AEMC 6608 Manuel utilisateur
PHASE ROTATION METER
ENGLISH
User Manual
PHASE ROTATION
MODEL 6608
L2/B L3/CL1/A
600V CAT III
300V CAT IV
690V
L1L2L3
RL
6608
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
The recommended verification interval for this
instrument is 12 months and begins on the date
of receipt by the customer.
Serial #: ____________________________
Catalog #: 2121.10
Model #: 6608
Please fill in the appropriate date as indicated:
Date Received: ________________________
Date Verification Due: _____________________
Chauvin Arnoux®, Inc. d.b.a AEMC®Instruments
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
Table of Contents
1. INTRODUCTION ..........................................................2
1.1 International Electrical Symbols .....................................3
1.2 DenitionofMeasurementCategories...........................3
1.3 ReceivingYourShipment ...............................................4
1.4 OrderingInformation ......................................................4
1.4.1 AccessoriesandReplacementParts .............4
2. PRODUCT FEATURES .................................................5
2.1 Description .....................................................................5
2.2 ControlFeatures.............................................................5
3. SPECIFICATIONS ........................................................6
4. OPERATION.................................................................7
4.1 PhaseRotationDirection................................................7
5. MAINTENANCE ...........................................................8
5.1 Cleaning .........................................................................8
Limited Warranty ..........................................................................10
WarrantyRepairs..........................................................................10
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
2
PhaseRotationMeterModel6608
CHAPTER 1
INTRODUCTION
Warning
• ThisinstrumentcomplieswithsafetystandardIEC61010-1,Ed
2ofFebruary2001.
• Foryourownsafety,andtopreventanydamagetoyourinstru-
ment,youmustfollowtheinstructionsgiveninthismanual.
• ThisinstrumentcanbeusedoncategoryIIIelectricalcircuitsnot
exceeding600Vwithrespecttoearth.Itmustbeusedindoors,in
anenvironmentnotexceedingpollutionlevel2,atanaltitudeof
notmorethan2000m.Theinstrumentcanthereforebeusedin
completesafetyon400Vand690Vthree-phasenetworksinan
industrialenvironment.
• Forsafetyreasons,youmustuseonlymeasurementleadshaving
avoltageratingandcategoryatleastequaltothoseoftheinstru-
mentandcompliantwithstandardIEC61010-031.
• Donotuseifthehousingisdamagedornotcorrectlyclosed.
• Donotplaceyourngersnearunusedterminals.
• Iftheinstrumentisusedotherthanasspeciedinthismanual,
theprotectionprovidedbytheinstrumentmaybeimpaired.
• Donotusethisinstrumentifitseemstobedamaged.
• Checktheintegrityoftheinsulationoftheleadsandofthehous-
ing.Replacedamagedleads.
• Beprudentwhenworkinginthepresenceofvoltagesexceeding
70Vdcor33Vrmsand46.7Vpp;suchvoltagescancauseariskof
electrocution.Theuseofindividualprotectionsisrecommended
in some cases.
• Alwayskeepyourhandsbehindthephysicalguardsoftheprobe
tipsoralligatorclips.
• Alwaysdisconnectallleadsfromthemeasurementandfromthe
instrumentbeforeopeningthehousing.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
PhaseRotationMeterModel6608
3
1.1 International Electrical Symbols
Instrument is protected by double or reinforced insulation.
CAUTION - DANGER! Read the User Manual.
Risk of electric shock. The voltage at the parts marked with this sym-
bol may be dangerous.
The CE marking guarantees conformity with European directives and
with regulations covering EMC.
The trash can with a line through it means that in the European
Union, the product must undergo selective disposal for the recycling
of electric and electronic material, in compliance with Directive WEEE
2002/96/EC.
1.2 Definition of Measurement Categories
CAT I: MeasurementcategoryIcorrespondstomeasurements
takenoncircuitsnotdirectlyconnectedtothenetwork.
