Advantech EKI-7626C Manuel utilisateur

EKI-7626C

Industrial 16+2G Combo Ports

Managed Redundant Fast

Ethernet Switch

User Manual

EKI-7626C User Manual ii

The documentation and the software included with this product are copyrighted 2007 by

Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make

improvements in the products described in this manual at any time without notice. No part of

this manual may be reproduced, copied, translated or transmitted in any form or by any

means without the prior written permission of Advantech Co., Ltd. Information provided in this

manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no

responsibility for its use, nor for any infringements of the rights of third parties, which may

result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

1st Edition

June 2007

Part No.

Printed in China

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by persons

other than repair personnel authorized by Advantech, or which have been subject to misuse,

abuse, accident or improper installation. Advantech assumes no liability under the terms of

this warranty as a consequence of such events.

Because of Advantech′s high quality-control standards and rigorous testing, most of our

customers never need to use our repair service. If an Advantech product is defective, it will be

repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you

will be billed according to the cost of replacement materials, service time and freight. Please

consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU speed,

Advantech products used, other hardware and software used, etc.) Note anything

abnormal and list any onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product, and any

helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return more

quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement Order

Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable

container. A product returned without proof of the purchase date is not eligible for

warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid to your

dealer.

EKI-7626C User Manual iv

Declaration of Conformity

This product has passed the CE test for environmental specifications. Test conditions for

passing included the equipment being operated within an industrial enclosure. In order to

protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage,

we strongly recommend the use of CE-compliant industrial enclosure products.

FCC Class A

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to correct

the interference at his own expense.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support where you can find

the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech’s customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, application software,

etc.)

- A complete description of the problem

- The exact wording of any error messages

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not

use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equipment and

must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may

cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from

overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the equipment to

the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything over the

power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid

damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by

qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work according to the user's

manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE

TEMPERATURE MAY GO BELOW -40℃(-40℉) OR ABOVE 85℃(185 ℉). THIS

COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A

CONTROLLED ENVIRONMENT.

EKI-7626C User Manual vi

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from damage.

1. To avoid electrical shock, always disconnect the power from your PC chassis before you

work on it. Don't touch any components on the CPU card or other cards while the PC is

on.

2. Disconnect power before making any configuration changes. The sudden rush of power

as you connect a jumper or install a card may damage sensitive electronic components.

vii Contents

Contents

Chapter 1 Overview...........................................2

1.1 Introduction ......................................................... 2

1.1.1 The SFP Advantage .................................. 2

1.1.2 High-Speed Transmissions ....................... 2

1.1.3 Dual Power Input ....................................... 2

1.1.4 Flexible Mounting ...................................... 2

1.1.5 Advanced Protection ................................. 2

1.1.6 Wide Operating Temperature .................... 3

1.1.7 Easy Troubleshooting................................ 3

1.2 Features.............................................................. 4

1.3 Specification ....................................................... 5

1.4 Packing List ........................................................ 7

1.5 Safety Precaution ............................................... 7

Chapter 2 Installation......................................10

2.1 LED Indicators .................................................. 10

Table 2.1: EKI-7626C LED Definition.......................10

2.2 Dimensions (units: mm) .................................... 11

Figure 2.1: Front View of EKI-7626C ........................11

Figure 2.2: Side View of EKI-7626C..........................12

Figure 2.3: Rear View of EKI-7626C .........................13

Figure 2.4: Top View of EKI-7626C...........................14

2.3 Mounting ........................................................... 15

2.3.1 Wall mounting.......................................... 15

Figure 2.5: Combine the Metal Mounting Kit.............15

2.3.2 DIN-rail Mounting..................................... 16

Figure 2.6: Installation to DIN-rail Step 1...................16

Figure 2.7: Installation to DIN-rail Step 2...................17

2.4 Network Connection ......................................... 18

2.5 Connection to a Fiber Optic Network................ 18

Figure 2.8: Transceiver to the SFP module.................18

Figure 2.9: Transceiver Inserted..................................19

Figure 2.10: LC connector to the transceiver ..............19

Figure 2.11: Remove LC connector ............................20

Figure 2.12: Pull out from the transceiver...................20

2.6 Power Connection ............................................ 21

Figure 2.8: Pin Assignment of the Power Connector..21

Chapter 3 Troubleshooting ............................24

Appendix A Pin Assignment & Wiring...........26

Figure A.1: RJ-45 Pin Assignment..............................26

Figure A.2: EIA/TIA-568B .........................................26

Figure A.2: EIA/TIA-568A.........................................26

Appendix B Compatible SFP Modules...........28

EKI-7626C User Manual viii

1 Chapter1

Overview

Sections include:

zIntroduction

zFeatures

zSpecifications

zPacking List

zSafety Precaution

CHAPTER

EKI-7626C User Manual 2

Chapter 1 Overview

1.1 Introduction

Aside from 16 x 10/100Base-TX fast Ethernet ports, the EKI-7626C comes equipped

with 2 combo 10/100/1000 Mbps RJ-45 copper ports/mini-GBIC expansion ports.

