Advantech PCA-6753 Manuel d'installation et d'exploitation

PCA-6753 Series Startup Manual 1

Before you begin installing your board, please make

sure that the following materials have been shipped:

• 1 PCA-6753 Series all-in-one single board computer

• 1 startup manual

• 1 utility disk/CD driver, and manual (in PDF format)

• 1 hard disk drive (IDE) interface cable (40-pin)

(part no. 1701400601)

• 1 keyboard / PS2 mouse cable (part no.

1700060201)

• COM port/parallel port cable (part no. 1701260303)

• 1 USB cable (part no. 1700100170)(optional)

• 1 IrdA adapter (part no. 968900042)(optional)

• 1 floppy disk drive interface cable 700 mm (28")

(part no. 1701340700)

• 1 ATX/AT power cable (part no. 1700000450) and

converter (part no. 1700040052 )

• 1 COM3, 4 Cable (part no. 1701200220)

(PCA-6753FC-G0V1 only)

• 1 Warranty Certificate

If any of these items are missing or damaged, contact

your distributor or sales representative immediately.

Note 1: For detailed contents of the PCA-6753

Series please refer to the enclosed CD-

ROM or disk (in PDF format).

Note 2: Acrobat Reader is required to view any PDF

file. Acrobat Reader can be downloaded at:

www.adobe.com/Prodindex/acrobat/

readstep.html

(Acrobat is a trademark of Adobe.)

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support and service, please visit our support

website at:

http://www.advantech.com/support

This manual is for the PCA-6753 series Rev.A3

Part No. 2006675312 3rd Edition

Printed in Taiwan Mar. 2001

PCA-6753 GX1 SBC with CPU, VGA/LCD and

Ethernet

Startup Manual

Standard SBC Functions

•CPU: Embedded Low Power 2.0 V 300/233 MHz NS GX1

processor

•BIOS: AWARD 256 KB Flash BIOS

•System memory: SDRAM DIMM x 1 Max. 128 MB

•Enhanced IDE interface: Supports up to two IDE

devices. BIOS auto-detect, PIO Mode 3 or Mode 4

transfer, Ultra DMA33 mode (ATA-4) up to 33 MB/sec (w/

Driver installation)

•FDD interface: Supports up to two FDD devices

•Serial ports: 2 serial ports: COM1 (RS232), COM2

(RS232/422/485), 4 serial ports for PCA-6753FC-G0B1

only: COM1, 3 and 4 (RS-232), COM2 (RS232/422/485)**

•Parallel port: One parallel port, supports EPP/EPC

mode

•Infrared port: One 115 K fast infrared (SIR) port, IrDA

1.1 compliant

•Keyboard/mouse connector: Mini-Din connector

supports standard PC/AT keyboard and PS/2 mouse

•USB interface: 2 USB ports, USB 1.0 compliant

•Power management: APM 1.2

•Watchdog timer: 1 ~ 62 sec. System reset or IRQ11

Local-bus Flat Panel/VGA Interface

•Chipset: NS CS5530A

•Display memory: 1 ~ 4 MB share memory, set in BIOS

•Display type: Supports CRT and TFT LCDs. Able to

display both CRT and flat panel simultaneously

•Flat-panel display mode: Panel resolution supports up

to 1024 x 768 @ 16 bpp. Supports 18-bit TFT LCD panel

•CRT display mode: Non-interlaced CRT monitor

resolutions up to 1280 x 1024 @ 256 colors or 1024 x

768 @ 16 bpp

Ethernet Interface (PCA-6753F)

•Chipset: RTL 8139

•Ethernet interface: PCI 10/100 Mbps Ethernet. IEEE

802.3 U protocol compatible

•Connection: On-board RJ-45 connector

•I/O address switchless setting

•Built-in boot ROM

•Supports Wake-on-Lan

PCA-6753 GX1 SBC with CPU, VGA/LCD and Ethernet

Packing List Specifications

** Please Note: COM mouse cannot share IRQ with other three COMs

2PCA-6753 Series Startup Manual

Jumpers and Connectors

Connectors on the board link it to external devices such as

hard disk drives, a keyboard or expansion bus connectors.

In addition, the board has a number of jumpers that allow

you to configure your system to suit your application.

The tables below lists the function of each of the

board's jumpers and connectors:

Table 2-1: Jumpers

Label Function

JP1 LCD Voltage select & Wake-up on LAN

JP8 DOC®2000 Address select

JP9 CMOS clear & Watchdog trigger output

JP10 RS-232/RS-422/RS-485 select

Table 2-2: Connectors

Label Function

CN1 HDD connector

CN2 FDD connector

CN3 Printer port connector

CN4 DIMM

CN5 LCD 18-bit connector

CN6 VGA connector

CN7 LAN connector

CN8 PC/104 connector

CN9 AT (big 4P) power connector

CN10 COM2 connector (RS-232)

CN11 COM2 connector (RS-422/RS-485)

CN12 COM1 connector

CN13 ATX power stand-by connector

CN15 Internal keyboard connector

CN16 PS/2 keyboard + PS/2 mouse

CN17 ISA Golden Finger connector

CN18 ISA Golden Finger connector

CN20 USB connector

CN21 Multiple connector

JP13 COM3, COM4 connector

PCA-6753 Locating jumpers (component side)

Locating Jumpers

Locating connectors ( component side)

Solid State Disk

• SupportsDiskOnChip®

Mechanical and Environmental

•Dimensions (L x W): 185 mm x 122 mm

•Power supply voltage: +5 V (4.75 V ~ 5.25 V)

•Power requirements:

Maximum: 5 V @ 4 A

Typical: +5 V @ 1.5 A (for GX1-300 version)

+5 V @ 1.4 A (for GX1-233 version)

•Operating temperature: 0 ~ 60° C (32 ~ 140° F)

•Weight: 0.27 kg ( 0.59 lbs.)

Locating Connectors

PCA-6753 Series Startup Manual 3

JP1: LCD Voltage select & Wake-up on LAN ATX

PWR

Pin Function

1-3 LCD Panel VDD +3.3 V

3-5 LCD Panel VDD +5 V*

2-4 Wake-up on LAN ATX power standby

4-6 Normal condition*

LCD 3.3 V LCD 5V* WOL ATX Normal*

COD

tcelessserdda0002

8PJ2-14-36-5

FFOFFOFFOFFO

FFFDD-000CDFFOnOFFO

FFF9D-0008DFFOnOnO

FFF5D-0004DnOFFOFFO

*FFF1D-000DnOFFOnO

FFFDC-000CCnOnOFFO

FFF9D-0008CnOnOnO

JP8: DOC® 2000 Address select

CN21 Multiple connector location

JP10: RS-232/RS-422/RS-485 select

Pin Function

1-2 COM2/232

3-4 COM2/422

5-6 COM2/485

External speaker connection

JP4: 5-7 Result

Closed Internal speaker enabled

Open Internal speaker disabled

OFF

DC000-

DDFFF

D8000-

D9FFF

D4000-

D5FFF

D000-

D1FFF*

CC000-

CDFFF

C8000-

D9FFF

4PCA-6753 Series Startup Manual

Board Dimensions (component side)

Mechanical Drawings

Board Dimensions (solder side)

JP9: Multiple Connection

(1-3-5) Watchdog timer

Pin Function

1-3 IRQ 11

3-5 Reset*

(2-4-6) CMOS clear

Pin Function

2-4 Normal*

4-6 Clear CMOS

Locating connectors (solder side)

IRQ11 Reset*

Normal* Clear CMOS
