Clarke CDP5EB Mode d’emploi

OPERATION & MAINTENANCE

INSTRUCTIONS

GC0513

DRILL PRESS

MODEL NO: CDP5EB/RB

PART NO: 655030 & 655035

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE Drill Press. These instructions cover the

CDP5EB (blue) and the CDP5RB (red).

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. In doing so you will ensure the safety of yourself

and that of others around you, and you can look forward to your purchase

giving you long and satisfactory service.

IMPORTANT

Please read all of the safety and operating instructions carefully before using

this product. Please pay particular attention to all sections of these instructions

that display warning symbols and notices.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

WARNING: THIS SYMBOL IS USED THROUGHOUT THE INSTRUCTIONS

WHENEVER THERE IS A RISK OF PERSONAL INJURY. ENSURE THAT

THESE WARNINGS ARE READ AND UNDERSTOOD AT ALL TIMES.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

GENERAL SAFETY RULES

GENERAL SAFETY IN THE WORKPLACE

1. ALWAYS ensure that air can circulate around the machine and that the air

vents are unobstructed.

2. ALWAYS keep work area clean & tidy. Cluttered work areas and benches

invite accidents.

3. NEVER over-reach. Keep proper footing and balance at all times.

4. NEVER store equipment in a wet/damp environment or expose to rain.

5. KEEP other persons away. Do not let persons, especially children, not

involved in the work, touch the tool or extension cable and keep them

away from the work area.

6. NEVER operate a machine when under the influence of alcohol, drugs or

medication.

7. ALWAYS ensure the workplace is well lit. Ensure that lighting is placed so

that you will not be working in your own shadow.

8. Do not use tools in the presence of flammable liquids or gasses.

9. Stay alert, watch what you are doing, use common sense and do not

operate the tool when you are tired.

CARE OF POWER TOOLS

1. Read this manual carefully. Learn the machines applications and

limitations, as well as the specific potential hazards peculiar to it.

2. ALWAYS keep guards in place and in working order. A guard or other part

that is damaged should be properly repaired or replaced by an authorised

service centre, unless otherwise indicated in this instruction manual.

3. Remove any adjusting keys or wrenches before starting. Form the habit of

checking to ensure that keys, wrenches and tools are removed from the

machine.

4. Don’t force the machine and use the correct tool. It will do the job better

and safer, at the rate for which it was intended.

WARNING: WHEN USING ELECTRIC TOOLS, BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK AND PERSONNAL INJURY INCLUDING THE FOLLOWING. READ ALL

THESE INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS PRODUCT

AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

5. ALWAYS disconnect the machine from the power supply before carrying

out any servicing or changing of accessories.

6. Before further use of the tool, it should be carefully checked to determine

that it will operate properly and perform its intended function. Check for

alignment of moving parts, binding of moving parts, breakage of parts,

mounting or other condition that may affect its operation.

7. Have defective switches repaired by an authorised service centre. Do not

use a tool if the switch does not turn it on and off.

8. ALWAYS check for any damage or any condition that could affect the

operation of the machine. Damaged parts should be properly repaired.

9. NEVER remove the cover panel unless the machine is disconnected from

the power supply, and never use the machine with cover panels removed.

10. Have your tool repaired by a qualified person. This tool complies with the

relevant safety rules. Repairs should only be carried out by qualified

persons using original spare parts, otherwise this may result in considerable

danger to the user.

11. NEVER use this product for any other purpose than that described in this

booklet.

12. NEVER abuse the power cable by yanking the cable to disconnect it from

the socket. Keep the cable away from heat, oil or sharp edges.

13. Guard against electric shock. Avoid body contact with earthed or

grounded surfaces.

14. If the tool should be used outdoors, use only extension cables intended for

outdoor use and marked accordingly.

15. Avoid accidental starting by making sure the power switch is off before

plugging in the power cable.

ADDITIONAL SAFETY RULES FOR DRILL PRESSES

1. IMPORTANT: You should not operate this machine unless you are thoroughly

familiar with drilling machines and drilling techniques. If there is any doubt

whatsoever you should consult a qualified person.

2. NEVER operate the machine until it is completely assembled and you have

read and understood this entire manual.

CAUTION: AS WITH ALL MACHINERY, THERE ARE CERTAIN HAZARDS

INVOLVED WITH THEIR OPERATION AND USE. EXERCISING RESPECT AND

CAUTION WILL CONSIDERABLY LESSEN THE RISK OF PERSONAL INJURY.

HOWEVER, IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED, OR

IGNORED, PERSONAL INJURY TO THE OPERATOR, OR DAMAGE TO

PROPERTY MAY RESULT.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

3. ALWAYS use clamps or a drill vice bolted to the table, to hold the work. It

should never be held with bare hands.

4. ALWAYS shut off the power & remove drill bit before leaving the machine.

5. ALWAYS make all adjustments with the power off.

6. ALWAYS use the correct drilling speeds for the drill size and the type of

material being drilled.

7. NEVER leave the drill unattended whilst it is running. Turn the machine OFF

and do not leave until it has come to a complete stop.

