AVF NUL404 Manuel utilisateur
NUL404 Leaflet No. 464051 rev00
STOP
77lbs
35kg
47"
119cm
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
CUSTOMER SERVICES HELP LINE NUMBER:
01952 670009
Read through ALL instructions before commencing installation.
If you have any questions about this product or issues with installation
contact the customer services help line before returning this product to
the store. Visit http://te.avf.co.uk/p/nul404 for more information.
Fit the TV Mounting Plate
Assembly Overview
Fit the Wall Bracket
Attach the TV
Measure the TV fixing holes Width and Height
1
Preparing the TV Mounting Plate
2
Fitting the TV Mounting Plate
3
Fitting the Wall Bracket
4
Arm Assembly
5
Retain all packaging in case the bracket needs to be returned.
Contents may vary from photography/ Illustrations.
You will not need all these parts, so expect there to be some left over
depending upon the specification of your TV.
This product is intended for indoor use only. Use of this product outdoors
could lead to failure and personal injury.
It is the responsibility of the installer to ensure that the mounting wall is of
a suitable standard and void of any services (eg gas, electricity, water etc).
AVF accept no responsibility for any damage or loss caused by installing
this product in a sub standard wall.
Index
Attach the TV
6
Stud Finder Ø3mm (1/8")
Wood
Ø10mm (25/64")
Masonry
Tools Recommended
Boxed Parts
A
BC
D
E
F1
F2
F2
F1
M4 M4 M6
M8
M4 M4 M6 M6
M8 M8
M5M6
N1x4 N2x4
Hx8
N6x4
N10 x4
O1x4 O2x4
N5x4
N3x4 N4x4 N7x4 N8x4
N11 x4
N9x4 P3x4
P1x4 P2x4
Gx8 Ix4
Qx3 Rx4 Sx4 T2x2
M1x2 M2x2
N12 x4
5mm
16mm
10mm
16mm
25mm
35mm
45mm
25mm
45mm
35mm
25mm
35mm
45mm
TV Screws, Reducers and Spacers
T1x1
4mm
Jx4 Kx2 Lx4
M6
M8
12mm
12mm
Measure the TV fixing holes Width and Height
If width X is greater than 400mm or height Y greater than 400mm
STOP installation now and contact the customer help line
!
1
You are provided with 3 diameters of TV fixing screws, M4, M6 and M8.
Determine the screw diameter that fits and remember for step 3.
TV Fixing Holes
75 - 400mm
75 - 400mm
X
Y
M8 = N9-N12
M6 = N5-N8
M4 = N1-N4
I
E
M5
Ix4
16mm
OPTION 1
75mm
100mm
200mm
75mm 100mm
X
Y200mm MAX 100mm MIN
Top
Use the option that fits your TV
Preparing the TV Mounting Plate
2
OPTION 1 OPTION 2 OPTION 3
TV Fixing Hole Sizes TV Fixing Hole Sizes TV Fixing Hole Sizes
This bracket is not limited to the TV fixing sizes above. If your TV has fixing holes that do
not match the sizes above use the X and Y dimensions shown in the diagrams to determine
the correct option layout for your TV. If in any doubt please call the customer help line.
75mm
100mm
200mm
200mm
X
X
X
X
Y
Y
Y
Y
x
x
x
x
75mm
100mm
100mm
200mm
300mm
300mm
400mm
400mm
X
X
X
X
Y
Y
Y
Y
x
x
x
x
200mm
300mm
200mm
300mm
400mmX Yx 400mm
400mm MAX
X
H
G
E
I
OPTION 2
F2
F1
F2
F1
M5M6
Hx8
Gx8 Ix4
16mm
10mm
Adaptors
can be fixed in different
positions in the slots on
Plate E to match your
TV fixing holes
F1 and F2
250mm MIN
Y300mm MAX 160mm MIN
Top
IE
OPTION 3
F1
F2
F1
F2
M5M6
Hx8
Gx8 Ix4
16mm
10mm
H
G
Adaptors
can be fixed in different
positions in the slots on
Plate E to match your
TV fixing holes
F1 and F2
400mm MAX
X
250mm MIN
Y400mm MAX 240mm MIN
Top
Fitting the TV Mounting Plate
3
TV TV
TV
TV
No Spacers Spacers P1-P3
For Tvs with flat/unobstructed back For Tvs with irregular/obstructed back
WARNING
After completing step 3 you will have fittings left over, please keep
for future reference
!
