AWS Bioweich USB Manuel utilisateur

330lb x 0.2lb

150kg x 0.1kg

USB Body Fat Scale

BioWeigh-USB Manual

Thank you for purchasing the American Weigh BioWeigh-

USB Body Fat Scale. Please read all operating instructions

carefully before use. Scales are precision instruments and

should always be handled with care.

Special Note on Body Fat Scales

Body fat scales and analyzers use bioelectrical impedance

analysis (BIA) technology to calculate body fat %.

This technology works by measuring the resistance

(impedance) of small electrical currents through your body.

When the user’s height and body impedance are known,

the scale can accurately determine total body water (TBW)

and fat-free mass (FFM). Fat-free mass is then subtracted

from your total body weight to obtain your body fat mass.

This scale should be used while barefoot. Measurement

errors can arise if weighing while wearing socks or

pantyhose. To avoid slipping, do not step on the scale with

wet feet. Do not use the scale on carpet.

Although BIA method uses a safe, low level of electrical

current, users with pacemakers or other electric

medical devices or implants should not operate this

scale.

I. Display Overview

II. Icon Descriptions

Icon

Description Male Athelete Female Body Fat Water

Icon

Description Muscle Bone Low

Batteries Age

III. Key Functions

kcal

cm ft

UP KEY SET KEY DOWN KEY

SET DOWN

kcal

cm ft

UP KEY SET KEY DOWN KEY

SET DOWN

IV. Battery Installation

This scale should come with batteries in the box. To

install the batteries, turn the scale over and remove the

battery cover. Insert two (2) AAA batteries according to

the diagram inside the battery compartment. Replace the

battery cover.

V. Turning the Scale On and O

This scale has a “tap to weigh” function. First tap the

scale with your foot to wake it from sleep mode before

weighing.

VI. Setting the Weighing Unit

To change the current weighing unit, use the “kg/st/lb”

button on the bottom of the scale. The display can change

between kg -> lb -> st.

VII. Setting the Clock

Press and hold t• he SET key to enter clock setup.

The year will being to ash. Use the UP and DOWN key•

to select the current year then press SET to conrm.

The month will being to ash. Use the UP and DOWN•

key to select the current year then press SET to conrm.

The day will being to ash. Use the UP and DOWN key•

to select the current year then press SET to conrm.

The hour will being to ash. Use the UP and DOWN key•

to select the current year then press SET to conrm.

The minute will being to ash. Use the UP and DOWN•

key to select the current year then press SET to conrm.

VIII. Basic Weighing

Tap the scale with your foot to turn it on.•

Wait for “0.0” to be displayed then step on the platform.•

Once stable, your weight will be displayed.•

IX. Entering Personal Data

Before you can obtain a body fat analysis, you must rst

enter your user data including sex, height, and age:

Turn the scale on and press the UP or DOWN key on the•

scale to enter User Select Mode.

Select the relevant user using the UP and DOWN keys.•

The sex, height, and age for the current user will be

displayed.

Press SET to edit sex. Use the UP and DOWN keys•

change the value.

Press SET to edit height. Use the UP and DOWN keys•

change the value.

Press SET to edit age. Use the UP and DOWN keys•

change the value.

Press SET to conrm.•

You may now stand on the scale’s metal contacts•

(barefoot).

Your weight will be displayed briey then the scale will•

begin body fat analysis. During this time, a oating 0

will be displayed.

If successful, the display will show Body Fat -> Water ->•

Muscle -> Bone -> Weight. After 3 cycles, the scale will

turn itself o.

NOTE: Your user data is automatically saved to the scales

internal memory, ready for upload to your computer. The

scale can track the weight and body composition of up to

10 users (one daily record per user). Each record includes

year, month, day, weight, body fat, water, muscle, and

bone.

X. WeightTrak Software Installation

Insert the included CD into your computer and follow•

the on-screen instructions to install.

Refer to the WeightTrak_UserGuide.pdf on the CD for•

instructions using the WeightTrak software.

XI. Computer Connection Via USB

You can use the included USB cable and WeighTrak

software to upload your scale’s stored data to a PC. The

scale is plug and play compatible with Windows 2000, XP,

and Vista 32 bit versions.

Connect the scale to your PC using the included USB•

cable.

Tap the scale, or press one of the function keys to turn•

the scale on.

The display will show “Load” to indicate that it is in•

computer upload mode.

You are ready to use the WeighTrak software to access•

the scale’s data.

XII. Body Composition Charts

Body Fat %

Age

Female Male

Under-

weight Healthy Over-

weight Obese Under-

weight Healthy Over-

weight Obese

10-12 <12 12-22 22-30 >30 <8 8-18 18-24 >24

13-18 <15 15-25 25-33 >33 <8 8-18 18-24 >24

19-30 <20 22-31 31-38 >38 <8 8-18 18-24 >24

31-40 <24 24-33 33-40 >40 <11 11-20 20-26 >26

41-50 <24 24-33 33-40 >40 <13 13-22 22-28 >28

51-60 <26 26-35 35-42 >42 <15 15-24 24-30 >30

60+ <28 28-37 37-47 >47 <17 17-25 26-34 >34

Body Water %

Age Female Male

Healthy Healthy

10-12 >60 >64

13-18 >58.5 >63.5

19-30 >56 >62.5

31-40 >53 >61

41-50 >52 >60

51-60 >51 >59

60+ >50 >58

Body Muscle %

Age Female Male

Healthy Healthy

10-99 >34 >40

Bone Mass

Female Male

Weight <100lb 100-130lb >130lb <130lb 130-165 >165lb

Bone 4lb 4.8lb 5.5lb 5.5lb 6.4lb 7lb

Model BIOWEIGH-USB

Capacity 150kg / 330lb / 23st:8lb

Resolution 0.1kg / 0.2lb / 0.2lb

Weighing Units kg, lb, st:lb

Memory 10 User Memory;

Stores up to 365 records per user.

Record includes: year, month, day, weight, fat, water,

muscle, and bone

Body Analysis Ranges body fat range: 0~80%

body fat graduation: 0.1%

water range: 10~80%

water graduation: 0.1%

muscle range: 13~80%

muscle graduation: 0.1%

bone range: 0~9kg

bone graduation: 0.2lb/0.1kg

age range: 10~80

Temperature Display range: 14°F ~ 104°F (-10°C ~ 40°C)

Scale Dimensions

(inches) 11.8 x 12.2 x 0.7”

Power 2 x AAA Batteries (included)

Warranty 10 Year Warranty

American Weigh Scales, Inc.

2 Carriage Ln, Suite 2

Charleston, SC 29407

Tel: 866-643-3444 (toll free)

Fax 843-225-7284
