Start Guide

for v2 Routers

01-07-20

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

Start Guide

Safety Instructions

Please take care to following instructions:

•Use the router in compliance with national and international law and in compliance with

any special or additional restrictions regulating the use of the router in the various appli-

cations and environments.

•To avoid possible injury and/or damage to the device, observe the relevant provisions

and standards. Use only the original accessories as recommended. Unauthorized de-

vice or accessory modiﬁcation, or using accessories that have not been approved can

result in router damage and/or violation of the regulations.

•Unauthorized device or accessory modiﬁcation or using the accessories that have not

been approved can result in warranty termination.

•Do not open the router.

•Caution! The SIM card can be swallowed by small children.

•When connecting the device to a power supply do not exceed the deﬁned voltage.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture, and high temperature.

•It is recommended that you do not use the router at petrol ﬁlling stations. We recommend

observing local restrictions concerning the use of radio-based devices while working with

explosive material for example, at petrol ﬁlling stations, or in chemical plants.

•While using the router close to personal medical devices, such as cardiac pacemakers

or hearing aids, proceed with heightened caution.

•Operating the router too close to TV sets, radio receivers, personal computers, or tele-

phones can cause interference.

•It is recommended that you create a copy or backup of the important settings stored in

the memory of the router.

QSG-0001-EN, April 29, 2020 1 Released in the Czech Republic

01-07-20

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

Start Guide

Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) direc-

tive has been introduced to ensure that electrical/electronic products are recy-

cled using the best available recovery techniques to minimize the impact on

the environment. This product contains high-quality materials and components

which can be recycled. At the end of its life, this product MUST NOT be mixed

with other commercial waste for disposal. Check with the terms and conditions

of your supplier for disposal information.

Open Source Software License

The software in this device uses various pieces of open-source software governed by the

following licenses:

•GPL versions 2 and 3

•LGPL version 2

•BSD-style licences

•MIT-style licences

The list of components together with complete license texts can be found on the device

itself. See Licenses link at the bottom of the router’s main Web page (General Status) or point

your browser to this address (replace the DEVICE_IP string with real router’s IP address):

http://DEVICE_IP/licenses.cgi

This is a written offer valid for 3 years since the device purchase offering any third party

for a charge no more than the cost of physically performing source distribution, a complete

machine-readable copy of the corresponding source code on a ﬂash drive medium. If you are

interested in obtaining the source, please contact us at:

cellularsales@advantech-bb.com

Modiﬁcations and debugging of LGPL-linked executables:

The manufacturer of the device hereby grants the right to use debugging techniques (e.g.

decompilation) and making customer modiﬁcations of any executable linked with an LGPL

library for own purposes. Note these rights are limited to the customer’s own usage. No further

distribution of such modiﬁed executables and no transmission of the information obtained

during these actions may be done.

QSG-0001-EN, April 29, 2020 2 Released in the Czech Republic

01-07-20

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

Start Guide

First Use

Before applying power to the router, connect the components that you required for your

applications. You cannot operate the router without a connected antenna, inserted SIM card,

nor a connected power supply.

If you do not have connected the main antenna during operation of the router, the router

can be damaged!

XR5i v2 routers are not equipped with a cellular module, which means that SIM card

readers and antenna connectors are not available on the router.

1. Antenna

Use an SMA connector to connect the antennas to the router. The main antenna is con-

nected to the router by screwing on the ANT connector (see the ﬁgure below). The second

diversity antenna can also be connected to the DIV connector to improve performance.

QSG-0001-EN, April 29, 2020 3 Released in the Czech Republic

01-07-20

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

Start Guide

2. SIM Card

The SIM card reader, for 3 V and 1.8 V SIM cards, is located on the front panel of the

router. The full version of the router contains two readers. If you intend to use this device to

communicate over a cellular network, please place an activated data-provisioned SIM card

with an unblocked PIN into the SIM card reader. Insert your SIM card into the SIM1 or SIM2

holder and push it to the reader (see the ﬁgure below).

Before handling the SIM card disconnect the router from the power supply!

