AEMC MN261 Manuel utilisateur
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
Copyright© Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments. All rights reserved.
No part of this documentation may be reproduced in any form or by any means (including electronic
storage and retrieval or translation into any other language) without prior agreement and written consent
from Chauvin Arnoux®, Inc., as governed by United States and International copyright laws.
This documentation is provided “as is,” without warranty of any kind, express, implied, or otherwise.
Chauvin Arnoux®
but does not warrant the accuracy or completeness of the text, graphics, or other information contained
in this documentation. Chauvin Arnoux®, Inc. shall not be liable for any damages, special, indirect,
user of the documentation has been advised of the possibility of such damages.
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer. For recalibration, please
use our calibration services. Refer to our repair and
calibration section at
Serial #:
Model #: MN261
Date Received:
Date Calibration Due:
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
TABLE OF CONTENTS
1.1 RECEIVING YOUR SHIPMENT ................................................ 6
1.2 ORDERING INFORMATION ..................................................... 6
1.2.1 Accessories and Replacement Parts ................................. 6
7
2.1 DESCRIPTION ........................................................................... 7
2.2 COMPATIBILITY ........................................................................ 7
2.3 CONTROL FEATURES ............................................................. 8
9
3.1 ELECTRICAL SPECIFICATIONS ............................................. 9
3.2 MECHANICAL SPECIFICATIONS ......................................... 10
3.3 ENVIRONMENTAL SPECIFICATIONS.................................. 10
3.4 SAFETY SPECIFICATIONS ................................................... 10
3.5 TYPICAL RESPONSE CURVES ............................................ 11
13
4.1 CURRENT MEASUREMENT .................................................. 13
14
5.1 CLEANING................................................................................ 14
5.2 REPAIR AND CALIBRATION ................................................. 15
5.3 TECHNICAL ASSISTANCE .................................................... 15
5.4 LIMITED WARRANTY ............................................................. 16
5.4.1 Warranty Repairs.............................................................. 16
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
6
AC Current Oscilloscope Probe Model MN261
PRECAUTIONS FOR USE
These safety warnings are provided to ensure the safety of personnel and
proper operation of the instrument.
Connect the probe to the oscilloscope or voltage measuring instrument
clamping the probe around a conductor.
Never use the probe on circuits rated higher than 600V, Cat III.
Never leave the probe clamped around a conductor while not connected
to an oscilloscope or voltage measuring instrument.
Carefully center the conductor inside the probe jaws and ascertain that
the probe is perpendicular to the conductor.
Avoid, if possible, the proximity of other conductors which may create
noise.
free of dirt, rust, or other foreign matter.
Do not use a probe which is cracked, damaged, or has defective leads.
Upon receiving your shipment, make sure that the contents are consistent
with the packing list. Notify your distributor of any missing items. If the equip-
notify your distributor at once, giving a detailed description of any damage.
Save the damaged packing container to substantiate your claim.
AC Current Oscilloscope Probe Model MN261..........................
Includes user manual and a product warranty and registration card.
Adapter - BNC (Female) to 4 mm
Banana (Male) 600 V CAT III ....................................................
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
AC Current Oscilloscope Probe Model MN261
7
The AC Current Oscilloscope Probe Model MN261 expands oscilloscope
applications in industrial or power environments, and is ideal for analysis
and measurement of distorted current waveforms and harmonics.
The Model MN261 permits accurate display and measurement of currents
from (0.1 to 240) Arms, 40 Hz to 10 kHz (with current derating) without
rising (di/dt) waveforms, and ensures accurate screen displays.
The probe connects directly to an oscilloscope through an insulated coax-
ial cable with an insulated BNC.
The Model MN261 is compatible with any analog or digital oscilloscope
or other voltage-measuring instrument which has the following features:
• BNC input connector
• Range capable of displaying (0.2 to 0.5) V per division, or 2 V range
• Minimum input impedance of 1 M
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
AC Current Oscilloscope Probe Model MN261
1. Jaw Opening: 0.83 in (21 mm)
2. Maximum dimension of conductor: 0.78 in (20 mm)
3. Two position switch
4. 6.5 ft (2 m) output cable
5.
direction when it travels from supply to load.
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
AC Current Oscilloscope Probe Model MN261
9
*Reference conditions: 23 °C ± 3 °K, 20 to 75 % RH, 48 to 65 Hz, external
A/m, no DC component, no external current carrying
conductor, test sample centered.
0.1 to 24 Arms
0.5 to 240 Arms
2 range switch selectable on handle
100mV/A: 0.1 to 24 Arms
10mV/A: 0.5 to 240 Arms
1 M @ 100 pF
10 mV/A (2 V at 200 A)
Current
3.5 % ± 5 mV 3 % ± 5 mV 2.5 % ± 5 mV 1.5 % ± 5 mV
N/A 6 ° 4 ° 3 °
Overload: 240 A for 10 mn ON, 30 mn OFF
100 mV/A (2 V at 20 A)
Overload: 120 A continuous
2 % ± 50 mV
40 Hz to 10 kHz (@ -3 dB)
See Typical Response Curves (§ 3.5)
100 k min
600 V CAT III
600 V CAT III
<15 mA/AAC @ 50 Hz
0.5 % of Reading @ ((50/60) Hz)
Range 20 A: 40 Hz to 1 kHz: 10 % of mV output
(1 to 10) kHz: 15% of mV output
Range 200 A: 40 Hz to 1 kHz: 3% of mV output
(1 to 10) kHz: 12% of mV output
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
AC Current Oscilloscope Probe Model MN261
(5.47 x 2.00 x 1.18) in (139 x 51 x 30) mm
6.5 oz (150g)
0.78 in (20 mm)
0.83 in (21 mm) max
0.78 in (20 mm)
Envelope Protection: IP 40 (IEC 529)
1 m (IEC 68-2-32)
Mechanical Shock: 100 g (IEC 68-2-27)
Vibration: (10/55/10) Hz @ 0.15 mm (IEC 68-2-6)
Output: 6 ft (2 m) insulated lead with insulated BNC Connector
(-40 to 158) °F (-40 to 70) °C
0.15 % / 10 K
Altitude:
Indoor Use
Electrical:
Double insulation or reinforced insulation between the primary or second-
ary and the outer case of the handle per EN 61010-2-032.
600V, CAT III, Pollution Degree: 2
Emission and immunity in an industrial environment according to the stan-
dard EN61326-1.
Shop for Power Metering products online at: 1.888.610.7664
www.PowerMeterStore.com
