BasIP AV-01KD Manuel utilisateur

AV-01KD

Exported on 08/12/2019

– 2
Table of Contents
Device description................................................................................................ 5
Appearance.....................................................................................................................................5
Technical parameters.......................................................................................... 6
Main features ................................................................................................................................. 6
Funcitonal capabilities ............................................................................................................... 6
Configuration through WEB interface...........................................................7
Login ..................................................................................................................................................7
Main ....................................................................................................................................................7
Network info ...................................................................................................................................................................8
Network ........................................................................................................................................... 9
Custom NTP....................................................................................................................................................................9
Panel ................................................................................................................................................. 9
Apartment settings ......................................................................................................................................................9
SIP settings....................................................................................................................................................................10
Call settings.................................................................................................................................................................... 11
Device settings ............................................................................................................................................................ 12
Access ............................................................................................................................................. 12
Common settings........................................................................................................................................................ 13
Locks management.................................................................................................................................................... 13
Open lock....................................................................................................................................................................... 14
Additional settings ..................................................................................................................................................... 14
Identifiers ....................................................................................................................................................................... 14
New identifier ............................................................................................................................................................... 15
Forward ..........................................................................................................................................16
Forward settings......................................................................................................................................................... 16
New forward queue ................................................................................................................................................... 16
Advanced....................................................................................................................................... 18
System ............................................................................................................................................18
Settings........................................................................................................................................................................... 19
Device language.......................................................................................................................................................... 19
Reboot ............................................................................................................................................................................ 19

– 3
Installation and connection.............................................................................20
Completness check of the product ....................................................................................20
Electrical connection................................................................................................................20
Mechanical mounting ................................................................................................................ 21
Connection of additional modules...................................................................................... 23
Usage of the device ...........................................................................................24
Getting the RTSP stream from the camera of the outdoor panel ..........................24

– 4

•Device description(see page 5)

•Technical parameters(see page 6)

•Configuration through WEB interface(see page 7)

•Installation and connection(see page 20)

•Usage of the device(see page 24)

Device description– 5

Device description

AV-01K is an individual call panel with a code set. This panel can operate in two modes -

individual and multi apartment. In the individual mode, the keypad panel serves as a keypad for

opening the lock, and using the direct call button, you can communicate with the desired

monitor.

Appearance

Technical parameters– 6

Technical parameters

Main features

Panel Type:Individual

Display:No

Camera:1/4 ", adjustable camera angle by 15 °

Viewing angle:Horizontal 100 °, vertical 52 °

Camera resolution:1 MP

Output video:720p (1280x720), H.264 Main Profile

Night backlight:6 LEDs

Minimum illumination:0.01 LuX

Protection class:IP65

Temperature range:-40 - +65 ° С

Power consumption:5.5 W, standby 2.5 W

Power supply:+ 12 volts

Body:Metallic

Color solution:titanium gray

Dimentions for installation:104 × 180 × 60 mm

The size of the panel itself:115 × 190 × 45 mm

Installation Type:Flush, surface with BR-AV bracket

Funcitonal capabilities

Interface:Russian / English, WEB – interface

Opening the lock:From the monitor, via the BAS-IP Intercom application

ACS Integration:No

Shortcut buttons:1 mechanical call button, keypad

Number of call melodies:4 polyphonic melodies

Authentication:Separate password for settings, WEB – interface

Talk mode:Duplex

Optional:SIP P2P, Built-in Relay

Configuration through WEB interface– 7

Configuration through WEB interface

•Login(see page 7)

•Main(see page 7)

•Network(see page 9)

•Panel(see page 9)

•Access(see page 12)

•Forward(see page 16)

•Advanced(see page 18)

•System(see page 18)

To configure the call panel remotely via the WEB interface, you need to connect to it with an

Internet browser on your PC. The panel must be connected in the same network segment as the

PC from which it is planned to perform the configuration.

To find the device in the LAN it is required to use Remote search and upgrade tool.

In the Internet browser, in the address entry box, you must enter the IP address of the panel,

after which the user name and password entry window will appear.

Username to enter the settings: admin.

The password required for entry corresponds to the password for access to the settings of the

call panel and is the installer password (default password: 123456).

Main

After successful authorization, the following interface will be displayed:

Configuration through WEB interface– 8

Device info

Framework:A version of the framework.

Launcher:A version of the launcher.

Network info

DHCP:Current DHCP status.

IP адрес:Current IP address of the device.

Subnet mask:Used subnet mask.

Gateway:Gateway address.

DNS server:DNS server address.

MAC address:Physical address of the device.

Configuration through WEB interface– 9

Network

DHCP: Enable/disable the automatic retrieval of network settings.

IP: Panel IP address.

Mask: Subnet mask.

Gateway: The main gateway.

DNS: DNS server address.

Custom NTP

Current device date/time:Shows the current device's date and time.

URL:Field to enter custom NTP server address.

Timezone:Choose used timezone.

Panel

Apartment settings

By default, the call panel can have a static IP address 192.168.1.90 or 192.168.1.91.

Configuration through WEB interface– 10

Mode: Selection of the panel operation mode.

Building: Building number.

Unit:Unit number.

Floor: Floor number.

Apartment.: Apartment number.

No: Order number of the call panel.

SIP settings

To work in the multi-apartment panel mode, with the ability to dial an apartment using

the keyboard, you need to select the "Unit Panel". In this mode, the call button will work

as a concierge call button.

To work in the individual panel mode, with the ability to dial the lock opening code

using the keyboard, you must select the "Personal Panel". In this mode, the call button

will work for its intended purpose. The building number, front door, floor, and

apartment must correspond to the internal monitor, which will receive an incoming call

from this call panel.

If you have several call panels that have one logical address, then in the "No." field

specify the value 2, 3, 4, 5, etc., up to 9.