3. Power

The router requires an external DC power supply. The DC voltage required is between

+10 to +30 V DC. The router has built-in protection against reverse polarity without signaling.

Connect the power supply cable to the PWR connector on the front panel of the router (see

the ﬁgure below) and tighten the locking screws.

QSG-0001-EN, April 29, 2020 4 Released in the Czech Republic

01-07-20

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

Start Guide

4. Ethernet

An Ethernet cable may be connected to the ETH connector on the front panel (see the

ﬁgure above). By default, this Ethernet port is conﬁgured as follows:

Connector Purpose Default Setting

ETH LAN port (default)

Connect your laptop or PC to this port to

get a local web-server for device conﬁgu-

ration and diagnostics.

DHCP Server

IP Address: 192.168.1.1

NetMask: 255.255.255.0

If the router is equipped with any expansion port, connect the appropriate cable to the port

PORT1 or PORT2. The pin assignments for expansion ports is described in manual for corre-

sponding expansion port.

Conﬁguration

1. Conﬁguring the Device Using the Web Browser

You can access the router for status monitoring, conﬁguration, and administration after en-

tering the IP address of the router into the web interface. The default IP address is 192.168.1.1

(netmask 255.255.255.0). Conﬁguration access is allowed for the user "root". The default

password is printed on the router’s label.1For a detailed description and examples of the

router conﬁgurations, see the Conﬁguration Manual.

2. Conﬁguring the Device Using the SSH or Telnet

Device management can be done by accessing the device through the Secure Shell (SSH)

or the Telnet protocol. The default IP address of the device is 192.168.1.1. Standard TCP

ports are used, 22 for the SSH and 23 for the Telnet. Please note, that access is permitted for

users of the admin role only and that the Telnet protocol is disabled by default. For a detailed

description of SSH and Telnet conﬁguration, see the Conﬁguration Manual.

1If the router’s label does not contain a unique password, use the password "root".

QSG-0001-EN, April 29, 2020 5 Released in the Czech Republic

01-07-20

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

Start Guide

3. Conﬁguration Settings via WebAccess/DMP

Your router has been pre-installed with the WebAccess/DMP client. If you enable it in

the router’s web interface, you may conﬁgure the router from WebAccess/DMP. Navigate your

browser to:

https://www.wadmp.com

If this is your ﬁrst time, please self-sign-up with the site. If not, please login with your

username and password. Once logged in, further assistance can be found here:

https://docs.wadmp.com

4. Restoring and Backing up the Router Conﬁguration

After you reset the router, the current conﬁguration is overwritten by the default settings.

We recommend that you back up the router conﬁguration before resetting the device. Refer to

the Conﬁguration Manual for more information.

When the PWR LED starts blinking, it is possible to restore the default conﬁguration of the

router by pressing the RST button on the front panel. After pressing this button, the default

conﬁguration is restored and then the router reboots (green LED will be on).

Important Notes

After logging on to the device for the ﬁrst time, we strongly recommend changing the

default password due to security reasons. Simultaneously, you will gain access to all

functions of the router.

For security reasons, it is highly recommended to update the ﬁrmware of the router to the

latest version regularly. Downgrading the ﬁrmware to an older version than the production

version or uploading a ﬁrmware intended for a different device may cause the malfunction

of the device.

Documentation

User’s Manual, Conﬁguration Manual and manual for each expansion port can be found

and downloaded on this web site: www.advantech-bb.cz/download

Hereby, Advantech Czech s.r.o., declares that the radio equipment type CR10 v2,

ER75i v2,LR77 v2,LR77 v2 Libratum,RR75i v2,UR5i v2,UR5i v2 Libratum,XR5i

v2 and XR5i v2E (versions with radio interface only) comply with Directive 2014/53/EU.

XR5i v2 and XR5i v2E versions without radio interface comply with the essential re-

quirements and other relevant provisions of Directives 2014/30/EU and 2014/35/EU.

The full text of the EU Declaration of Conformity is available at the following internet address:

www.advantech-bb.cz/eudoc

QSG-0001-EN, April 29, 2020 6 Released in the Czech Republic
