNING: NEVER REMOVE THE TOOL FROM THE CYLINDER WHILE THE

DRILL IS RUNNING AND THE TOOL IS STILL TURNING. ALWAYS SWITCH OFF

THE DRILL AND ONLY REMOVE FROM THE CYLINDER ONCE IT HAS

STOPPED TURNING.

Type Part No: Type Part No: Type Part No:

Fine 1800905 Medium 1800906 Coarse 1800907
