Clarke CSA10F Manuel

MAINTE

OPERATING & MAINTENANCE

INSTRUCTIONS

10 TON

HYDRAULIC PRESS

Model Nos. CSA10F and CSA10B

0200

Please contact your nearest dealer, or

CLARKE International, on one of the following numbers.

PARTS & SERVICE TEL: 020 8988 7400

PARTS & SERVICE FAX: 020 8558 3622

or e-mail as follows:

PARTS: [email protected]

SERVICE: [email protected]

SPARE PARTS and SERVICING

Thank you for purchasing this CLARKE 10 Ton Hydraulic Press.

Please read this manual thoroughly and follow the instructions carefully, in doing

so you will ensure the safety of yourself and that of others around you, and you can

look forward to the press giving you long and satisfactory service.

Please note that this manual is an integral part of the Hydraulic Press and must

always accompany it, even in the event of sale.

The press owner and/or user must read and fully understand the operating

instructions and recommendations before using this press.

CLARKE International shall not be held liable to any damage to persons or

equipment due to improper or non-permitted use of the press.

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt as proof of purchase.

This guarantee is invalid if the product is found to have been abused or tampered

with in any way, or not used for the purpose for which it was intended.

Faulty goods should be returned to their place of purchase, no product can be

returned to us without prior permission. This guarantee does not effect your

statutory rights.

SAFETY PRECAUTIONS

•During assembly or if the press is moved, ALWAYS use a lifting appliance -

crane or hoist etc., do not man handle.

• The press MUST BE located on firm level ground, or a sturdy workbench, with

adequate light. The operator must never work in his/her own shadow.

• Before applying a load, be certain that all press bed support pins are fully

engaged, and the hydraulic ram is fully located into the ram mount. Ensure

also that hydraulic hoses and couplings are completely sound.

• Before use always ensure the workpiece is firmly secure and stable.

• Always clean spills of hydraulic oil immediately as this can be extremely

dangerous in a workshop environment.

• Do not exceed the rated capacity.

• Do not allow any person, who is inexperienced in the use of hydraulic presses,

to use the machine unless they are under direct supervision.

• Do not allow anyone to work directly in front of the machine when it is in use.

• Never tamper with the machine. The safety valve is calibrated and sealed at

the factory, do not attempt to change these settings.

•UseONLY the recommended hydraulic oil.

• Never use the machine for any purpose other than that for which it is

designed.

• Components of this press are specially designed to withstand the rated

capacity. Do not substitute bolts, pins, or any other components.

• Always apply the load on the centre of ram plunger. Offset loads can

damage the ram or ram mount and may cause work piece to eject.

• Before operating, check for signs of cracked welds, bent bed pins, loose or

missing bolts, or any other structural damage. Do not operate if any of these

conditions exist. Have repairs made only by authorised service centres.

• Remove all loads from press bed before attempting to adjust bed height.

Beware of possible falling bed.

• Press only on a work piece supported by the press bed.

• When using accessories such as arbor plates, be certain they are centered

on press bed, and are in full contact with the bed.

• Parts being pressed may splinter, shatter, or be ejected from the press. Due to

varied applications, it is your responsibility to always use adequate guards,

wear eye protection and heavy protective clothing when operating this press.

• Keep hands and fingers out of the press and away from the parts that may

pinch and shift.

• It is the owners responsibility to keep warning decals legible and intact.

Replacement decals may be obtained from Clarke International Spare Parts

Dep’t.

• Failure to heed these warnings may result in damage to the equipment, or

failure resulting in property damage, personal, or even fatal injury.

• NEVER operate the ram without the bed locating pins fully in place.

• DO NOT use extension tubes on the pump handle. Excessive effort can cause

severe damage.

ASSEMBLY

A. CSA10F

Fig.1

HYDRAULIC PUMP/RAM OPERATION

Ensure the press and its components

suffered no damage during transit.

Should any damage be apparent,

contact your Clarke dealer

immediately.

1. Attach the feet and foot struts

to the side supports using the

nuts, bolts and washers

provided, leaving them finger

tight.

2. Raise the assembly and rock it

to ensure that no part is under

stress and that the structure is

completely stable before

tightening all nuts securely.

3. Feed the ram assembly down

through the hole in the top

plate and screw it fully into the

threaded hole in the bottom

plate. The pressure gauge at

this point should be facing the

front.

4. Attach the pump assembly to

the frame by hooking the front

edge into the recess in one

end of the pump platform and

securing at the opposite end

with the screws provided.

Finally, screw on the hose

assembly to the ram inlet.

Your Hydraulic Press is now ready

for use.

