AEMC 6240 Manuel utilisateur

MICRO-OHMMETER 6240

ENGLISH User Manual

NOTE: For instruments with serial numbers

lower than 116339SEDV, terminals C1 and P1

are red, and C2 and P2 are black

Statement of Compliance

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

certiﬁes that this instrument has been calibrated

using standards and instruments traceable to

international standards.

We guarantee that at the time of shipping your

instrument has met its published speciﬁcations.

An NIST traceable certiﬁcate may be

requested at the time of purchase, or obtained

by returning the instrument to our repair and

calibration facility, for a nominal charge.

The recommended calibration interval for this

instrument is 12 months and begins on the date of

receipt by the customer. For recalibration, please

use our calibration services. Refer to our repair

and calibration section at www.aemc.com.

Serial #: ________________________________

Catalog #: 2129.80

Model #: 6240

Please ﬁll in the appropriate date as indicated:

Date Received: _________________________________

Date Calibration Due: _______________________

Chauvin Arnoux®, Inc.

d.b.a AEMC®Instruments

www.aemc.com

Table of Contents

1. INTRODUCTION ................................................................................. 4

1.1 International Electrical Symbols................................................5

1.2 DenitionofMeasurementCategories .....................................5

1.3 ReceivingYourShipment..........................................................5

1.4 OrderingInformation.................................................................6

1.4.1 AccessoriesandReplacementParts............................6

2. PRODUCT FEATURES......................................................................... 7

2.1 Description................................................................................7

2.2 Applications ..............................................................................8

2.3 KeyFeatures ............................................................................8

2.4 ControlFeatures .......................................................................9

2.5 ButtonFunctions.....................................................................10

2.6 DisplaySymbols ..................................................................... 11

3. SPECIFICATIONS............................................................................. 12

3.1 Electrical .................................................................................12

3.2 Mechanical..............................................................................13

3.3 Environmental.........................................................................14

3.4 Safety......................................................................................14

4. OPERATION..................................................................................... 15

4.1 PrecautionsBeforeUse..........................................................15

4.2 InstrumentConguration(SET-UPmode) ..............................15

4.3 ResistanceMeasurements .....................................................16

4.3.1 MeasurementReadings..............................................17

4.3.2 ConnectionsandReadings.........................................17

4.3.3 Test Lead Connection .................................................18

4.4 RepetitiveMeasurements .......................................................18

4.5 MeasuringVeryLowResistance ............................................19

4.6 AutomaticRecording ..............................................................20

4.7 StoringResultsintoMemory...................................................21

Micro-Ohmmeter Model 6240

4.8 RecallingResultsfromMemory..............................................22

4.9 ErasingMeasurementsfromMemory.....................................23

4.9.1 ErasingSelectedMeasurements................................23

4.9.2 ErasingAllMeasurements ..........................................23

5. DATAVIEW®SOFTWARE................................................................... 24

5.1 InstallingDataView®................................................................24

5.2 Micro-ohmmeterControlPanel...............................................26

6. TROUBLESHOOTING ........................................................................ 27

6.1 ErrorMessages ......................................................................27

6.1.1 VoltagePresent ..........................................................27

6.1.2 Overrange...................................................................28

6.1.3 NoisyMeasurement....................................................28

6.1.4 Overheating ................................................................28

7. MAINTENANCE................................................................................ 29

7.1 Warning..................................................................................29

7.2 Cleaning..................................................................................29

7.3 Charging/RechargingtheBattery ...........................................30

7.4 BatteryandFuseReplacement ..............................................31

RepairandCalibration ....................................................................32

TechnicalandSalesAssistance......................................................32

Limited Warranty .............................................................................33

WarrantyRepairs ............................................................................33

Micro-Ohmmeter Model 6240

CHAPTER 1

INTRODUCTION

WARNING

These safety warnings are provided to ensure the safety of

personnelandproperoperationoftheinstrument.

• Thisinstrumentisprotectedfromaccidentalvoltagesofnot

more than 50V with respect to earth in measurement Cat-

egoryIII.

• Donotattempttoperformanytestswiththisinstrumentuntil

youhavereadtheusermanual.

• Tests are to be carried out on de-energized circuits only!

Never connect the unit to a live circuit.

• Make sure that none of the input terminals are connected

andthattheswitchissettoOFFbeforepluggingintheAC

powertorechargethebatteryoftheinstrument.

• Makesuretheinternalbatteryisfullychargedpriortotesting.

If the instrument has been left unused for several months,

rechargethebattery.

