MediaPack 504-508 (MP-5xx ) Hardware Instal lation Ma nual

Hardware Installation Manual

AudioCodes MediaPack™5xx Analog Voice Gateway Series

MediaPack 504 (MP-504)

MediaPack 508 (MP-508)

Contents
MP-504/8

- ii -
Table of Contents
MediaPack 504-508 (MP-5xx) Hardware Installation Manual..............................................1
Notice...............................................................................................................................iii
WEEE EU Directive...........................................................................................................................iii
Customer Support............................................................................................................................iii
Stay in the Loop with AudioCodes...................................................................................................iii
Abbreviations and Terminology ......................................................................................................iii
General Notes and Warnings...........................................................................................................iii
Safety Precautions...........................................................................................................................iv
Related Documentation...................................................................................................................iv
Documentation Feedback................................................................................................................iv
1Introduction................................................................................................................5
2Unpacking the Device..................................................................................................6
3Physical Description ....................................................................................................7
3.1 Physical Dimensions and Operating Environment .................................................................7
3.2 Front Panel Description..........................................................................................................7
3.3 Rear Panel Description...........................................................................................................8
4Mounting the Device...................................................................................................9
4.1 Desktop mounting..................................................................................................................9
4.2 19-Inch Rack Mounting ..........................................................................................................9
4.3 Wall Mounting......................................................................................................................12
5Cabling the Device.....................................................................................................14
5.1 Cabling WAN Interface .........................................................................................................14
5.2 Cabling FXS Analog Interfaces ..............................................................................................15
5.3 Connecting to Power............................................................................................................17


Notices

MP-504/8

- iii -

Notice

Information contained in this document is believed to be accurate and reliable at the time of

printing. However, due to ongoing product improvements and revisions, AudioCodes cannot

guarantee accuracy of printed material after the Date Published nor can it accept responsibility for

errors or omissions. Updates to this document can be downloaded from

https://www.audiocodes.com/library/technical-documents.

This document is subject to change without notice.

Date Published: February-14-2023

WEEE EU Directive

Pursuant to the WEEE EU Directive, electronic and electrical waste must not be disposed of with

unsorted waste. Please contact your local recycling authority for disposal of this product.

Customer Support

Customer technical support and services are provided by AudioCodes or by an authorized

AudioCodes Service Partner. For more information on how to buy technical support for AudioCodes

products and for contact information, please visit our website at

https://www.audiocodes.com/services-support/maintenance-and-support.

Stay in the Loop with AudioCodes

Abbreviations and Terminology

Each abbreviation, unless widely used, is spelled out in full when first used.

Throughout this manual, unless otherwise specified, the term device refers to the MediaPack 504 /

508 (MP-504/MP-508) analog voice gateway.

General Notes and Warnings

Warning: The device must be installed only indoors.

Open-source software may have been added and/or amended. For further information,

contact your AudioCodes sales representative.

Notices

MP-504/8

- iv -

Safety Precautions

◼It's recommended that Ethernet and phone (FXS) cabling be routed only indoors and not exit

the building.

◼Do not open or dismantle the device.

◼Do not expose the device to water or moisture.

◼Make sure the device is installed in a well-ventilated location to avoid overheating of internal

components and subsequent damage.

◼Do not place any object on top of the device and make sure that sufficient clearance from the

top and sides are maintained to ensure proper airflow to avoid over heating of internal

components.

◼Operate the device in an ambient temperature (Tma) that does not exceed 40°C (104°F).

◼Use only the supplied AC/DC power adapter for connection to the power source.

Warning: In case of a malfunction, do not attempt to fix the power adapter and do not use

any other type of power adapter.

Related Documentation

Document Name

MediaPack 5xx Voice Gateway Basic Configuration

MediaPack 504-508 (MP-5xx) Voice Gateway Quick Guide

Documentation Feedback

AudioCodes continually strives to produce high quality documentation. If you have any comments

(suggestions or errors) regarding this document, please fill out the Documentation Feedback form on

our website at https://online.audiocodes.com/documentation-feedback.

1. Introduction

MP-504/8

- 5 -

1Introduction

This document provides a hardware description of the device and step-by-step procedures for

mounting and cabling the device.

The device supports the following interfaces:

◼WAN interface - single Gigabit Ethernet copper (10/100/1000Base-T)

◼LAN interface - single Gigabit Ethernet (1000Base-T) LAN port (RJ-45)

◼Telephony interfaces:

•MP-504 model: One slot of four FXS port interfaces

•MP-508 model: Two slots, each providing four FXS port interfaces (i.e., total eight

interfaces)

◼Serial console port (RJ-45) for device management

2. Unpacking the Device

MP-504/8

- 6 -

2Unpacking the Device

Follow the procedure below for unpacking the carton in which the device was shipped.

To unpack the device:

1. Open the carton and carefully remove packing materials.

2. Remove the chassis from the carton.

3. Check that there is no equipment damage.

4. Ensure that in addition to the chassis, the package contains the following items:

•Four anti-slide bumpers for desktop installation

•AC/DC power adapter

3. Physical Description

MP-504/8

- 7 -

3Physical Description

This section provides a physical description of the device.

3.1 Physical Dimensions and Operating Environment

The device's physical dimensions and operating environment are listed in the table below:

Table 1: Physical Dimensions and Operating Environment

Specification

Value

Dimensions (H x W x D)

51 x 296 x 165 mm (2 x 11.65 x 6.5 in.)

Weight

670 g (1.5 lbs.)