1. Bolt the feet to the side

members using the nuts

bolts and washers provided.

2. Bolt on the top and bottom

plates in the manner shown

in fig. 2 , ensuring the bottom

plate is that with the

threaded hole at its centre.

Do not fully tighten the nuts.

3. Feed the ram assembly

down through the hole in

the top plate and screw it

fully into the threaded hole

in the bottom plate. The

pressure gauge at this point

should be facing the front.

Centralise the ram between

the top rails before

tightening the securing bolts

It is strongly recommended that

the Bench Press be securely

bolted to a sturdy workbench

Fig.2

The pump is provided with handwheel , which opens or closes a valve in the pump

to raise the ram or lower it under pressure.

Turn the handwheel clockwise and pump the handle to operate (or lower) the

ram. Turning the handwheel anticlockwise releases the pressure and the ram will

rise.

HYDRAULIC PUMP/RAM OPERATION

B. CSA10B

OPERATION

1. Position the bed to the desired height, so as it will be as close as possible to the

ram when the workpiece is mounted.

Raise one side of the bed, and insert a pin into a locating hole directly

beneath the bed. Repeat the process at the other side, until the bed is level

and at the desired height, with the pins fully ‘home’.

2. The workpiece is placed on top of the bed, or on top of the arbour, or clover

leaf, plate and must be completely stable. To achieve this you must use

packing or shims where required.

NOTE: Any packing pieces or shims used, MUST be capable of withstanding the

extreme pressure that will be brought to bear, and MUST be of sufficient size with

sufficient surface contact, so as to avoid the possibility of slipping or springing

taking place. Mating surfaces MUST be horizontal so that the force being exerted

will be vertical and NOT at an angle.

3. Two Mandrels are provided, either of which should be screwed to the end of

the Ram, depending upon the size of workpiece bearing surface. One of

these is ‘stepped’ and is shown fitted at B1, Figs.1 and 2. The other has a larger

bearing surface area and is shown at B2.

3. Turn the Pump Handwheel, fully clockwise and pump the handle to bring the

ram very lightly into contact with the workpiece.

Manoeuvre the workpiece so that the desired point of contact is directly

beneath the centre of the ram.

4. When satisfied that the workpiece is correctly lined up and is completely

stable in that position, slowly pump the handle so that the ram begins to exert

pressure on the workpiece.

Continue to pump the handle, whilst standing to the side of the press (DO

NOT stand directly in front of the work), and constantly monitor the process,

ensuring the ram and work remain completely in line, and there is no risk of

slipping.

5. When the process is complete, turn the Pump Handwheel anticlockwise to

release ram pressure

MAINTENANCE

A Visual inspection must be made before each use of the press, checking for

leaking hydraulic fluid, and damaged, loose or missing parts.

Owners and/or users should be aware that repair of this equipment may require

specialised knowledge and facilities. It is recommended that a thorough annual

inspection of the press be made and that any defective parts, decals or warning

labels be replaced with genuine Clarke parts.

Any press which appears to be damaged in any way, is found to be badly worn,

or operates abnormally SHOULD BE REMOVED FROM SERVICE until necessary repairs

are made.

• Periodically check the press frame to make sure all bolts are tight and inspect

for cracked welds, bent, loose or missing parts.

• Periodically check the hydraulic connections for possible leaks. Replace or

properly repair damaged or leaking hydraulic components before using.

• Periodically apply a light smear of oil to the moving parts and the bed support

pins.

• If oil leaks, caused by a loose union/connection etc., have been repaired,

check the hydraulic pump oil level, by removing the pump from its mounting,

holding it vertically on its nose, and removing the filler/dipstick, shown at ‘A’,

Fig.1. Top up if necessary to the level on the dipstick, with CLARKE Hydraulic

Oil, Part No. 3050830 only.

This operation is carried out with the ram fully retracted.

• Replace the Hydraulic oil every TWO years. This operation requires the

dismantling of the hydraulic system, for which you should consult your CLARKE

dealer.

PARTS DIAGRAM - CSA10F

No. Description Qty Part No.

