AWS ECOWEIGH Series Manuel utilisateur
ECO-5K (5000g x 1g)
User Manual
ECO-5K
Copyright © 2011 American Weigh Scales, Inc.
All rights reserved. Rev. 1.0
ECOWEIGH Series
ECO-5K
Thank you for purchasing the American Weigh ECO-
5K digital kitchen scale. Please read all operating instructions
carefully before use. Scales are precision measuring devices
and should always be handled with proper care. To ensure
years of reliable service, keep these simple tips in mind:
• Do not exceed the scale’s maximum capacity. This scale
has integrated overload protection, but any overload
protection has its limits.
• Avoid weighing in extreme heat or cold. Scales perform
best at normal room temperature.
• This scale has been calibrated at the factory. Only
advanced users should attempt recalibration using the
speciedcalibrationmasses.
• Store your scale in a clean, dry location. Dust, dirt, and
moisture can accumulate on the weighing sensors and
electronics causing inaccuracy or malfunction.
• Keep the area around and under the scale clean. Loose
debris under the scale can push against the base causing
inaccuracy.
• Avoid using your scale in close proximity to strong radio
wave emitting devices such as cordless phones.
• Alwaysweighonaatandlevelsurface,freefrom
vibrations and drafts. The corner of a room is usually the
most stable.
• Gently apply all items to be weighed. Do not drop items
onto the weighing platform. Overload protection does not
protect the sensor from shock loading.
• Avoid dropping your scale. The warranty does not cover
damage due to rough treatment or overload.
• Checkthebatteriesrstifyouarehavinganytroublewith
your scale. This simple step can remedy most scale issues.
I. Part List
1. Scale
2. CR2032 Batteries (x2)
II. Key Description
1. ON/OFF/Tare Key - Tap to turn on or re-zero the scale (if
already on). Hold to turn the scale off.
2. Unit Key - Changes the displayed unit of measure
III. Battery Installation
1. Beforeusingthescaleforthersttime,checkthebattery
compartment and remove any plastic insulation strips or
packaging that may be in place to prevent battery drainage
during shipping/storage.
2. If you are replacing the batteries, make sure the positive
and negative contacts are properly aligned:
1.
2.
Install Both
CR2302 Batteries
Positive Side Up
Unit T
ECO-5K
IV. Scale Operation
1. Placethescaleonaat,levelsurface.
2. Tap the
T
key to turn the scale on.
3. Once the scale displays zero, you are ready to weigh.
4. Place items to be weighed on the center of the scale
platform.
5. Whenyouarenishedweighing,youcanturnthescaleoff
by holding the
T
key for 2 seconds.
V. Using the Tare Feature
You can use this scale’s tare feature to subtract the weight of an
empty container or vessel to weigh only the contents. NOTE: The
weight of the container will subtract from the available capacity.
1. Place the empty container or vessel on the weighing
platform.
2. Press the
T
key once. The display will then reset
to zero. If the container is removed, its weight will be
displayed as a negative number.
3. Youmaynowllthecontainerwiththequantitytobe
weighed. The display will show just the weight of the
contents.
4. To return to normal weight display (gross weight), remove
any items from the weighing platform and press the
T
key again to re-zero the scale.
VI. Changing the Unit of Measure
1. Press the Unit key to change the scale’s displayed unit of
measure.
2. If the scale is turned off then back on, it will default to the
last unit used.
• ECO-5K Units: g (gram) lb:oz (pound:ounce) oz (ounce)
ml (milliliter) .oz.(uidounce-US)
VII. Calibration Adjustment (Advanced Users Only)
Calibration is performed at the factory. Only advanced users
should attempt calibration if the scale is not weighing properly.
1. Turn the scale on and wait for zero to be displayed.
2. Tap the
T
key four times, holding the key on the last
tap. A random number will be displayed.
3. With no weight on the scale, tap the
T
key again to set
the zero point. After a couple of seconds the display will
show “ZERO” followed by “0000” (±2).
4. Place a 2000g calibration weight on the center of the
platform. After a couple of seconds the display will show
“CAL1” followed by another random number (ISN).
5. Now place a total of 5000g on the center of the scale
platform. The display will show “CAL2” then “5000g”.
Calibration is complete!
ECO-5K
VIII. Error Codes
1. Symbol - Batteries are low. Replace the batteries.
2. EEEE- Maximum capacity exceeded. This scale cannot be
used to give measurements over 11lbs (5kg).
IX. Specications
ECO-5K
Max. Capacity 5000g/176.4oz/5000ml/169.oz/11lb
Readability 1g/0.1oz/1ml/0.1.oz/0.1oz
Calibration Weights 2000g, 5000g (not included)
Power 2 x CR2032 Lithium Batteries (included)
Auto-Off Time 120SecondsofNon-Use
Dimensions 5.9 x 9.0 x 0.6”
Display Size 0.9 x 2.2”
Warranty 10 Year Limited Warranty
American Weigh Scales, Inc.
Norcross,GA30092,U.S.A
MadeinChinatoourexactspecicationsandqualitycontrol.