Operating Environment

◼Operational: 5 to 40°C (41 to 104°F)

◼Storage: -25 to 85°C (-13 to 185°F)

◼Relative Humidity: 10 to 90% non-condensing

3.2 Front Panel Description

The front panel provides LEDs for indicating the status of various functionalities. The LEDs are shown

in the figure below and described in the subsequent tables.

Figure 1: Front Panel

Power

LED indicating power status:

Green On

Power received by device.

Off

No power.

Status

LED indicating operating status:

Green On

Device is operational.

Green Flashing

Initial rebooting stage or software upgrade in process.

Red On

Boot failure.

WAN GE

LED indicating Gigabit Ethernet WAN link status:

Green On

WAN GE link established.

Green Flashing

Data received or transmitted.

Off

No WAN GE link or power not received by the device.

3. Physical Description

MP-504/8

- 8 -

3.3 Rear Panel Description

The device's rear panel is shown in the figure below and described in the subsequent table.

Figure 2: Rear Panel

POWER

DC power plug entry for external AC/DC power adapter.

Reset pinhole button for resetting the device or restoring it to factory defaults. To restore to

factory defaults: with a paper clip or any other similar pointed object, press and hold down the

button for at least 12 seconds (but no more than 25 seconds). Please note that the device will

lose all its configuration!

S0 / WAN

WAN interface port Giga Ethernet (10/100/1000Base-T)

Green On

Ethernet link established.

Green Flashing

Data is received or transmitted.

Off

No Ethernet link.

S2 / FXS

S3 / FXS

S2: FXS ports 1-4

S3: FXS ports 5-8 (applicable only to MP-508)

4. Mounting the Device

MP-504/8

- 9 -

4Mounting the Device

You can mount the device using one of the following methods:

◼Desktop mounting

◼19-inch Rack mounting

◼Wall mounting

4.1 Desktop mounting

Place the device on a desktop using the four anti-slide bumpers (supplied), which you need to stick

on the grooves located on the underside of the device. The bumpers avoid involuntary movement

of the unit on the desktop as well as enable better air flow for cooling the device.

4.2 19-Inch Rack Mounting

You can mount the device in a standard 19-inch rack, using AudioCodes 1U 19-inch rack mount shelf

(not supplied).

The AudioCodes 1U 19-inch rack mount shelf is not supplied with your product and can be

ordered separately from an AudioCodes sales distributor.

Warning:

◼Elevated Operating Ambient: If installed in a closed or multi-unit rack assembly,

consideration should be given to installing the equipment in an environment

compatible with the maximum ambient temperature (Tmax) of 40°C (104°F).

◼Reduced Air Flow: Installation should be such that the amount of air flow required for

safe operation on the equipment is not compromised. Do not stack equipment one on

top of the other and keep the ventilation openings free from cables or any objects to

allow free air circulation. The device must be mounted correctly on the rack mount

shelf to avoid air blockage to the three vents located on the bottom of the device.

Mounting the device on a shelf other than AudioCodes' rack mount shelf may cause

the device to overheat, resulting in permanent damage to it.

◼Only one device can be mounted per rack mount shelf.

◼The minimum vertical rack space for mounting the device in a 19-inch rack must be

2Us (3.5 in. or 88.9 mm). See figure below.

Figure 3: Minimum Vertical Space for 19-inch Rack Mounting

4. Mounting the Device

MP-504/8

- 10 -

To mount the device in a 19-inch rack:

1. Position the rack mount shelf (ordered separately from AudioCodes) in the 19-inch rack,

aligning the holes of the shelf's side brackets with the holes of the rack's front posts, as shown

in the figure below.

Figure 4: Positioning Shelf in Rack

Make sure that you attach the shelf's side brackets (left and right) at the same height level

in the rack so that the shelf is in a horizontal position.

2. Attach the shelf to the rack posts using four standard 19-inch rack bolts (not supplied).

3. Place the device on the shelf so that the device's front panel faces the front of the rack and

the device's four anti-slide rubber legs (located on the bottom of the device) fit into the four

square openings on the shelf, as shown in the figure below (viewed from underneath):

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels AudioCodes Porte

AudioCodes

AudioCodes Media Pack MP-124 Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-124 Manuel utilisateur

AudioCodes

AudioCodes Mediant 2000 Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-124 Manuel utilisateur

AudioCodes

AudioCodes Mediapack mp-11x Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-112 Instructions de montage

AudioCodes

AudioCodes MediaPack Series Instructions de montage

AudioCodes

AudioCodes MediaPack 114 Manuel utilisateur

AudioCodes

AudioCodes Mediant 2000 Manuel utilisateur

AudioCodes

AudioCodes MP-108 Manuel utilisateur

AudioCodes

AudioCodes Mediant 1000 Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-124 Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-40x series Manuel utilisateur

AudioCodes

AudioCodes Mediant 1000 Instructions de montage

AudioCodes

AudioCodes MediaPack MP-262 Manuel utilisateur

AudioCodes

AudioCodes MP-11 Manuel utilisateur

AudioCodes

AudioCodes Gateway & Session Border Controller Series Instructions de montage

AudioCodes

AudioCodes Mediant 1000B Instructions de montage

AudioCodes

AudioCodes MediaPack 1288 Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-264 Manuel utilisateur

AudioCodes

AudioCodes Mediant 800B Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-272 Manuel utilisateur

AudioCodes

AudioCodes MediaPack MP-124 Manuel utilisateur

AudioCodes

AudioCodes MP-104 Mode d’emploi

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
