Advantech ECU-P1522LPE Manuel d'installation et d'exploitation

ECU-P1522LPE Startup Manual 1

Before installation, please make sure that you have re-

ceived the following:

• ECU-P1522LPE card

• Quick Start User Manual

If anything is missing or damaged, contact your distributor

or sales representative immediately.

For more detailed information on this product, please refer

to the ECU-P1522LPE User Manual on the Website (PDF

format).

FCC Class A

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable

protection against harmful interference when the equipment

is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruc-

tion manual, may cause harmful interference to radio com-

munications. Operation of this equipment in a residential

area is likely to cause interference in which case the user is

required to correct interference at his own expense.

This product has passed the CE test for environmental

specicationswhenshieldedcablesareusedforexternal

wiring. We recommend the use of shielded cables. This kind

of cable is available from Advantech. Please contact your

local supplier for ordering information.

ECU-P1522LPE 2-Port SFP HSR/PRP Card with Low

Prole PCI Express

Startup Manual

The ECU-P1522LPE is a standard PCIE extension card

with HSR/PRP functions to reduce data transfer packet loss

probability and ensure seamless switching.

• TheECU-P1522LPEsupportsfollowingspecications:

• 2 port SFP Base Ethernet Card with HSR/PRP

• Supports HSR Protocol (IEC 62439-3 Clause 5)

• Supports PRP Protocol (IEC 62439-3 Clause 4)

• BUS Type: PCI-Express x1 Gen 1

• Dimensions: 68.9 x 181 x 20.32 mm

• Power Consumption: 12V ±5% @ 500mA typical;

3.3V ±5% @ 600mA typical;

• Operating Temp: -25 ~ 70°C (-13 ~158°F)

• Operating Humidity: 10 ~ 90% RH non-condensing (refer

to IEC 60068-2-3)

After the device driver is installed, you can now install the

ECU-P1522LPE card in your computer.

Please follow the steps below to install the ECU-P1522LPE

card:

1. Turno󰀨yourcomputerandunplugthepowercordand

cables. TURN OFF your computer before installing or

removing any components on the computer.

2. Remove the cover of your computer.

3. Remove the slot cover on the back panel of your

computer.

4. Touch the metal part on the surface of your computer

to neutralize the static electricity that might be on your

body.

5. Insert the ECU-P1522LPE card into a PCI Express

slot. Hold the card only by its edges and carefully align

itwiththeslot.Insertthecardrmlyintoplace.Useof

excessive force must be avoided; otherwise, the card

might be damaged.

6. Fasten the bracket of the PCI Express card on the back

panel rail of the computer with screws.

7. Connect SFP modules to the SFP ports.

8. Replace the cover of your computer chassis.

9. Plug in the power cord and turn on the computer.

OverviewPacking List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com/eAutomation

For technical support and service:

http://www.advantech.com/support/

This startup manual is for ECU-P1522LPE.

Part No.

Printed in China

1st Edition

August 2023

Declaration of Conformity

Hardware Installation

Specications

2 ECU-P1522LPE Startup Manual

Name Function Interface

A RedBox_A

100M Base-FX SFP Interface

(Select by SFP MODE)

1000M Base-X SFP Interface

(Select by SFP MODE)

B RedBox_B

100M Base-FX SFP Interface

(Select by SFP MODE)

1000M Base-X SFP Interface

(Select by SFP MODE)

InterLink RedBox_

Interlink 10/100/1000 Mbps Base-T

Name Function Interface

A_ACT Blinking SFP module A transmit data

A_Link

Yellow 100M Base-FX SFP_A is

linked

Green 1000M Base-X SFP_A is

linked

B_ACT Blinking SFP module B transmit data

B_Link

Yellow 100M Base-FX SFP_B is

linked

Green 1000M Base-X SFP_B is

linked

Mode_1

HSR/PRP

mode

No light Normal switch

Green HSR

Yellow PRP

Mode_2

SFP mode

Yellow 100M Base-FX SFP

Green 1000M Base-X SFP

Intel link

Blink(Green) Interlink port transmit data

Yellow Interlink port 100M linked

Green Interlink port 1000M linked

Connector and LED Assignments

Switch Mode SW1

Normal Switch OFF OFF OFF OFF

HSR OFF ON OFF OFF

PRP ON ON OFF OFF

SFP Mode SW2

1000M Base-FX

100M Base-FX

Switch and Jumper Settings