1 Frame 1 CSA1001

2 Frame 1 CSA1002

3 Bridge 2 CSA1003

4 Bolt M12 8 CSA1004

5 Spring Washer 8 CSA1005

6 Nut M12 8 CSA1006

7 Union Support 1 CSA1007

8 Base Supports 2 CSA1008

9 Bolt 5/16” X 1” 12 CSA1009

10 Spring Washer 12 CSA1010

11 Nut 5/16” 12 CSA1011

12 Support Plates 4 CSA1012

13 Pump Support 1 CSA1013

14 Bolt 3/8 x 1” 4 CSA1014

15 Spring Washer 6 CSA1015

16 Nut 3/8” 6 CSA1016

17 Support Plates 1 CSA1017

18 Ram Support 1 CSA1018

19 Bolt 3/8 x 6” 2 CSA1019

20 Washer 4 CSA1020

21 Support pins 2 CSA1021

22 Bed Flat 1 CSA1022

23 Arbour Plates 2 CSA1023

24 Ram compl. 1 CSA1024

25 Adapter 1 CSA1025

26 Adapter 1 CSA1026

27 Pump compl. 1 CSA1027

- Seal Kit 1 CSA1028

No. Description Qty Part No.

PARTS DIAGRAM - CSA10B

No. Description Qty Part No.

1 Frame 1 CSA10B01

2 Foot 2 CSA10B02

3 Bolt M10 4 CSA10B03

4 Flat Washer 12 CSA10B04

5 Spring Washer M10 6 CSA10B05

6 Nut M10 6 CSA10B06

7 Bottom Plate 1 CSA10B07

8 Top Plate 1 CSA10B08

9 Bolt M10 2 CSA10B09

No. Description Qty Part No.

10 Support Pins 2 CSA10B10

11 Bed 1 CSA10B11

12 Arbour Plate 1 CSA10B12

13 Ram Assembly 1 CSA10B13

14 Pump Assembly 1 CSA10B14

15 Mandrel 1 CSA10B15

16 Mandrel Stepped 1 CSA10B16

- Seal Kit 1 CSA1028

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Clarke Outils électriques

Clarke

Clarke CHT 459 Manuel utilisateur

Clarke

Clarke PRO235 Manuel d'installation et d'exploitation

Clarke

Clarke Metalworker CDP350V Manuel d'installation et d'exploitation

Clarke

Clarke CDP10B Mode d’emploi

Clarke

Clarke Air CAT232 Manuel d'installation et d'exploitation

Clarke

Clarke Contractor CON15 Manuel d'installation et d'exploitation

Clarke

Clarke CMPS2 Mode d’emploi

Clarke

Clarke CAT209 Manuel d'installation et d'exploitation

Clarke

Clarke CAT108 Manuel d'installation et d'exploitation

Clarke

Clarke CMFT250 Manuel d'installation et d'exploitation

Clarke

Clarke STRONG-ARM CSA50FP Guide de dépannage

Clarke

Clarke Air CAT149 Manuel d'installation et d'exploitation

Clarke

Clarke CDP10B Manuel d'installation et d'exploitation

Clarke

Clarke Air 25CN Manuel d'installation et d'exploitation

Clarke

Clarke CHT879 Manuel utilisateur

Clarke

Clarke CAT221B Mode d’emploi

Clarke

Clarke ECSS-1 Guide de l'utilisateur

Clarke

Clarke Strong-Arm GC0915 Mode d’emploi

Clarke

Clarke CPR2 Manuel d'installation et d'exploitation

Clarke

Clarke 6505512 Mode d’emploi

Clarke

Clarke Metalworker CDP101B Manuel d'installation et d'exploitation

Clarke

Clarke CAT50 Manuel d'installation et d'exploitation

Clarke

Clarke CBM 2 Manuel d'installation et d'exploitation

Clarke

Clarke X-Pro CAT199 Manuel d'installation et d'exploitation

Manuels Outils électriques populaires d'autres marques

AEG

AEG OMNI-JS Manuel utilisateur

SIP

SIP 01533 Manuel utilisateur

Ribimex

Ribimex PRS499 Manuel utilisateur

3M Fiber Optic Connector Crimp Tool Manuel utilisateur

Ryobi

Ryobi P524 Manuel utilisateur

ROJEK

ROJEK FSN 300A Manuel utilisateur

Kemper

Kemper 1740PRO Manuel utilisateur

WABCO

WABCO OptiTire Manuel utilisateur

EINHELL

EINHELL TE-MS 18/210 Li Manuel utilisateur

Orgapack

Orgapack OR-T 85 Guide rapide

TOUGHCUT

TOUGHCUT Diamond 400 Manuel utilisateur

Yaros

Yaros PB-3603 Manuel utilisateur

Fein

Fein BSS 2.0 E Guide de configuration

Baileigh Industrial

Baileigh Industrial SS-2725 Manuel utilisateur

Milwaukee

Milwaukee 2674-20 Manuel utilisateur

Fein

Fein BLs 1.6 Manuel utilisateur

Princess

Princess Electric Multi Sharpener Manuel utilisateur

FOREDOM

FOREDOM K.1050 Manuel
