AVF RML8300-F Manuel utilisateur
RML8300-F Leaflet No. 464843 rev00
121lbs
55kg
STOP
Read through ALL instructions before commencing installation.
If you have any questions about this product or issues with installation
contact the customer services help line before returning this product to
the store. See ca.orbitalholdings.com/p/RML8300-F
CUSTOMER SERVICES HELP LINE NUMBER:
1-800 601 8450 (USA)
English Language
##
Orbital Holdings Inc. 3187, Cornerstone Drive, Eastvale, CA 91752, USA
Assembly Overview
Fit Screen Hangers to TV
Fitting the Wall Bracket
Hanging the TV
Index
Retain all packaging in case the bracket needs to be returned.
Contents may vary from photography / Illustrations.
You will not need all these parts, so expect there to be some left over depending upon the
specification of your TV.
This product is intended for indoor use only. Use of this product outdoors could lead to
failure and personal injury.
It is the responsibility of the installer to ensure that the mounting wall is of a suitable
standard and void of any services (eg gas, electricity, water etc).
AVF accept no responsibility for any damage or loss caused by installing this product in a
sub standard wall.
Marking Wall For Drill Points
5
Assemble Positioning Template
3
Fit Screen Hangers to TV
2
Measure the TV fixing holes Width and Height
1
Determine Bracket Hole Centers
4
Fitting the Wall Bracket
6
7Hanging the TV
Outils recommandés
Trouve latte
Ø3mm (1/8") Bois
Ø10mm (25/64") Maçonnerie
Ø5.5mm (7/32") Maçonnerie
Ø3.5mm (9/64") Métal
Boxed Parts
A
B
U2
U1
Dx2
Cx2 Hx4 Jx8 Lx2 Mx4 Nx4
Ox2 Px2 Qx2 R TS
Measure the TV fixing holes Width and Height
1
TV Fixing
Holes
200mm
to infinity
100mm
to infinity
X
Y
After completing step 2 you
will have TV fixing screws
left over, please keep for
future reference
!
G7-G9
G4-G6
G1
M8 =
M6 =
M4 =
M5 =
G10-G12
TV Screws, Reducers and Spacers
F1x4
F2x4
F3x4
E1x12 E2x4
16mm
M5
25mm
M5
45mm
M5
16mm
25mm
45mm
M6 M6 M6 M8 M8 M8
16mm
25mm
45mm
16mm
M4
G1x4 G4x4 G5x4 G6x4
G7x4 G10 x4
G8x4 G11 x4
G9x4 G12 x4
If width X is less than mm
or height Y is less than mm
STOP installation now and contact
the customer help line
200
100
!
You are provided with 4 diameters of
TV fixing screws, M4, M5, M6 and M8.
Determine the screw diameter
that fits and remember for step 2.
Fit Screen Hangers to TV
2
Once you have established which screw diameter you need for your TV you will need to choose
which wall spacing you require. Check the back of your TV and use the OPTION that fits your TV.
Please see page opposite for more details.
OPTION 1
12mm Wall Space
OPTION 2
20mm Wall Space
OPTION 3
40mm Wall Space
Suitable for TVs with a flat
back and no obstructions
Suitable for TVs with small
to medium obstructions eg
power supply, mouldings etc
Suitable for TVs with large
obstructions eg power
supply, mouldings etc
12mm 20mm 40mm
TV TV TV
E2
TV
TV
Problem
Not enough screw
engagement
Solution
Red spacer
has replaced
spacer
E2
E1
E1
Top
Bottom Fixings
If required
Top Fixings
F1-F3
G1-G12
C
If required E1
G1-G12
If required
F1-F3
D
If required
E1
In certain circumstances it may be necessary to use
red spacer E2 as either a replacement or addition to
spacer E1.
When is it necessary to use red spacers E2?
It is recommended that when fitting Hangers C and
Stand-offs D to your TV you have at least 5-10mm of
screw engagement. In certain circumstances you may
need to use red spacers E2 as either a replacement,
or together with spacers E1 to achieve this. Whenever
you use red spacers E2 you must use all 4 provided.
C C CDD D
E1E1E1E1E1E1
E1E1E1E1E1E1
E1E1E1E1E1E1
F2F3F2F3
G6G6G9G9G12 G12
C D
C DC D
E1E1
E1E1E1E1
F2F3
G5G8G11
F2F3
G5G8G11
C DC DC DC D
F1F1F2F2F3F3
G1G1G4G4G7G7G10 G10
OPTION 1
12mm Wall Space
Top Fixings
M4 M5 M6 M8
Bottom Fixings
M4 M5 M6 M8
TopFixings
M5 M6 M8
Bottom Fixings
M5 M6 M8
Top Fixings
M5 M6 M8
Bottom Fixings
M5 M6 M8
OPTION 2
20mm Wall Space. Not applicable for M4 fixings G1
OPTION 3
40mm Wall Space. Not applicable for M4 fixings G1
Assemble Positioning Template
3
Top
The center line of the
template represents
the center of your TV.
U2
Lay the template on the back of the TV and follow the instructions below.
Line up with top
of the screen.
Cut the template so it is flush with
the bottom of your TV so that when the
template is on the wall you can see
exactly where your TV will be vertically
(distance from the floor and ceiling).
U2
U2
U1
Determine Bracket Hole Centers
4
U1
U2
C
Top row holes
If hangers C do not line up with any holes on the template then ensure template is
firmly in position and punch 2 holes to match your top fixing centres with a pencil or
sharp object.
Place the top row of holes on
template U1 over hangers C.
Mark off the top fixing centres
Marking Wall For Drill Points
5
Use your template to mark
two points on the wall that
correspond with the top
fixing centers of your TV.
Represents the
top of your TV. T
Represents the
bottom of your TV.
Represents the
center of your TV.
DRILL POINTS
T
Next, use the Wall Brackets and as a template and position them over the appropriate
PENCIL MARKS you have made, so that the mark is in the middle of the
CENTRAL HOLE of the Wall Bracket. Ensure the bracket is level and mark the three
DRILL POINTS with a pencil. Repeat for other bracket.
A B
Drill six 3mm pilot holes and select appropriate fixings (see section 6)
B
DRILL POINTS
A B
A
Before marking the wall,
determine the wall type that
you have (i.e. Solid Wall/
Dot & Dab/ Plasterboard/
Wood Stud/Metal Stud).
Ensure the drilling area is
free from mains services
(Gas/Electric/Water).
Represents the
center of your TV.
PENCIL MARK
CENTRAL HOLE
PENCIL MARK
CENTRAL HOLE
Fitting the Wall Bracket
6
Use the correct fixings for your wall type. Mixing fixing screws may be required for
installations that span different wall types. DO NOT OVER TIGHTEN SCREWS.
Solid Wall
10mm (25/64")
40mm (19/16")
5.5mm (7/32")
N
O
N
M
Q
M
Remove dust
from holes
Lubricate screw
thread with soap
12.5 mm (½") MAX
75mm (3")
A+B
Solid
Concrete
Drywall
18mm (3/4")
R
R
40mm
(19/16")
MIN gap
Remove dust from holes
A+B
O
Jx2
J
PSelf
drilling
i
ii
iii
H
S
Min supporting surface specification:- ½” thick
drywall, mounted on 1½” x 3½” wood stud at
16" centers.
Turn until
secure do not
over tighten