• If the case needs cleaning, do not use any alcohol or oil

based cleaners. Preferably use soapy water with a damp

clothorsponge.Donotimmersethe6240micro-ohmmeter

inwater.

• Use connection accessories of which the overvoltage cat-

egory and the service voltage are greater than or equal to

those of the measuring instrument (50V CAT III). Use only

accessoriesthatcomplywithsafetystandards(IEC61010-2-

031).

• The test leads and measuring wires must be in good

conditionandshouldbereplacedifthereisanyevidenceof

deterioration(insulationsplit,burnt,etc.).

• Troubleshooting and metrological verication procedures

mustonlybeperformedbyqualied,approvedpersonnel,or

thefactory.

Micro-Ohmmeter Model 6240

1.1 International Electrical Symbols

Signiﬁes that the instrument is protected by double or reinforced insulation.

This symbol on the instrument indicates a WARNING and that the operator must refer

to the user manual for instructions before operating the instrument. In this manual,

the symbol preceding instructions indicates that if the instructions are not followed,

bodily injury, installation/sample and/or product damage may result.

Risk of electric shock. The voltage at the parts marked with this symbol may

be dangerous.

When disposed of, this product must be sorted for the recycling of electrical

and electronic equipment in accordance with WEEE directive 2002/96/EC.

1.2 Deﬁnition of Measurement Categories

CAT IV: For measurements performed at the primary electrical supply

(<1000V) such as on primary overcurrent protection devices,

ripplecontrolunits,ormeters.

CAT III: For measurements performed in the building installation at

the distribution level such as on hardwired equipment in xed

installationandcircuitbreakers.

CAT II: For measurements performed on circuits directly connected to

the electrical distribution system. Examples are measurements

onhouseholdappliancesorportabletools.

1.3 Receiving Your Shipment

Uponreceivingyourshipment,makesurethatthecontentsareconsistent

withthepackinglist.Notifyyourdistributorofanymissingitems.Iftheequip-

mentappearstobedamaged,leaclaimimmediatelywiththecarrierand

notifyyourdistributoratonce,givingadetaileddescriptionofanydamage.

Savethedamagedpackingcontainertosubstantiateyourclaim.

NOTE: Charge the instrument fully before use.

Micro-Ohmmeter Model 6240

1.4 Ordering Information

Micro-ohmmeter Model 6240............................................ Cat. #2129.80

Includes extra large tool bag, set of two 10ft Kelvin clips (10A - Hippo), set of two 10ft Kelvin

probes (1A - Spring Loaded), optical USB cable, US 115V power cord, two spare fuses

(12.5A), NiMH rechargeable battery pack, and USB stick supplied with product user manual

and DataView®software.

1.4.1 Accessories and Replacement Parts

Kelvinclips(10A-Hippo),10ftcolor-codedleads

withspadelugterminations................................................. Cat. #1017.84

Kelvinclips(10A-Hippo),20ftcolor-codedleads

withspadelugterminations................................................. Cat. #2118.70

KelvinProbes(1A-SpringLoaded),10ftwith4mmbanana

plugtermination(includessetof5forkterminals)............... Cat. #2118.73

KelvinProbes(1A-SpringLoaded),20ftwith4mmbanana

plugtermination(includessetof5forkterminals)............... Cat. #2118.74

KelvinProbesPistolGrip10ft(10A)SpringLoaded........... Cat. #2118.75

KelvinProbesPistolGrip20ft(10A)SpringLoaded........... Cat. #2118.76

KelvinProbes10ft(10A)SpringLoaded ........................... Cat. #2118.77

KelvinProbes20ft(10A)SpringLoaded ............................ Cat. #2118.78

KelvinClips10ft(1-10A)..................................................... Cat. #2118.79

KelvinClips20ft(1-10A)..................................................... Cat. #2118.80

Thermo-HygrometerModelCA846 .....................................Cat. #2121.24

OpticalUSBCable...............................................................Cat. #2135.41

KelvinClips25ft(200A-Hippo)..........................................Cat. #2129.72

KelvinClips50ft(200A-Hippo)..........................................Cat. #2129.73

Battery–ReplacementNiMH6V9000mAH

forModels6240&6250 ......................................................Cat. #2129.91

Fuse,setof5,12.5A/500V,6.3x32mm ............................. Cat. #2129.92

ExtraLargeClassicToolBag ..............................................Cat. #2133.73

Inverter–12VDCto120VAC200Wattforvehicleuse......... Cat. #2135.43

115VPowerCordUS .......................................................... Cat. #5000.14

Order Accessories and Replacement Parts Directly Online

Check our Storefront at www.aemc.com/store for availability

Micro-Ohmmeter Model 6240

CHAPTER 2

PRODUCT FEATURES

2.1 Description

The Micro-ohmmeter Model 6240 is used to perform low resistance

measurementsfrom5μΩto 400Ω.Therearesixrangeswithtestcurrents

from10mAto10A.