8. ALWAYS remove and store the drill bits when you have finished work.

9. NEVER attempt to drill into a workpiece that does not have a flat surface

unless a suitable support is used.

10. ALWAYS stop the drill before removing workpieces, work supports or swarf

from the table.

11. Keep drills sharp and clean for best and safest performance. Follow

instructions for changing accessories.

12. Adjust the table or depth stop to avoid drilling into the table surface.

13. ALWAYS be sure that the drill bit is securely locked in the chuck.

14. NEVER assemble or set up any work on the table while the drill is running.

15. ALWAYS ensure the table lock is tight before starting the drill.

16. Keep handles dry, clean and free from oil and grease.

17. ALWAYS keep hands and fingers away from the drill bit.

PROTECTIVE CLOTHING

1. Dress properly. Loose clothing or other jewellery may get caught in moving

parts. Non-slip footwear is recommended. Wear protective hair covering to

contain long hair..

2. ALWAYS wear safety glasses. (Everyday glasses are not safety glasses.)

3. Wear a face mask if drilling into any material which produces dust.

WARNING: DUST GENERATED FROM CERTAIN MATERIALS CAN BE

HAZARDOUS TO YOUR HEALTH. ALWAYS OPERATE THE DRILL IN A WELL

VENTILATED AREA. USE A DUST COLLECTION SYSTEM IF POSSIBLE.

WARNING: THE USE OF ANY ACCESSORY OR ATTACHMENT OTHER THAN

ONE RECOMMENDED IN THIS INSTRUCTION MANUAL MAY PRESENT A RISK

OF PERSONNAL INJURY.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ELECTRICAL CONNECTIONS

Before switching the product on, make sure that the voltage of your electricity supply is

the same as that indicated on the rating plate. This product is designed to operate on

230VAC 50Hz. Connecting it to any other power source may cause damage.

This product may be fitted with a non-rewireable plug. If it is necessary to change the

fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or

damaged, the plug must not be used until a suitable replacement is obtained.

If the plug has to be changed because it is not suitable for your socket, or due to

damage, it should be cut off and a replacement fitted, following the wiring instructions

shown below. The old plug must be disposed of safely, as insertion into a mains socket

could cause an electrical hazard.

If the colours of the wires in the power cable of this product do not correspond with the

markings on the terminals of your plug, proceed as follows.

If the colours of the wires in the power cable of this product do not correspond with the

markings on the terminals of your plug, proceed as follows.

• The wire which is coloured Blue must be connected to the terminal which is

marked Nor coloured Black.

• The wire which is coloured Brown must be connected to the terminal which is

marked Lor coloured Red.

• The wire which is coloured Yellow and Green must be connected to the

terminal which is marked E or or coloured Green.

We strongly recommend that this machine is connected to the mains supply via a Residual

Current Device (RCD)

If in any doubt, consult a qualified electrician. DO NOT attempt any repairs yourself.

WARNING! Read these electrical safety instructions thoroughly

before connecting the product to the mains supply.

WARNING! The wires in the power cable of this product are

coloured in accordance with the following code:

Blue = Neutral Brown = Live Yellow and Green = Earth

Plug must be BS1363/A approved.

Always fit a 13 Amp fuse.

Ensure that the outer sheath of the cable is firmly held by the clamp

Neutral

(Blue)

Live

(Brown)

Earth

(Green and Yellow)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

PRODUCT OVERVIEW

NO DESCRIPTION NO DESCRIPTION

1 Head & Motor Assembly 7 Chuck Key

2 Column 8 Feed Handles (x 3)

3Base 9Bolts(x3)

4 Table 10 Table Locking Handle

5 Chuck Guard Assembly 11 Depth Stop Assembly

6 Chuck 12 Hex Key

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

UNPACKING

The drill press is delivered with the components shown on page 7.

Check the parts against the above list. Should there be any deficiencies or

damage, you should contact your CLARKE dealer immediately where the

product was originally purchased. Do not discard the packaging until the

machine is assembled. The packaging consists of cardboard and

appropriately marked materials which can be sent tp a re-cycling facility.

To protect the machine parts from moisture, a protective coating of light

machine oil will have been applied to the outside surfaces. Remove any

excess with a paper towel.

Take care when lifting the head assembly, considering its weight.

Before use, the machine must be mounted, and securely bolted, to a strong,

heavy workbench, of sufficient height that you will be standing upright when

working.

Ensure the work place is adequately lit, and that you will not be working in your

own shadow.

ASSEMBLY

COLUMN TO BASE

Bolt the column assembly to the base with the three bolts provided.

NOTE: Ideally, the base with column attached, should be firmly bolted to

the workbench, prior to the assembly of other components.

TABLE TO COLUMN

1. Thread the table locking handle

into the table support from the

right hand side and leave it loose

at this stage.

2. Slide the table support with the

table, over the column, and allow

it to rest against the base as

shown in Fig.1.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

HEAD TO COLUMN

NOTE: It may be necessary to

unscrew both the head

locking set screws

slightly, to ensure they do

not protrude internally,

as this would prevent the

head from sliding fully

into position.

