Advantech ICR-2734 Manuel utilisateur

Hardware Manual

Industrial Cellular Router

ICR-2734

Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0066-EN, revision from 15th November, 2023.

electronic or mechanical, including photography, recording, or any information storage and retrieval system without written consent.

Information in this manual is subject to change without notice, and it does not represent a commitment on the part of Advantech.

Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnishing, performance,

or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of trademarks or other

designations in this publication is for reference purposes only and does not constitute an endorsement by the trademark holder.

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information – Useful tips or information of special interest.

Contents

1. Product Overview 1

1.1 Product Introduction ......................................... 1

1.2 Product Usage Examples ...................................... 2

1.3 Hardware Overview ......................................... 5

1.4 Order Codes ............................................. 7

1.5 Product Revisions .......................................... 8

1.6 Package Contents and Accessories ................................ 9

1.7 Product Dimensions ......................................... 11

1.8 Mounting Recommendations .................................... 13

1.9 DIN Rail Mounting .......................................... 14

1.10 Product Label ............................................. 15

2. Hardware Functionality 16

2.1 SIM Card Slots ............................................ 16

2.2 Antennas ............................................... 17

2.3 Ethernet Interfaces .......................................... 17

2.4 Power Supply ............................................. 18

2.5 Low Power Mode ........................................... 19

2.6 USB Port ............................................... 19

2.7 LED Status Indication ........................................ 21

2.8 Reset Functions ........................................... 22

3. First Use 23

3.1 Accessories Connection ....................................... 23

3.2 Router Conﬁguration ......................................... 23

4. Technical Speciﬁcations 24

4.1 Basic Parameters ........................................... 24

4.2 Standards and Regulations ..................................... 25

4.3 Type Tests and Environmental Conditions ............................. 26

4.4 Parameters of Cellular Module ................................... 27

4.5 Parameters of WiFi .......................................... 28

4.6 System Conﬁguration ........................................ 29

Appendix A: Troubleshooting 30

Appendix B: Customer Support 33

Appendix C: Regulatory & Safety Information 34

Appendix D: Related Documents 35

List of Figures

1 Access to the Internet from LAN .................................. 2

2 Backed up Access to the Internet .................................. 3

3 Using VPN Tunnel .......................................... 4

4 Hardware Overview of the Router .................................. 5

5 Metal Box – Top, Side and Front View ............................... 11

6 Plastic Box – Top, Side and Front View ............................... 12

7 Position of the DIN Rail Clip ..................................... 14

8 Removing Router from the DIN Rail ................................. 14

9 Product Label ............................................. 15

10 SIM Cards Insertion ......................................... 16

11 Ethernet Connector Pinout ...................................... 17

12 Connection of Power Supply .................................... 18

13 Position of the Grounding Screw .................................. 18

14 USB Connector Pinout ........................................ 20

15 Resetting the Router ......................................... 22

List of Tables

1 Hardware Overview of the Router .................................. 6

2 Order Codes Overview ........................................ 7

3 HW Revisions History ........................................ 8

4 Contents of Package ......................................... 10

5 Ethernet Connector Pinout Description ............................... 17

6 Power Supply Pinout ......................................... 18

7 USB Connector Pinout ........................................ 20

8 LED Status Indication ........................................ 21

9 Basic Parameters ........................................... 24

10 Standards and Regulations ..................................... 25

11 Type Tests and Environmental Conditions ............................. 26

12 Technical Parameters of Cellular Module .............................. 27

13 Technical Parameters of WiFi .................................... 28

14 System Conﬁguration ........................................ 29

1. Product Overview

1.1 Product Introduction

Industrial cellular router ICR-2734 is designed for wireless communication in mobile networks that use

traditional cellular technologies.

The primary purpose of this router is its use in the Category 4 (Cat.4) services on the cellular LTE

network. Cat.4 rated router is capable of achieving typical speeds in 4G coverage areas where the network

is enabled with 20 MHz of contiguous spectrum.

The peak downlink data rate for Category 4 is approximately 150 Mbps. In the uplink, LTE Category 4

provides a peak data rate of 50 Mbps.

The router, which may have a metal or plastic box, is equipped with two independently conﬁgurable

Ethernet ports, two Mini SIM slots (2FF), main and diversity cellular antenna connectors, with one USB

2.0 host interface and with LEDs for status indication. The router can be equipped with a dual-band WiFi

module, but this must be part of the initial conﬁguration – it cannot be assembled to the router at some

point in the future.

The router provides diagnostic functions, which include automatically monitoring the PPP connection,

automatic restart in case of connection losses, Low Power Mode and hardware watchdog that monitors

the router status.

The router supports VPN tunnel creation using various protocols to ensure safe communications. The

router provides diagnostic functions which include automatic monitoring of the wireless and wired connec-

tions, automatic restart in case of connection losses, and a hardware watchdog that monitors the router

status.

With open Linux platform and wide possibilities of programming customer SW applications in Python,

C/C++. The Advantech existing app library Router Apps (formerly User modules) with apps already de-

veloped to enhance speciﬁc router functionality including industrial protocol conversions and support of IoT

platforms such as MS Azure,Cumulocity,ThingWorx, and others are supported on the router.

Examples of possible applications

• mobile ofﬁce

• ﬂeet management

• security system

• telematic

• telemetric

• remote monitoring

• vending and dispatcher machines

ICR-2734 Hardware Manual (preliminary version) 1

1. Product Overview 1.2 Product Usage Examples

1.2 Product Usage Examples

Access to the Internet from LAN

• This example illustrates a typical case when the cellular router is used to access the Internet through

the cellular network.

• Not supported by LAN routers without a cellular interface.

Figure 1: Access to the Internet from LAN

ICR-2734 Hardware Manual (preliminary version) 2

1. Product Overview 1.2 Product Usage Examples

Backed up access to the Internet (from LAN)

• This example illustrates the function of backing up the access to the Internet for a cellular router.

• The access can be backed up by a PPPoE connection, Ethernet wired connection, or by WiFi (for

models supporting WiFi).

Figure 2: Backed up Access to the Internet

ICR-2734 Hardware Manual (preliminary version) 3

1. Product Overview 1.2 Product Usage Examples

Secure networks interconnection or using VPN

• This example illustrates the secure VPN tunnel interconnection between the conﬁgured Advantech

router and a router of a remote network behind the Internet. The cellular network is used to connect

the conﬁgured router to the Internet.

Figure 3: Using VPN Tunnel

ICR-2734 Hardware Manual (preliminary version) 4
