Advantech ADAM-3016 Manuel utilisateur

ADAM-3016

Strain Gauge Input Module

User’s Manual

ADAM and the ADAM logo are trademarks of Advantech

Part no. 2000016000 1st Edition

Printed in Taiwan August 1997

Introduction

ADAM-3016 is a DIN rail-mounted strain gauge input signal conditioning module

with 1000 VDC 3-way isolation between input, output and power. The switch con-

figurable input and output offers flexible, wide ranging capability for strain gauge.

ADAM-3016 is equipped with a power LED to monitor the line power and a DC-to-

DC converter status and 3 VR (ZERO, SPAN, EXCI) to calibrate input/output

range and excitation voltage.

The ADAM-3016 features three-way isolation. The power supply that drives the

module’s input circuitry and output circuitry is internally isolated, enabling

ADAM-3016 to offer true channel-to-channel isolation.

ADAM-3016’s input bandwidth is typically 2.4 kHz. The ADAM-3016 is powered

by a single +24VDC input. Power can be easily connected from the adjacent

modules, making the wiring simple and easy to maintain. The ADAM-3016 can

be mounted on a DIN rail and operate in environments with high humidity and

wide temperature variation.

Features

•1000 VDC (fully-isolated)

•Easy input/output range configuration

•Flexible DIN-rail mounting

•Low power consumption:

£ 1.85 W (voltage output)

£2.15 W (current output)

•–10° to 70° C operating temperature range

•Operates from a single +24 VDC input

Specifications

Voltage specifications

• Electrical input: ± 10 mV, ± 20 mV, ± 30 mV, ±50 mV, ±100 mV

•Excitation voltage: 1 ~ 10 VDC (60 mA max) (factory default 10 V)

Output

•Voltage output

Bipolar: ±5 V, ±10 V

Unipolar: 0 ~ 10 V

Impedance: < 50 W

•Current output

Current: 0 ~ 20 mA

Current load resistor: 0 ~ 500 W(source)

Specifications

General

•Three-way isolation: 1000 VDC

•Accuracy: ±0.1% of full range

•Bandwidth: 2.4 kHz (typical)

•Stability (temperature drift): 150 ppm (typical)

•Isolation mode rejection: >100 dB @ 50 Hz/60 Hz

•Operation temperature range: -10° to 70° C

Power

•Range: 24 VDC ±10%

•Consumption: £ 1.85 W (voltage output)

£2.15 W (current output)

Ordering Information

•ADAM-3016: Isolated strain gauge signal conditioning module

•ADAM-3920: 20-pin wiring adapter

•ADAM-3937: 37-pin wiring adapter

•ADAM-4350: Intelligent calibrator

•PWR-242: Switching power supply for DIN rail mounting

Configuration

Figure 1 shows the terminal wiring of ADAM-3016. Positive power terminals 9

and 7 are internally connected, as are negative terminals 12 and 10. Power can

be connected through the adjacent modules, making wiring much easier.

ADAM-3016 uses single +24 VDC. Table 1 and table 2 show the switch positions

to configure input and output range. The I/O configuration switches are located

insidethe module. Toreach theswitches, youneed toremove theDIN-rail bracket

by sliding it down.

Figure 1: Terminal wiring diagram

+24 V 9

GND 12

Out+ 8

4 EXCI +

7 +24V

10 GND

11 Out-

2 In-

SW1 SW2

EXCI - 5

1 In+

EXCI

ZERO

SPAN

Input Range Setting (SW2)

Table 1: Input range setting (SW2)

Input Range (SW2)

Range 1 2 3 4 5

+/- 10mV On

+/- 20mV On

+/- 30mV On

+/-50mV On

+/- 100mV On