1. Lift the head assembly and

locate it on top of the

column, ensuring it slides

home fully.

2. Align the head with the base, and

firmly secure to the column with

the set screws as shown in Fig. 2.

Tighten with the hex key supplied.

3. Screw the three feed handles,

firmly into the hub of the feed

shaft shown in Fig. 3.

CHUCK GUARD ASSEMBLY

This task should be carried out before

the chuck is installed.

1. Slide the chuck guard support

over the Quill Shaft and nip up the

pinch bolt at the rear of the

assembly shown in Fig 4.

2. Assemble the transparent guard

to the guard support using the

small bolt/nut and the two small

screws provided. (A small x-head

screwdriver will be required.)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ASSEMBLING THE DEPTH STOP

1. Slide the end of the threaded rod

through the bracket on the side of

the head and through the hole in

the top of the chuck guard

support as shown in Fig 5.

2. Secure with the nut provided,

from beneath, locking the Depth

Stop to the Chuck Guard and the

spindle assembly. (In use, as the

spindle is moved downwards, the

depth stop will move by the same

amount).

3. Add the two adjuster nuts to the

depth stop and slide the pointer

to the tip of the stop rod as shown

in Fig 6. The pointer may be

zeroed by sliding it up or down on

its mounting.

INSTALLING THE CHUCK

1. With the chuck guard lifted clear

of the spindle nose, slide the work

table up the column to within 6" of

the spindle.

2. Open the jaws of the chuck to

their maximum, using the chuck

key supplied.

3. Put a piece of scrap wood on the

table to protect the chuck nose

as shown in Fig 7.

4. Ensuring all parts are thoroughly clean, dry, and burr free, place the chuck

over the end of the spindle and pull the spindle down using the feed

handles, pressing the chuck jaws hard against the piece of scrap wood

until the chuck is forced home. Discard the scrap wood.

5. When the chuck is installed, turn the chuck guard around so that the shield

is facing the front, and tighten the pinch bolt to secure it in position.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Clarke Outils électriques

Clarke

Clarke CCIW160 Manuel d'installation et d'exploitation

Clarke

Clarke DHC-2 Mode d’emploi

Clarke

Clarke CAT211 Manuel d'installation et d'exploitation

Clarke

Clarke Metalworker CDP350V Manuel d'installation et d'exploitation

Clarke

Clarke CAT50 Manuel d'installation et d'exploitation

Clarke

Clarke Metalworker CDP202B Mode d’emploi

Clarke

Clarke CONTRACTOR CON800 Manuel d'installation et d'exploitation

Clarke

Clarke CAT52 Manuel d'installation et d'exploitation

Clarke

Clarke PRO236 Manuel d'installation et d'exploitation

Clarke

Clarke X-Pro CAT205 Manuel d'installation et d'exploitation

Clarke

Clarke CHT259 Mode d’emploi

Clarke

Clarke cp185 Manuel d'installation et d'exploitation

Clarke

Clarke CAT126 Manuel d'installation et d'exploitation

Clarke

Clarke DU8 Manuel utilisateur

Clarke

Clarke Metalworker CDP101B Manuel d'installation et d'exploitation

Clarke

Clarke CAT84 Guide de dépannage

Clarke

Clarke CAT22B Manuel d'installation et d'exploitation

Clarke

Clarke CHT674 Manuel utilisateur

Clarke

Clarke CIR450C Manuel d'installation et d'exploitation

Clarke

Clarke CAT134 Manuel d'installation et d'exploitation

Clarke

Clarke Air TPG30PTC Manuel utilisateur

Clarke

Clarke CPSB100B Mode d’emploi

Clarke

Clarke CSG1C Mode d’emploi

Clarke

Clarke CPSB1 Mode d’emploi

Manuels Outils électriques populaires d'autres marques

AEG

AEG OMNI-JS Manuel utilisateur

SIP

SIP 01533 Manuel utilisateur

Ribimex

Ribimex PRS499 Manuel utilisateur

3M Fiber Optic Connector Crimp Tool Manuel utilisateur

Ryobi

Ryobi P524 Manuel utilisateur

ROJEK

ROJEK FSN 300A Manuel utilisateur

Kemper

Kemper 1740PRO Manuel utilisateur

WABCO

WABCO OptiTire Manuel utilisateur

EINHELL

EINHELL TE-MS 18/210 Li Manuel utilisateur

Orgapack

Orgapack OR-T 85 Guide rapide

TOUGHCUT

TOUGHCUT Diamond 400 Manuel utilisateur

Yaros

Yaros PB-3603 Manuel utilisateur

Fein

Fein BSS 2.0 E Guide de configuration

Baileigh Industrial

Baileigh Industrial SS-2725 Manuel utilisateur

Milwaukee

Milwaukee 2674-20 Manuel utilisateur

Fein

Fein BLs 1.6 Manuel utilisateur

Princess

Princess Electric Multi Sharpener Manuel utilisateur

FOREDOM

FOREDOM K.1050 Manuel