CAT II: MeasurementcategoryIIcorrespondstomeasurements
takenoncircuitsdirectlyconnectedtotheinstallation.
Example: measurementforelectrodomesticunits,
portabletoolsandanaloguedevices
CAT III: Measurement category III corresponds to measure-
mentsonbuildinginstallations.
Example: measurementondistributionpanels,cabling,
etc.
CAT IV: Measurement category IV corresponds to measure-
mentstakenatthesourceoflow-voltageinstallations
Example:meteringandmeasurementsonovervoltage
protectiondevices.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
4
PhaseRotationMeterModel6608
1.3 Receiving Your Shipment
Uponreceivingyourshipment,makesurethatthecontentsarecon-
sistentwiththepackinglist.Notifyyourdistributorofanymissing
items.Iftheequipmentappearstobedamaged,leaclaimimme-
diately with the carrier and notify your distributor at once, giving
adetaileddescriptionofanydamage.Savethedamagedpacking
containertosubstantiateyourclaim.
1.4 Ordering Information
Phase Rotation Meter Model 6608 ........................ Cat. #2121.10
Includes meter, three color-coded test leads (red, black, blue), three alligator
clips (black), soft carrying case and a user manual.
1.4.1 Accessories and Replacement Parts
Softcarryingcase..................................................... Cat. #2121.54
Setof3color-codedleadswith
blackalligatorclipsCATIII1000V10A..................... Cat. #2121.55
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
PhaseRotationMeterModel6608
5
CHAPTER 2
PRODUCT FEATURES
2.1 Description
TheModel6608isdesignedtofacilitateinstallingthree-phaseelec-
tricalpower supply networksbyallowing a rapid determinationof
thedirectionofphaserotation
2.2 Control Features
PHASE ROTATION
MODEL 6608
L2/B L3/CL1/A
600V CAT III
300V CAT IV
690V
1
2
3
L1L2L3
RL
1.Testleadinputterminals
2. PhaseindicatorsL1,L2,L3
3.Clockwiseandcounter-
clockwiserotationLED
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
6
PhaseRotationMeterModel6608
CHAPTER 3
SPECIFICATIONS
ELECTRICAL
Operating Voltage 40 to 850Vac between phases
Frequency 15 to 400Hz
Test Current 1mA
Power Source Line Powered
MECHANICAL
Dimensions 5.1 x 2.7 x 1.3"(130 x 69 x 32mm)
Weight 4.5 oz (130g)
ENVIRONMENTAL
Operating
Temperature 32° to 104°F (0° to 40°C)
Storage
Temperature -4° to 122°F (-20° to 50°C); RH < 80%
SAFETY
Safety Rating
CAT III 600V
IEC 61010-1, DIN VDE 0411;
IEC 61557-7, DIN VDE 0413-7;
Tightness : IP 40 (as per IEC 60529 Ed.92)
Double Insulation Yes
CE Mark Yes
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
PhaseRotationMeterModel6608
7
CHAPTER 4
OPERATION
4.1 Phase Rotation Direction
Onathree-phaseelectricalnetwork:
1. Connectthethreeleadstotheinstrument,matchingthemark-
ings.
2. Connectthethreealligatorclipstothe3phasesofthenetwork
to be tested.
3. Thedisplaylightsup,indicatingthattheinstrumentisinopera-
tion.
4. When the three phase indicators (L1, L2, L3) are lit, the
clockwise(orcounter-clockwise)rotationarrowindicatesthe
directionofphaserotation.
Warning: Thewrongdirectionofrotationmaybedisplayedifalead
isconnectedinerrortotheneutralconductor.
Refertotheinstrument’sbacklabelforasummaryofthevarious
displaypossibilities.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
8
PhaseRotationMeterModel6608
CHAPTER 5
MAINTENANCE
5.1 Cleaning
To avoid electrical shock or damage to the meter, do not
get water inside the case.
• Periodicallywipethecasewithadampclothandmilddetergent
• Drycompletelybeforeusingagain.
• Donotuseabrasivesorsolvents.