Traditional RJ-45 ports can be used for uplinking wide-band paths in short distance (<

100 m), or the appropriate replaceable SFP module can be used for the application of

wideband uploading and long distance transmissions to fit the field request flexibility.

Also, the long MTBF (Mean Time Between Failures) ensures that the EKI-7626C will

continue to operate until a Gigabit network infrastructure has been established, without

requiring any extra upgrade costs.

1.1.1 The SFP Advantage

The EKI-7626C’s two SFP fiber slots provide a lot of flexibility when planning and

implementing a network. The slots can accept any SFP-type fiber module and these

modules are designed for transmitting over distances of either 500m (multi-mode),

10km, 30km, 50km, 70km or 110km (single-mode) – and the slots support SFP

modules for WDM single-fiber transmissions. This means that you can easily change

the transmission mode and distance of the switch by simply pulling out the SFP

module and plugging in a different module. The SFP modules are hot-swappable and

plug-and-play! Also, the fact that the switch has two of these slots, means that the

network manager can, for example, have one 10km module in one slot and one 110km

in the other.

1.1.2 High-Speed Transmissions

The EKI-7626C includes a switch controller that can automatically sense transmission

speeds (10/100 Mbps). The RJ-45 interface can also be auto-detected, so MDI or MDI-

X is automatically selected and a crossover cable is not required.

1.1.3 Dual Power Input

EKI-7626C redundant power input design is with power reserve protection to prevent

the switch device broken by wrong power wiring. When one of power input is fail, P-

Fail LED will turn on and send an alarm through a relay output for notifying user.

1.1.4 Flexible Mounting

EKI-7626C is compact and can be mounted on a DIN-rail or panel, so it is suitable for

any space-constrained environment.

1.1.5 Advanced Protection

The power line of EKI-7626C supports up to 3,000 VDC EFT protection, which secure

equipment against unregulated voltage and make systems safer and more reliable.

Meanwhile, 4,000 VDC ESD protections for Ethernet ports make EKI-7626C more

suitable for harsh environments.

Table des matières

Autres manuels Advantech Routeur réseau

Advantech

Advantech B&B SmartWorx ESWGP506-2SFP-T Manuel utilisateur

Advantech

Advantech EKI-7529MI Manuel utilisateur

Advantech

Advantech ICR-4401 Manuel utilisateur

Advantech

Advantech B+B SmartWorx AirborneM2M BB-ABDN-ER-DP553 Manuel utilisateur

Advantech

Advantech ICR-2031 Manuel utilisateur

Advantech

Advantech CR10 v2 Manuel utilisateur

Advantech

Advantech EKI-4524I Manuel utilisateur

Advantech

Advantech LR77 v2 Series Manuel utilisateur

Advantech

Advantech SmartFlex SR303 Manuel utilisateur

Advantech

Advantech SmartStart SL302 Manuel utilisateur

Advantech

Advantech SmartFlex SR307 Manuel utilisateur

Advantech

Advantech SmartStart SL304 Manuel utilisateur

Advantech

Advantech ICR-1601 Mode d’emploi

Advantech

Advantech SL305 Manuel utilisateur

Advantech

Advantech ICR-3231 Manuel utilisateur

Advantech

Advantech ICR-3232 Manuel utilisateur

Advantech

Advantech ICR-1601 Manuel utilisateur

Advantech

Advantech AirborneM2M BB-ABDN-ER-DP553 Manuel utilisateur

Advantech

Advantech XR5i v2 Mode d’emploi

Advantech

Advantech B+B SmartWorx ER75i v2 Manuel utilisateur

Advantech

Advantech EKI-2526M/S Manuel utilisateur

Advantech

Advantech ICR-2432 Manuel utilisateur

Advantech

Advantech EKI-2528PAI Manuel utilisateur

Advantech

Advantech SmartFlex SR304 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