Thefrontendofthemicro-ohmmeteremploysafour-wireKelvincongu-

ration,whicheliminatestestleadresistanceforameasurementaccuracy

of0.25%.Abuilt-incircuitltersoutACsignals.

TheMicro-ohmmeterModel6240ispackagedinasealedeldcasewell

suitedforshopandelduse.Powerissuppliedbyalong-lifeNiMHbattery

packwithabuilt-inrecharger(110/220V).

Thelarge,easy-to-readliquidcrystaldisplayis2.25x4.00".Itdisplaysthe

valueofresistance,currentorvoltagetest,polarityandbatterycharge.

Foroperatorsafetyandinstrumentprotection,themicro-ohmmeterisfuse

protectedattheinputs.Onefuse,accessiblefromthefrontpanel,protects

againststoredenergyininductiveloads.

Enhanced internal circuitry protects against possible inductive kickback

whenthecurrentisshuto󰀨.

Abuilt-inthermalswitchprotectsthemicro-ohmmeteragainstoverheating

onthe10Arangewhenincontinuoususe.

Micro-Ohmmeter Model 6240

2.2 Applications

Someofthemorepopularandmostfrequentusesofthemicro-ohmmeter

areinapplicationsfor:

• Checkingmetalliccoatingresistance,especiallyinaeronautics

• Groundconnectionsandcontinuitymeasurement

• Resistancemeasurementsonmotorsandsmalltransformers

• Contactresistancemeasurementsonbreakersandswitches

• Componentmeasurement

• Electricalcableresistancemeasurement

• Mechanicalbondtests

• Wire to terminal connections

• Aircraftandrailbonds

2.3 Key Features

• Measuresfrom5µΩto 400Ω

• Testcurrentselectionfrom10mAto10A

• Manualtemperaturecompensation(withDataView®software)

• Frontpanelpolarityreversefunction

• Storesupto99testresults

• Operatorsafetybyautomaticdischargeofresidualchargeonthe

equipmentundertest

• Instantaneous,continuousormultipletestoperation

• Autostoreofmultipletestresults

• Internal,rechargeablebatteriesconductupto850,10Atests

• Abuilt-inbatterypackrechargerrechargesthebatteriesby

connectingtotheACline(110V-230V,50/60Hz)usingastandard

line cord

• 4-Wiremeasurementwithautomaticcompensationof

undesirablevoltagesandleadresistance

• Largemulti-functionbacklitdisplay

• Directdisplayofthemeasurementwithunits,rangeandtest

current

• Rugged,sealedcase

Autres manuels pour 6240

Table des matières

Autres manuels AEMC Instrument de mesure

AEMC

AEMC 4000D-14 Manuel utilisateur

AEMC

AEMC PowerPad III 8336 Guide de configuration

AEMC

AEMC 203 Manuel utilisateur

AEMC

AEMC 5100 Manuel utilisateur

AEMC

AEMC MD304 Manuel utilisateur

AEMC

AEMC SL261 Manuel utilisateur

AEMC

AEMC MN375 Manuel utilisateur

AEMC

AEMC CA811 Manuel utilisateur

AEMC

AEMC MN126 Manuel utilisateur

AEMC

AEMC MN03 Manuel utilisateur

AEMC

AEMC MN170 Manuel utilisateur

AEMC

AEMC PowerPad III 8336 Manuel utilisateur

AEMC

AEMC Simple Logger II Manuel utilisateur

AEMC

AEMC 1035 Manuel utilisateur

AEMC

AEMC OX 5022-CK Guide de configuration

AEMC

AEMC 1000N Manuel d'utilisation et d'entretien

AEMC

AEMC MN186 Manuel utilisateur

AEMC

AEMC JM861 Manuel utilisateur

AEMC

AEMC PowerPad 8435 Guide de configuration

AEMC

AEMC CL601 Manuel utilisateur

AEMC

AEMC 6250 Manuel utilisateur

AEMC

AEMC MN352 Manuel utilisateur

AEMC

AEMC PowerPad 8335 Manuel utilisateur

AEMC

AEMC F09 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
